70. 72. 718. 719 SERIES

Image may differ from product. See technical specification for details.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Pairing method

DB, DF, DT, DBD, DBB, SU

70. 72. 718. 719 SERIES

Filters

NO. Product Product Number Basic dynamic load rating Basic static load rating Inner diameter (d) Mass Outer diameter (D) Width (B)
5101 HCB71834C/ HCB71834C 47.50 KN 61.00 KN 170 mm 1.6 kg 215 mm 22 mm
5102 HCB71834-C-P2-DB/ HCB71834-C-P2-DB 47.50 KN 61.00 KN 170 mm 1.6 kg 215 mm 22 mm
5103 HCB71834E/ HCB71834E 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
5104 HCB71834-E-P2-DT/ HCB71834-E-P2-DT 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
5105 B71934C/ B71934C 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
5106 B71934-C-P2-U/ B71934-C-P2-U 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
5107 B71934E/ B71934E 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
5108 B71934-E-P2-DU/ B71934-E-P2-DU 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
5109 HCB71934C/ HCB71934C 88.00 KN 114.00 KN 170 mm 2.4 kg 230 mm 28 mm
5110 HCB71934-C-P2-DB/ HCB71934-C-P2-DB 88.00 KN 114.00 KN 170 mm 2.4 kg 230 mm 28 mm
5111 HCB71934E/ HCB71934E 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
5112 HCB71934-E-P2-DT/ HCB71934-E-P2-DT 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
5113 B7034C/ B7034C 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
5114 B7034-C-P2-U/ B7034-C-P2-U 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
5115 B7034E/ B7034E 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
5116 B7034-E-P2-DU/ B7034-E-P2-DU 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
5117 B7234C/ B7234C 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
5118 B7234-C-P2-U/ B7234-C-P2-U 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
5119 B7234E/ B7234E 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
5120 B7234-E-P2-DU/ B7234-E-P2-DU 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
5121 B71836C/ B71836C 71.00 KN 93.00 KN 180 mm 1.7 kg 225 mm 22 mm
5122 B71836-C-P2-U/ B71836-C-P2-U 71.00 KN 93.00 KN 180 mm 1.7 kg 225 mm 22 mm
5123 B71836E/ B71836E 67.00 KN 86.50 KN 180 mm 1.7 kg 225 mm 22 mm
5124 B71836-E-P2-DU/ B71836-E-P2-DU 67.00 KN 86.50 KN 180 mm 1.7 kg 225 mm 22 mm
5125 HCB71836C/ HCB71836C 49.00 KN 65.50 KN 180 mm 1.7 kg 225 mm 22 mm
5126 HCB71836-C-P2-DB/ HCB71836-C-P2-DB 49.00 KN 65.50 KN 180 mm 1.7 kg 225 mm 22 mm
5127 HCB71836E/ HCB71836E 45.50 KN 60.00 KN 180 mm 1.7 kg 225 mm 22 mm
5128 HCB71836-E-P2-DT/ HCB71836-E-P2-DT 45.50 KN 60.00 KN 180 mm 1.7 kg 225 mm 22 mm
5129 B71936C/ B71936C 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
5130 B71936-C-P2-U/ B71936-C-P2-U 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
5131 B71936E/ B71936E 156.00 KN 193.00 KN 180 mm 4.2 kg 250 mm 33 mm
5132 B71936-E-P2-DU/ B71936-E-P2-DU 156.00 KN 193.00 KN 180 mm 4.2 kg 250 mm 33 mm
5133 HCB71936C/ HCB71936C 114.00 KN 143.00 KN 180 mm 3.5 kg 250 mm 33 mm
5134 HCB71936-C-P2-DB/ HCB71936-C-P2-DB 114.00 KN 143.00 KN 180 mm 3.5 kg 250 mm 33 mm
5135 HCB71936E/ HCB71936E 106.00 KN 134.00 KN 180 mm 3.5 kg 250 mm 33 mm
5136 HCB71936-E-P2-DT/ HCB71936-E-P2-DT 106.00 KN 134.00 KN 180 mm 3.5 kg 250 mm 33 mm
5137 B7036C/ B7036C 245.00 KN 285.00 KN 180 mm 8.9 kg 280 mm 46 mm
5138 B7036-C-P2-U/ B7036-C-P2-U 245.00 KN 285.00 KN 180 mm 8.9 kg 280 mm 46 mm
5139 B7036E/ B7036E 232.00 KN 275.00 KN 180 mm 8.9 kg 280 mm 46 mm
5140 B7036-E-P2-DU/ B7036-E-P2-DU 232.00 KN 275.00 KN 180 mm 8.9 kg 280 mm 46 mm
5141 B7236C/ B7236C 305.00 KN 390.00 KN 180 mm 16.8 kg 320 mm 52 mm
5142 B7236-C-P2-U/ B7236-C-P2-U 305.00 KN 390.00 KN 180 mm 16.8 kg 320 mm 52 mm
5143 B7236E/ B7236E 290.00 KN 365.00 KN 180 mm 16.8 kg 320 mm 52 mm
5144 B7236-E-P2-DU/ B7236-E-P2-DU 290.00 KN 365.00 KN 180 mm 16.8 kg 320 mm 52 mm
5145 B71838C/ B71838C 80.00 KN 108.00 KN 190 mm 2.2 kg 240 mm 24 mm
5146 B71838-C-P2-U/ B71838-C-P2-U 80.00 KN 108.00 KN 190 mm 2.2 kg 240 mm 24 mm
5147 B71838E/ B71838E 75.00 KN 100.00 KN 190 mm 2.2 kg 240 mm 24 mm
5148 B71838-E-P2-DU/ B71838-E-P2-DU 75.00 KN 100.00 KN 190 mm 2.2 kg 240 mm 24 mm
5149 HCB71838C/ HCB71838C 55.00 KN 75.00 KN 190 mm 2.2 kg 240 mm 24 mm
5150 HCB71838-C-P2-DB/ HCB71838-C-P2-DB 55.00 KN 75.00 KN 190 mm 2.2 kg 240 mm 24 mm
5151 HCB71838E/ HCB71838E 52.00 KN 69.50 KN 190 mm 2.2 kg 240 mm 24 mm
5152 HCB71838-E-P2-DT/ HCB71838-E-P2-DT 52.00 KN 69.50 KN 190 mm 2.2 kg 240 mm 24 mm
5153 B71938C/ B71938C 166.00 KN 212.00 KN 190 mm 4.4 kg 260 mm 33 mm
5154 B71938-C-P2-U/ B71938-C-P2-U 166.00 KN 212.00 KN 190 mm 4.4 kg 260 mm 33 mm
5155 B71938E/ B71938E 156.00 KN 200.00 KN 190 mm 4.4 kg 260 mm 33 mm
5156 B71938-E-P2-DU/ B71938-E-P2-DU 156.00 KN 200.00 KN 190 mm 4.4 kg 260 mm 33 mm
5157 HCB71938C/ HCB71938C 116.00 KN 150.00 KN 190 mm 3.6 kg 260 mm 33 mm
5158 HCB71938-C-P2-DB/ HCB71938-C-P2-DB 116.00 KN 150.00 KN 190 mm 3.6 kg 260 mm 33 mm
5159 HCB71938E/ HCB71938E 108.00 KN 140.00 KN 190 mm 3.6 kg 260 mm 33 mm
5160 HCB71938-E-P2-DT/ HCB71938-E-P2-DT 108.00 KN 140.00 KN 190 mm 3.6 kg 260 mm 33 mm
5161 B7038C/ B7038C 250.00 KN 305.00 KN 190 mm 9.3 kg 290 mm 46 mm
5162 B7038-C-P2-U/ B7038-C-P2-U 250.00 KN 305.00 KN 190 mm 9.3 kg 290 mm 46 mm
5163 B7038E/ B7038E 236.00 KN 290.00 KN 190 mm 9.3 kg 290 mm 46 mm
5164 B7038-E-P2-DU/ B7038-E-P2-DU 236.00 KN 290.00 KN 190 mm 9.3 kg 290 mm 46 mm
5165 B7238C/ B7238C 315.00 KN 415.00 KN 190 mm 20.3 kg 290 mm 46 mm
5166 B7238-C-P2-U/ B7238-C-P2-U 315.00 KN 415.00 KN 190 mm 20.3 kg 290 mm 46 mm
5167 B7238E/ B7238E 300.00 KN 390.00 KN 190 mm 20.3 kg 290 mm 46 mm
5168 B7238-E-P2-DU/ B7238-E-P2-DU 300.00 KN 390.00 KN 190 mm 20.3 kg 290 mm 46 mm
5169 B71840C/ B71840C 81.50 KN 114.00 KN 200 mm 2.3 kg 250 mm 24 mm
5170 B71840-C-P2-U/ B71840-C-P2-U 81.50 KN 114.00 KN 200 mm 2.3 kg 250 mm 24 mm
5171 B71840E/ B71840E 76.50 KN 106.00 KN 200 mm 2.3 kg 250 mm 24 mm
5172 B71840-E-P2-DU/ B71840-E-P2-DU 76.50 KN 106.00 KN 200 mm 2.3 kg 250 mm 24 mm
5173 HCB71840C/ HCB71840C 57.00 KN 78.00 KN 200 mm 2.3 kg 250 mm 24 mm
5174 HCB71840-C-P2-DB/ HCB71840-C-P2-DB 57.00 KN 78.00 KN 200 mm 2.3 kg 250 mm 24 mm
5175 HCB71840E/ HCB71840E 53.00 KN 73.50 KN 200 mm 2.3 kg 250 mm 24 mm
5176 HCB71840-E-P2-DT/ HCB71840-E-P2-DT 53.00 KN 73.50 KN 200 mm 2.3 kg 250 mm 24 mm
5177 B71940C/ B71940C 204.00 KN 255.00 KN 200 mm 6.1 kg 280 mm 38 mm
5178 B71940-C-P2-U/ B71940-C-P2-U 204.00 KN 255.00 KN 200 mm 6.1 kg 280 mm 38 mm
5179 B71940E/ B71940E 193.00 KN 240.00 KN 200 mm 6.1 kg 280 mm 38 mm
5180 B71940-E-P2-DU/ B71940-E-P2-DU 193.00 KN 240.00 KN 200 mm 6.1 kg 280 mm 38 mm
5181 HCB71940C/ HCB71940C 140.00 KN 176.00 KN 200 mm 5.1 kg 280 mm 38 mm
5182 HCB71940-C-P2-DB/ HCB71940-C-P2-DB 140.00 KN 176.00 KN 200 mm 5.1 kg 280 mm 38 mm
5183 HCB71940E/ HCB71940E 134.00 KN 166.00 KN 200 mm 5.1 kg 280 mm 38 mm
5184 HCB71940-E-P2-DT/ HCB71940-E-P2-DT 134.00 KN 166.00 KN 200 mm 5.1 kg 280 mm 38 mm
5185 B7040C/ B7040C 305.00 KN 390.00 KN 200 mm 12.0 kg 310 mm 51 mm
5186 B7040-C-P2-U/ B7040-C-P2-U 305.00 KN 390.00 KN 200 mm 12.0 kg 310 mm 51 mm
5187 B7040E/ B7040E 290.00 KN 365.00 KN 200 mm 12.0 kg 310 mm 51 mm
5188 B7040-E-P2-DU/ B7040-E-P2-DU 290.00 KN 365.00 KN 200 mm 12.0 kg 310 mm 51 mm
5189 B7240C/ B7240C 325.00 KN 440.00 KN 200 mm 24.40 kg 360 mm 58 mm
5190 B7240-C-P2-U/ B7240-C-P2-U 325.00 KN 440.00 KN 200 mm 24.40 kg 360 mm 58 mm
5191 B7240E/ B7240E 310.00 KN 415.00 KN 200 mm 24.40 kg 360 mm 58 mm
5192 B7240-E-P2-DU/ B7240-E-P2-DU 310.00 KN 415.00 KN 200 mm 24.40 kg 360 mm 58 mm
5193 B71844C/ B71844C 83.00 KN 118.00 KN 220 mm 2.50 kg 270 mm 24 mm
5194 B71844-C-P2-U/ B71844-C-P2-U 83.00 KN 118.00 KN 220 mm 2.50 kg 270 mm 24 mm
5195 B71844E/ B71844E 78.00 KN 110.00 KN 220 mm 2.50 kg 270 mm 24 mm
5196 B71844-E-P2-DU/ B71844-E-P2-DU 78.00 KN 110.00 KN 220 mm 2.50 kg 270 mm 24 mm
5197 HCB71844C/ HCB71844C 57.00 KN 83.00 KN 220 mm 2.50 kg 270 mm 24 mm
5198 HCB71844-C-P2-DB/ HCB71844-C-P2-DB 57.00 KN 83.00 KN 220 mm 2.50 kg 270 mm 24 mm
5199 HCB71844E/ HCB71844E 54.00 KN 76.50 KN 220 mm 2.50 kg 270 mm 24 mm
5200 HCB71844-E-P2-DT/ HCB71844-E-P2-DT 54.00 KN 76.50 KN 220 mm 2.50 kg 270 mm 24 mm
