QIBR XSU Series Crossed Cylindrical Roller Bearings: Material Options and Application Selection Guide
The QIBR XSU Series Crossed Cylindrical Roller Bearings feature an integrated inner and outer ring design with mounting holes, eliminating the need for flanges and support bases, making installation simpler. These bearings are suitable for both outer ring and inner ring rotation. They are equipped with seals that prevent contaminants from entering the bearing, reduce grease leakage, and lower maintenance costs. Both axial and radial sides feature lubrication holes for convenient multi-directional oil injection.
The QIBR XSU Series Crossed Cylindrical Roller Bearings are typically made from AISI 52100 material, which provides excellent wear resistance and strength, making them ideal for high-load applications.
For harsh environments, the XSU Series is available in AISI 440C stainless steel.
The choice of material depends on specific application requirements, such as load, strength, and environmental conditions, to ensure optimal bearing performance and service life. By considering these factors, users can select the most suitable bearings for their applications.
QIBR
Model Selection
| NO. | Product | Product Number | Mass | Da h6 | Fixing Holes La | di H6 | Fixing Holes Li | Limiting Speedsmin-1 |
|---|---|---|---|---|---|---|---|---|
| 1 |
|
QXSU 140414 | 28kg | 460 | 368 | 92 | ||
| 2 |
|
QXSU 080168 | 3.3kg | 205(+0~-0.029)mm | 190 | 130(+0,025~–0)mm | 145 | 227 |
| 3 |
|
QXSU 140544 | 38kg | 590 | 498 | 70 | ||
| 4 |
|
QXSU 080188 | 3,7kg | 225(+0~-0.029)mm | 210 | 150(+0,025~–0)mm | 165 | 203 |
| 5 |
|
QXSU 140644 | 44kg | 690 | 598 | 59 | ||
| 6 |
|
QXSU 080218 | 4,3kg | 255(+0~-0.032)mm | 240 | 180(+0,025~–0)mm | 195 | 175 |
| 7 |
|
QXSU 140744 | 52kg | 790 | 698 | 51 | ||
| 8 |
|
QXSU 080318 | 6,3kg | 355(+0~-0.036)mm | 340 | 280(+0,032~–0)mm | 295 | 120 |
| 9 |
|
QXSU 140844 | 60kg | 890 | 798 | 45 | ||
| 10 |
|
QXSU 080258 | 5,1kg | 295(+0~-0.032)mm | 280 | 220(+0,029~–0)mm | 235 | 148 |
| 11 |
|
QXSU 140944 | 67kg | 990 | 898 | 40 | ||
| 12 |
|
QXSU 080398 | 7,8kg | 435(+0~-0.040)mm | 420 | 360(+0,036~–0)mm | 375 | 96 |
| 13 |
|
QXSU 141094 | 77kg | 1140 | 1048 | 35 |
Features and Advantages of QIBR XSU Series Crossed Cylindrical Roller Bearings
High Rigidity and Load Capacity
Despite its compact design, the QIBR XSU Series Crossed Cylindrical Roller Bearings offer excellent rigidity and load-bearing capacity, making them suitable for high-load applications.
Optimized Structural Design
The integrated inner and outer ring design with mounting holes in the XSU Series eliminates the need for flanges and support bases, simplifying installation. These bearings are suitable for both outer and inner ring rotation. The sealing design prevents contaminants from entering the bearing, reduces grease leakage, and lowers maintenance costs. Lubrication holes on both the axial and radial sides allow for convenient multi-directional oil injection.
Low Friction and High Efficiency
The QIBR XSU Series Crossed Cylindrical Roller Bearings reduce bearing friction torque, making them suitable for applications requiring low driving torque and enhancing overall equipment efficiency.
Customizable Services
QIBR XSU Series Crossed Cylindrical Roller Bearings offer custom services, allowing for specific bearing designs to meet the unique requirements of various industries and operational conditions.
Performance Enhancements and Solutions for the QIBR XSU Series Crossed Cylindrical Roller Bearings
Enhanced Material Performance for Increased Load Capacity
QIBR XSU Series bearings are made using high-quality steel for the inner and outer rings and rollers. Vacuum heat treatment improves surface hardness and material performance, increasing the bearing's load capacity and service life.
Improved Manufacturing Precision and Load Capacity
Advanced foreign processing equipment and techniques, such as precision grinding, are used in the production of the QIBR XSU Series to enhance the geometric accuracy of the inner and outer rings and rollers, reducing machining errors and improving rotational precision and operational stability.
Personalized Design
For different application demands, the QIBR XSU Series offers personalized structural dimension solutions to meet specific performance requirements. This approach not only broadens the bearing standards but also provides manufacturers with effective guidance to meet users' unique needs.
In conclusion, by optimizing materials, manufacturing precision, and offering customized design solutions, the performance of the QIBR XSU Series Crossed Cylindrical Roller Bearings can be significantly enhanced, meeting increasingly stringent application requirements.
Main Application Areas of QIBR XSU Series Crossed Cylindrical Roller Bearings
Industrial Robots
The QIBR XSU Series sealed crossed roller bearings can handle high loads while providing precise motion control, making them ideal for the rotary sections of industrial robots.
Rotary Tables
With extremely high rigidity, the XSU Series can withstand loads from multiple directions, ensuring greater stability and precision during rotary table operations.
Medical Equipment
The high rigidity and vibration resistance of the QIBR XSU Series make them suitable for providing stable support in medical equipment, particularly for devices requiring precise positioning and operation.
