Needle Rollers

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Material

52100

Applications

Bearing Manufacturing, Automotive and Medical Devices

Diameter (Dw)

1mm-6mm

Length (Lw)

5.8mm-39.8mm

Mass

0.048kg-6.13kg (1000 pieces)

Needle Rollers

Filters

NO. Product Product Number Diameter (Dw) Length (Lw) Mass
1 Needle Needle Roller NRB1X7.8-G2 1 mm 7.8 mm 0.048 kg
2 Needle Needle Roller NRB1.5X5.8-G2 1.5 mm 5.8 mm 0.081 kg
3 Needle Needle Roller NRB1.5X6.8-G2 1.5 mm 6.8 mm 0.094 kg
4 Needle Needle Roller NRB1.5X7.8-G2 1.5 mm 7.8 mm 0.108 kg
5 Needle Needle Roller NRB1.5X9.8-G2 1.5 mm 9.8 mm 0.136 kg
6 Needle Needle Roller NRB1.5X11.8-G2 1.5 mm 11.8 mm 0.164 kg
7 Needle Needle Roller NRB1.5X13.8-G2 1.5 mm 13.8 mm 0.191 kg
8 Needle Needle Roller NRB2X6.3-G2 2 mm 6.3 mm 0.16 kg
9 Needle Needle Roller NRB2X7.8-G2 2 mm 7.8 mm 0.19 kg
10 Needle Needle Roller NRB2X9.8-G2 2 mm 9.8 mm 0.24 kg
11 Needle Needle Roller NRB2X11.8-G2 2 mm 11.8 mm 0.29 kg
12 Needle Needle Roller NRB2X13.8-G2 2 mm 13.8 mm 0.34 kg
13 Needle Needle Roller NRB2X15.8-G2 2 mm 15.8 mm 0.39 kg
14 Needle Needle Roller NRB2X17.8-G2 2 mm 17.8 mm 0.44 kg
15 Needle Needle Roller NRB2X19.8-G2 2 mm 19.8 mm 0.49 kg
16 Needle Needle Roller NRB2X21.8-G2 2 mm 21.8 mm 0.54 kg
17 Needle Needle Roller NRB2.5X7.8-G2 2.5 mm 7.8 mm 0.3 kg
18 Needle Needle Roller NRB2.5X9.8-G2 2.5 mm 9.8 mm 0.38 kg
19 Needle Needle Roller NRB2.5X11.8-G2 2.5 mm 11.8 mm 0.45 kg
20 Needle Needle Roller NRB2.5X13.8-G2 2.5 mm 13.8 mm 0.53 kg
21 Needle Needle Roller NRB2.5X15.8-G2 2.5 mm 15.8 mm 0.61 kg
22 Needle Needle Roller NRB2.5X17.8-G2 2.5 mm 17.8 mm 0.69 kg
23 Needle Needle Roller NRB2.5X19.8-G2 2.5 mm 19.8 mm 0.76 kg
24 Needle Needle Roller NRB2.5X21.8-G2 2.5 mm 21.8 mm 0.84 kg
25 Needle Needle Roller NRB2.5X23.8-G2 2.5 mm 23.8 mm 0.92 kg
26 Needle Needle Roller NRB3X9.8-G2 3 mm 9.8 mm 0.54 kg
27 Needle Needle Roller NRB3X11.8-G2 3 mm 11.8 mm 0.65 kg
28 Needle Needle Roller NRB3X13.8-G2 3 mm 13.8 mm 0.77 kg
29 Needle Needle Roller NRB3X15.8-G2 3 mm 15.8 mm 0.88 kg
30 Needle Needle Roller NRB3X17.8-G2 3 mm 17.8 mm 0.99 kg
31 Needle Needle Roller NRB3X19.8-G2 3 mm 19.8 mm 1.1 kg
32 Needle Needle Roller NRB3X21.8-G2 3 mm 21.8 mm 1.21 kg
33 Needle Needle Roller NRB3X23.8-G2 3 mm 23.8 mm 1.32 kg
34 Needle Needle Roller NRB3.5X11.8-G2 3.5 mm 11.8 mm 0.89 kg
35 Needle Needle Roller NRB3.5X13.8-G2 3.5 mm 13.8 mm 1.04 kg
36 Needle Needle Roller NRB3.5X15.8-G2 3.5 mm 15.8 mm 1.19 kg
37 Needle Needle Roller NRB3.5X17.8-G2 3.5 mm 17.8 mm 1.34 kg
38 Needle Needle Roller NRB3.5X19.8-G2 3.5 mm 19.8 mm 1.5 kg
39 Needle Needle Roller NRB3.5X21.8-G2 3.5 mm 21.8 mm 1.65 kg
40 Needle Needle Roller NRB3.5X29.8-G2 3.5 mm 29.8 mm 2.25 kg
41 Needle Needle Roller NRB3.5X34.8-G2 3.5 mm 34.8 mm 2.63 kg
42 Needle Needle Roller NRB4X11.8-G2 4 mm 11.8 mm 1.16 kg
43 Needle Needle Roller NRB4X13.8-G2 4 mm 13.8 mm 1.36 kg
44 Needle Needle Roller NRB4X15.8-G2 4 mm 15.8 mm 1.56 kg
45 Needle Needle Roller NRB4X17.8-G2 4 mm 17.8 mm 1.76 kg
46 Needle Needle Roller NRB4X19.8-G2 4 mm 19.8 mm 1.95 kg
47 Needle Needle Roller NRB4X21.8-G2 4 mm 21.8 mm 2.15 kg
48 Needle Needle Roller NRB4X23.8-G2 4 mm 23.8 mm 2.35 kg
49 Needle Needle Roller NRB4X25.8-G2 4 mm 25.8 mm 2.55 kg
50 Needle Needle Roller NRB4X27.8-G2 4 mm 27.8 mm 2.74 kg
51 Needle Needle Roller NRB4X29.8-G2 4 mm 29.8 mm 2.94 kg
52 Needle Needle Roller NRB4X34.8-G2 4 mm 34.8 mm 3.43 kg
53 Needle Needle Roller NRB4X39.8-G2 4 mm 39.8 mm 3.93 kg
54 Needle Needle Roller NRB5X15.8-G2 5 mm 15.8 mm 2.44 kg
55 Needle Needle Roller NRB5X19.8-G2 5 mm 19.8 mm 3.05 kg
56 Needle Needle Roller NRB5X21.8-G2 5 mm 21.8 mm 3.36 kg
57 Needle Needle Roller NRB5X23.8-G2 5 mm 23.8 mm 3.67 kg
58 Needle Needle Roller NRB5X25.8-G2 5 mm 25.8 mm 3.98 kg
59 Needle Needle Roller NRB5X27.8-G2 5 mm 27.8 mm 4.28 kg
60 Needle Needle Roller NRB5X29.8-G2 5 mm 29.8 mm 4.59 kg
61 Needle Needle Roller NRB5X34.8-G2 5 mm 34.8 mm 5.36 kg
62 Needle Needle Roller NRB5X39.8-G2 5 mm 39.8 mm 6.13 kg
63 Needle Needle Roller NRB6X17.8-G2 6 mm 17.8 mm 3.95 kg

Characteristics of needle rollers

Low friction: Due to the principle of rolling friction, needle roller bearings have less friction and high efficiency than sliding bearings.

High precision: Some high-precision needle rollers can be used in high-speed and precision equipment.


When choosing needle rollers, the following factors need to be considered:

Load requirements: Choose the appropriate specifications according to the load size required.

Speed requirements: When running at high speed, choose rollers made of materials that are suitable for high speed.

Temperature and environment: Choose appropriate materials and sealing methods according to the temperature and pollution conditions of the working environment.

Lubrication: Reasonable lubrication can reduce friction and extend the service life of the bearing.
