Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
1 S311/ S311 11 4.666 inch 12.00 lbs 4.000 inch 3
2 S312/ S312 12 4.666 inch 11.00 lbs 4.000 inch 3
3 S313/ S313 13 5.000 inch 10.70 lbs 4.333 inch 3
4 S314/ S314 14 5.333 inch 12.80 lbs 4.667 inch 3
5 S315/ S315 15 5.666 inch 14.80 lbs 5.000 inch 3
6 S316/ S316 16 6.000 inch 17.00 lbs 5.333 inch 3
7 S318/ S318 18 6.666 inch 22.00 lbs 6.000 inch 3
8 S320/ S320 20 7.333 inch 27.40 lbs 6.667 inch 3
9 S321/ S321 21 7.666 inch 30.70 lbs 7.000 inch 3
10 S324/ S324 24 8.666 inch 48.20 lbs 8.000 inch 3
11 S330/ S330 30 10.666 inch 74.50 lbs 10.000 inch 3
12 S336/ S336 36 12.666 inch 114.00 lbs 12.000 inch 3
13 S342/ S342 42 14.666 inch 106.00 lbs 14.000 inch 3
14 S348/ S348 48 16.666 inch 120.00 lbs 16.000 inch 3
15 S354/ S354 54 18.666 inch 134.00 lbs 18.000 inch 3
16 S360/ S360 60 20.666 inch 150.00 lbs 20.000 inch 3
17 S372/ S372 72 24.666 inch 180.00 lbs 24.000 inch 3
18 S384/ S384 84 28.666 inch 215.00 lbs 28.000 inch 3
19 S396/ S396 96 32.666 inch 264.00 lbs 32.000 inch 3
20 S3108/ S3108 108 36.666 inch 305.00 lbs 36.000 inch 3
21 S3120/ S3120 120 40.666 inch 367.00 lbs 40.000 inch 3
22 C324/ C324 24 8.666 inch 40.40 lbs 8.000 inch 3
23 C328/ C328 28 10.000 inch 54.20 lbs 9.333 inch 3
24 C330/ C330 30 10.666 inch 57.10 lbs 10.000 inch 3
25 C332/ C332 32 11.333 inch 62.40 lbs 10.667 inch 3
26 C336/ C336 36 12.666 inch 71.30 lbs 12.000 inch 3
27 C340/ C340 40 14.000 inch 75.90 lbs 13.333 inch 3
28 C342/ C342 42 14.666 inch 79.50 lbs 14.000 inch 3
29 C345/ C345 45 15.666 inch 85.00 lbs 15.000 inch 3
30 C348/ C348 48 16.666 inch 92.90 lbs 16.000 inch 3
31 C354/ C354 54 18.666 inch 104.00 lbs 18.000 inch 3
32 C360/ C360 60 20.666 inch 115.00 lbs 20.000 inch 3
33 C372/ C372 72 24.666 inch 153.00 lbs 24.000 inch 3
34 C375/ C375 75 25.666 inch 155.00 lbs 25.000 inch 3
35 C384/ C384 84 28.666 inch 178.00 lbs 28.000 inch 3
36 C390/ C390 90 30.666 inch 185.00 lbs 30.000 inch 3
37 C396/ C396 96 32.666 inch 205.00 lbs 32.000 inch 3
38 C3105/ C3105 105 35.666 inch 216.00 lbs 35.000 inch 3
39 C3108/ C3108 108 36.666 inch 228.00 lbs 36.000 inch 3
40 C3120/ C3120 120 40.666 inch 226.00 lbs 40.000 inch 3
41 S411/ S411 11 3.500 inch 4.00 lbs 3.000 inch 4
42 S412/ S412 12 3.500 inch 3.90 lbs 3.000 inch 4
43 S413/ S413 13 3.750 inch 4.60 lbs 3.250 inch 4
44 S414/ S414 14 4.000 inch 5.70 lbs 3.500 inch 4
45 S415/ S415 15 4.250 inch 6.80 lbs 3.750 inch 4
46 S416/ S416 16 4.500 inch 8.00 lbs 4.000 inch 4
47 S417/ S417 17 4.750 inch 9.20 lbs 4.250 inch 4
48 S418/ S418 18 5.000 inch 10.40 lbs 4.500 inch 4
49 S419/ S419 19 5.250 inch 10.50 lbs 4.750 inch 4
50 S420/ S420 20 5.500 inch 13.40 lbs 5.000 inch 4
51 S421/ S421 21 5.750 inch 14.90 lbs 5.250 inch 4
52 S422/ S422 22 6.000 inch 16.50 lbs 5.500 inch 4
53 S424/ S424 24 6.500 inch 22.80 lbs 6.000 inch 4
54 S426/ S426 26 7.000 inch 24.80 lbs 6.500 inch 4
55 S428/ S428 28 7.500 inch 27.80 lbs 7.000 inch 4
56 S430/ S430 30 8.000 inch 31.00 lbs 7.500 inch 4
57 S432/ S432 32 8.500 inch 34.40 lbs 8.000 inch 4
58 S436/ S436 36 9.500 inch 41.70 lbs 9.000 inch 4
59 S440/ S440 40 10.500 inch 51.80 lbs 10.000 inch 4
60 S442/ S442 42 11.000 inch 56.00 lbs 10.500 inch 4
61 S444/ S444 44 11.500 inch 60.80 lbs 11.000 inch 4
62 S448/ S448 48 12.500 inch 70.80 lbs 12.000 inch 4
63 S454/ S454 54 14.000 inch 57.40 lbs 13.500 inch 4
64 S456/ S456 56 14.500 inch 59.90 lbs 14.000 inch 4
65 S460/ S460 60 15.500 inch 62.80 lbs 15.000 inch 4
66 S464/ S464 64 16.500 inch 66.20 lbs 16.000 inch 4
67 S472/ S472 72 18.500 inch 82.90 lbs 18.000 inch 4
68 S480/ S480 80 20.500 inch 95.00 lbs 20.000 inch 4
69 S484/ S484 84 21.500 inch 92.00 lbs 21.000 inch 4
70 S488/ S488 88 22.500 inch 95.80 lbs 22.000 inch 4
71 S496/ S496 96 24.500 inch 124.00 lbs 24.000 inch 4
72 S4120/ S4120 120 30.500 inch 155.00 lbs 30.000 inch 4
73 S4144/ S4144 144 36.500 inch 208.00 lbs 36.000 inch 4
74 C424/ C424 24 6.500 inch 17.00 lbs 6.000 inch 4
75 C428/ C428 28 7.500 inch 20.20 lbs 7.000 inch 4
76 C430/ C430 30 8.000 inch 21.10 lbs 7.500 inch 4
77 C432/ C432 32 8.500 inch 23.20 lbs 8.000 inch 4
78 C436/ C436 36 9.500 inch 30.50 lbs 9.000 inch 4
79 C440/ C440 40 10.500 inch 26.40 lbs 10.000 inch 4
80 C442/ C442 42 11.000 inch 33.90 lbs 10.500 inch 4
81 C444/ C444 44 11.500 inch 32.00 lbs 11.000 inch 4
82 C448/ C448 48 12.500 inch 38.40 lbs 12.000 inch 4
83 C452/ C452 52 13.500 inch 42.50 lbs 13.000 inch 4
84 C454/ C454 54 14.000 inch 44.70 lbs 13.500 inch 4
85 C456/ C456 56 14.500 inch 46.70 lbs 14.000 inch 4
86 C460/ C460 60 15.500 inch 49.50 lbs 15.000 inch 4
87 C464/ C464 64 16.500 inch 54.50 lbs 16.000 inch 4
88 C468/ C468 68 17.500 inch 56.00 lbs 17.000 inch 4
89 C472/ C472 72 18.500 inch 63.00 lbs 18.000 inch 4
90 C480/ C480 80 20.500 inch 72.00 lbs 20.000 inch 4
91 C484/ C484 84 21.500 inch 73.00 lbs 21.000 inch 4
92 C488/ C488 88 22.500 inch 75.00 lbs 22.000 inch 4
93 C496/ C496 96 24.500 inch 86.00 lbs 24.000 inch 4
94 C4100/ C4100 100 25.500 inch 91.00 lbs 25.000 inch 4
95 C4104/ C4104 104 26.500 inch 105.00 lbs 26.000 inch 4
96 C4112/ C4112 112 28.500 inch 108.00 lbs 28.000 inch 4
97 C4120/ C4120 120 30.500 inch 115.00 lbs 30.000 inch 4
98 C4132/ C4132 132 33.500 inch 129.00 lbs 33.000 inch 4
99 C4144/ C4144 144 36.500 inch 140.00 lbs 36.000 inch 4
100 S511/ S511 11 2.800 inch 2.00 lbs 2.400 inch 5
