Image may differ from product. See technical specification for details.
Standard
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material
52100/100Cr6/SUJ2/Stainless Steel
Brand
QIBR/OEM/Neutral
Package
QIBR/Standard Industrial Package/OEM
Inner diameter
300~370mm
Outer diameter
400~495mm
Applications
Aerospace Industry, Robotics, Medical Devices, Semiconductor Manufacturing Equipment, Optical Equipment, Industrial Machinery, Automotive, etc

NO. | Product | Product Number | Coefficient (K) | Dynamic radial load | Dynamic load axial | Inner diameter (d) | Outer diameter (D) | Thickness (T) |
---|---|---|---|---|---|---|---|---|
1 |
![]() |
JXR637050 | 0.45 | 63000 N | 80100 N | 300.000 mm | 400.000 mm | 37.000 mm |
2 |
![]() |
JXR652050 | 0.46 | 82200 N | 102000 N | 310.000 mm | 425.000 mm | 45.000 mm |
3 |
![]() |
JXR699050 | 0.45 | 93600 N | 119000 N | 370.000 mm | 495.000 mm | 50.000 mm |
Features and advantages of QIBR metric cross tapered roller bearings
QIBR metric cross tapered roller bearings have many significant features and advantages, solving key problems in various fields, mainly reflected in the following aspects:
1. QIBR metric cross tapered roller bearings have the characteristics of high rigidity and high load capacity
Although QIBR metric cross tapered roller bearings are compact in design, they have good rigidity and load capacity and are suitable for high-load applications.
2. QIBR metric cross tapered roller bearings have the characteristics of optimized structural design
The tapered geometry design of QIBR metric cross tapered roller bearings makes the overall effective span of the bearing several times the width of the bearing itself. Make the bearing more stable and able to withstand greater overturning torque.
3. QIBR Metric Cross Tapered Roller Bearings have the characteristics of low friction and high efficiency
The QIBR Metric Cross Tapered Roller Bearing process reduces the friction torque of the bearing, is suitable for use with low driving torque requirements, and improves the overall operating efficiency of the equipment.
4. QIBR Metric Cross Tapered Roller Bearings Customized Service
QIBR Metric Cross Tapered Roller Bearings usually provide customized services, and can design bearings according to specific needs to meet the special requirements and operating conditions of different industries.
QIBR Metric Cross Tapered Roller Bearings Performance Improvement and Solutions
1. Effectively improve material properties and enhance high load-bearing capacity
QIBR Metric Cross Tapered Roller Bearings are produced using high-quality steel to manufacture inner and outer rings and balls, and vacuum heat treatment or carburizing quenching is used to improve the surface hardness and material properties, thereby improving the load capacity and service life of the bearing.
2. Improve manufacturing accuracy and load capacity
QIBR metric cross tapered roller bearings are produced using advanced foreign processing equipment and processes, such as precision grinding, to improve the geometric accuracy of the inner and outer rings and balls, reduce processing errors, and thus improve the rotation accuracy and operation stability of the bearings.
3. Personalized design
According to the application requirements of QIBR metric cross tapered roller bearings in different occasions, personalized structural size solutions are provided to meet specific performance requirements. This approach not only enriches the standards of bearings, but also provides effective guidance for manufacturers to meet the personalized needs of users.
In short, by optimizing materials, manufacturing accuracy, personalized design and other measures, the performance of QIBR metric cross tapered roller bearings can be significantly improved to meet increasingly demanding application requirements.
Main application areas of QIBR metric cross tapered roller bearings
Vertical grinders
QIBR metric cross tapered roller bearings can provide high-precision positioning due to their design to reduce clearance and deformation. This is essential for the precise rotation of the spindle in the vertical grinder and the accuracy of the grinding process. The rigidity of the bearing can reduce vibration and error during the operation of the grinder, and improve processing accuracy and surface finish.
Large gear hobbing machine
QIBR metric cross tapered roller bearings have high rigidity, which helps to reduce vibration during machine operation and ensure the stability of the gear hobbing machine during processing. It effectively reduces the processing error caused by mechanical vibration and improves the quality and reliability of processing.
Crane center pivot
The center pivot of the crane needs to bear large radial loads and axial loads at the same time. QIBR metric cross tapered roller bearings can effectively support these loads and can handle large overturning moments. In the dynamic operation of the crane, the high load-bearing capacity of the cross tapered roller bearing ensures the stability and reliability of the center pivot.
