XR

XR

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

XR

QIBR

Model Selection

Filters

NO. Product Product Number Overall height (H) Outer diameter (Do) Height of outer ring (Ho) Inner diameter (di) Gear Type Height of inner ring (Hi)
1 Q16318001/ Q16318001 1.417in 11.811in 1.181in 5.512in No Gear 1.181in
2 Q16319001/ Q16319001 2.165in 15.886in 1.772in 9.055in No Gear 1.850in
3 Q16320001/ Q16320001 3.031in 27.362in 2.520in 18.779in No Gear 2.244in
4 Q16321001/ Q16321001 2.953in 35.312in 2.863in 26.625in No Gear 2.863in
5 Q16322001/ Q16322001 4.250in 46.250in 3.880in 34.250in No Gear 3.880in
6 Q16323001/ Q16323001 3.820in 56.380in 3.470in 46.770in No Gear 3.430in
7 Q16324001/ Q16324001 3.750in 85.000in 3.250in 74.000in No Gear 3.250in
8 Q16325001/ Q16325001 4.000in 95.000in 3.500in 82.000in No Gear 3.500in
9 Q16326001/ Q16326001 7.874in 131.890in 6.496in 112.205in No Gear 7.087in
10 Q16327001/ Q16327001 8.819in 158.661in 6.654in 140.945in No Gear 6.654in
11 Q16328001/ Q16328001 2.500in 26.700in 2.000in 18.667in Internal Gear 2.000in
12 Q16329001/ Q16329001 3.880in 36.000in 3.380in 24.160in Internal Gear 3.380in
13 Q16330001/ Q16330001 4.190in 41.500in 3.370in 30.320in Internal Gear 4.000in
14 Q16331001/ Q16331001 3.350in 41.970in 2.560in 30.828in Internal Gear 2.950in
15 Q16332001/ Q16332001 4.500in 54.740in 3.750in 44.400in Internal Gear 4.130in
16 Q16333001/ Q16333001 5.906in 78.819in 4.921in 62.913in Internal Gear 4.921in
17 Q16334001/ Q16334001 6.000in 114.000in 5.500in 95.000in Internal Gear 5.500in
18 Q16335001/ Q16335001 6.772in 121.496in 6.299in 97.717in Internal Gear 6.299in
19 Q16336001/ Q16336001 6.000in 142.000in 5.500in 123.200in Internal Gear 5.500in
20 Q16337001/ Q16337001 2.170in 16.000in 1.770in 9.190in External Gear 1.850in
21 Q16338001/ Q16338001 2.750in 23.333in 2.500in 13.750in External Gear 2.500in
22 Q16339001/ Q16339001 3.030in 27.362in 2.520in 18.780in External Gear 2.240in
23 Q16340001/ Q16340001 2.205in 33.627in 1.752in 26.535in External Gear 1.752in
24 Q16341001/ Q16341001 4.690in 36.333in 4.310in 24.500in External Gear 3.880in
25 Q16342001/ Q16342001 3.930in 45.050in 3.360in 34.180in External Gear 3.470in
26 Q16343001/ Q16343001 4.000in 51.040in 3.500in 40.000in External Gear 3.500in
27 Q16344001/ Q16344001 5.118in 63.150in 4.409in 47.480in External Gear 4.409in
28 Q16345001/ Q16345001 5.040in 70.510in 4.330in 53.540in External Gear 4.330in
29 Q16346001/ Q16346001 3.300in 85.866in 2.800in 75.250in External Gear 2.800in
30 Q16347001/ Q16347001 6.500in 100.667in 6.500in 84.000in External Gear 4.000in
31 Q16348001/ Q16348001 6.142in 159.843in 5.748in 141.732in External Gear 5.748in
32 Q16393001/ Q16393001 7.047in 209.843in 6.417in 188.583in External Gear 6.024in
