70. 72. 718. 719 SERIES

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Pairing method

DB, DF, DT, DBD, DBB, SU

70. 72. 718. 719 SERIES

Filters

NO. Product Product Number Inner diameter (d) Outer diameter (D) Width (B) Basic dynamic load rating Basic static load rating Mass
9001 HCB71801-C-P2-DB/ HCB71801-C-P2-DB 12 mm 21 mm 5 mm 1.43 KN 0.83 KN 0.01 kg
9002 HCB71801-CDLR-TX-P2/ HCB71801-CDLR-TX-P2 12 mm 21 mm 5 mm 1.43 KN 0.83 KN 0.01 kg
9003 HCB71801C/ HCB71801C 12 mm 21 mm 5 mm 1.43 KN 0.83 KN 0.01 kg
9004 HCB71801-E-P2-DT/ HCB71801-E-P2-DT 12 mm 21 mm 5 mm 1.34 KN 0.78 KN 0.01 kg
9005 HCB71801-EDLR-TX-P2/ HCB71801-EDLR-TX-P2 12 mm 21 mm 5 mm 1.34 KN 0.78 KN 0.01 kg
9006 HCB71801E/ HCB71801E 12 mm 21 mm 5 mm 1.34 KN 0.78 KN 0.01 kg
9007 B71901-C-P2-DT-H/ B71901-C-P2-DT-H 12 mm 24 mm 6 mm 3.35 KN 1.86 KN 0.01 kg
9008 B71901-C-P2-U/ B71901-C-P2-U 12 mm 24 mm 6 mm 3.35 KN 1.86 KN 0.01 kg
9009 B71901C/ B71901C 12 mm 24 mm 6 mm 3.35 KN 1.86 KN 0.01 kg
9010 71901 71901 ACE/P2 12 mm 24 mm 6 mm 2.03 KN 0.865 KN 0.01 kg
9011 71901 71901 ACE/P4A 12 mm 24 mm 6 mm 2.03 KN 0.865 KN 0.01 kg
9012 B71901-E-P2-DU/ B71901-E-P2-DU 12 mm 24 mm 6 mm 3.20 KN 1.76 KN 0.01 kg
9013 B71901E/ B71901E 12 mm 24 mm 6 mm 3.20 KN 1.76 KN 0.01 kg
9014 S71901 S71901 ACE/P4A 12 mm 24 mm 6 mm 2.03 KN 0.865 KN 0.01 kg
9015 HCB71901-C-P2-DB/ HCB71901-C-P2-DB 12 mm 24 mm 6 mm 2.32 KN 1.29 KN 0.01 kg
9016 HCB71901-CDLR-TX-P2/ HCB71901-CDLR-TX-P2 12 mm 24 mm 6 mm 2.32 KN 1.29 KN 0.01 kg
9017 HCB71901C/ HCB71901C 12 mm 24 mm 6 mm 2.32 KN 1.29 KN 0.01 kg
9018 XCB71901-CDLR-TX-P2/ XCB71901-CDLR-TX-P2 12 mm 24 mm 6 mm 2.32 KN 1.29 KN 0.01 kg
9019 XCB71901-EDLR-TX-P2/ XCB71901-EDLR-TX-P2 12 mm 24 mm 6 mm 2.32 KN 1.29 KN 0.01 kg
9020 HCB71901-E-P2-DT/ HCB71901-E-P2-DT 12 mm 24 mm 6 mm 2.20 KN 1.22 KN 0.01 kg
9021 HCB71901-EDLR-TX-P2/ HCB71901-EDLR-TX-P2 12 mm 24 mm 6 mm 2.20 KN 1.22 KN 0.01 kg
9022 HCB71901E/ HCB71901E 12 mm 24 mm 6 mm 2.20 KN 1.22 KN 0.01 kg
9023 XCB71901-C-P2-DF/ XCB71901-C-P2-DF 12 mm 24 mm 6 mm 5.20 KN 1.29 KN 0.01 kg
9024 XCB71901C/ XCB71901C 12 mm 24 mm 6 mm 5.20 KN 1.29 KN 0.01 kg
9025 XCB71901-E-P2-TBT/ XCB71901-E-P2-TBT 12 mm 24 mm 6 mm 5.00 KN 1.22 KN 0.01 kg
9026 XCB71901E/ XCB71901E 12 mm 24 mm 6 mm 5.00 KN 1.22 KN 0.01 kg
9027 HC71901-EDLR-TX-P2/ HC71901-EDLR-TX-P2 12 mm 24 mm 6 mm 2.04 KN 1.20 KN 0.01 kg
9028 HS71901 HS71901 AC/HQ1 12 mm 24 mm 6 mm 1.9 KN 1.1 KN 0.01 kg
9029 HS71901 HS71901 C/HQ1 12 mm 24 mm 6 mm 2.00 KN 1.10 KN 0.01 kg
9030 HS71901-C-P2-DT/ HS71901-C-P2-DT 12 mm 24 mm 6 mm 2.04 KN 1.20 KN 0.01 kg
9031 HS71901-C-P2-QBC/ HS71901-C-P2-QBC 12 mm 24 mm 6 mm 2.04 KN 1.20 KN 0.01 kg
9032 HS71901-CDLR-TX-P2/ HS71901-CDLR-TX-P2 12 mm 24 mm 6 mm 2.04 KN 1.20 KN 0.01 kg
9033 HS71901-EDLR-TX-P2/ HS71901-EDLR-TX-P2 12 mm 24 mm 6 mm 2.04 KN 1.20 KN 0.01 kg
9034 HS71901AC/ HS71901AC 12 mm 24 mm 6 mm 1.9 KN 1.1 KN 0.01 kg
9035 HS71901C/ HS71901C 12 mm 24 mm 6 mm 2.04 KN 1.20 KN 0.01 kg
9036 HS71901E/ HS71901E 12 mm 24 mm 6 mm 1.93 KN 1.14 KN 0.01 kg
9037 HC71901C/ HC71901C 12 mm 24 mm 6 mm 1.40 KN 0.83 KN 0.01 kg
9038 HC71901E/ HC71901E 12 mm 24 mm 6 mm 1.34 KN 0.80 KN 0.01 kg
9039 XC71901C/ XC71901C 12 mm 24 mm 6 mm 3.15 KN 0.83 KN 0.01 kg
9040 XC71901E/ XC71901E 12 mm 24 mm 6 mm 3.00 KN 0.80 KN 0.01 kg
9041 B7001-C-P2-DT-H/ B7001-C-P2-DT-H 12 mm 28 mm 8 mm 4.75 KN 2.60 KN 0.02 kg
9042 B7001C/ B7001C 12 mm 28 mm 8 mm 4.75 KN 2.60 KN 0.02 kg
9043 7001 7001 ACE/P2 12 mm 28 mm 8 mm 3.07 KN 1.27 KN 0.021 kg
9044 7001 7001 ACE/P4A 12 mm 28 mm 8 mm 3.07 KN 1.27 KN 0.021 kg
9045 B7001-E-P2-DU/ B7001-E-P2-DU 12 mm 28 mm 8 mm 4.55 KN 2.50 KN 0.02 kg
9046 B7001E/ B7001E 12 mm 28 mm 8 mm 4.55 KN 2.50 KN 0.02 kg
9047 S7001 S7001 ACE/P4A 12 mm 28 mm 8 mm 3.07 KN 1.27 KN 0.021 kg
9048 HCB7001-C-P2-DB/ HCB7001-C-P2-DB 12 mm 28 mm 8 mm 3.25 KN 1.80 KN 0.02 kg
9049 HCB7001-CDLR-TX-P2/ HCB7001-CDLR-TX-P2 12 mm 28 mm 8 mm 3.25 KN 1.80 KN 0.02 kg
9050 HCB7001C/ HCB7001C 12 mm 28 mm 8 mm 3.25 KN 1.80 KN 0.02 kg
9051 XCB7001-CDLR-TX-P2/ XCB7001-CDLR-TX-P2 12 mm 28 mm 8 mm 3.25 KN 1.80 KN 0.02 kg
9052 XCB7001-EDLR-TX-P2/ XCB7001-EDLR-TX-P2 12 mm 28 mm 8 mm 3.25 KN 1.80 KN 0.02 kg
9053 HCB7001-E-P2-DT/ HCB7001-E-P2-DT 12 mm 28 mm 8 mm 3.15 KN 1.73 KN 0.02 kg
9054 HCB7001-EDLR-TX-P2/ HCB7001-EDLR-TX-P2 12 mm 28 mm 8 mm 3.15 KN 1.73 KN 0.02 kg
9055 HCB7001E/ HCB7001E 12 mm 28 mm 8 mm 3.15 KN 1.73 KN 0.02 kg
9056 XCB7001-C-P2-DF/ XCB7001-C-P2-DF 12 mm 28 mm 8 mm 7.20 KN 1.73 KN 0.02 kg
9057 XCB7001C/ XCB7001C 12 mm 28 mm 8 mm 7.20 KN 1.73 KN 0.02 kg
9058 XCB7001-E-P2-TBT/ XCB7001-E-P2-TBT 12 mm 28 mm 8 mm 7.10 KN 1.73 KN 0.02 kg
9059 XCB7001E/ XCB7001E 12 mm 28 mm 8 mm 7.10 KN 1.73 KN 0.02 kg
9060 HC7001-EDLR-TX-P2/ HC7001-EDLR-TX-P2 12 mm 28 mm 8 mm 2.70 KN 1.63 KN 0.02 kg
9061 HS7001 HS7001 AC/HQ1 12 mm 28 mm 8 mm 2.50 KN 1.50 KN 0.02 kg
9062 HS7001 HS7001 C/HQ1 12 mm 28 mm 8 mm 2.70 KN 1.60 KN 0.02 kg
9063 HS7001-C-P2-DT/ HS7001-C-P2-DT 12 mm 28 mm 8 mm 2.70 KN 1.63 KN 0.02 kg
9064 HS7001-C-P2-QBC/ HS7001-C-P2-QBC 12 mm 28 mm 8 mm 2.70 KN 1.63 KN 0.02 kg
9065 HS7001-CDLR-TX-P2/ HS7001-CDLR-TX-P2 12 mm 28 mm 8 mm 2.70 KN 1.63 KN 0.02 kg
9066 HS7001-EDLR-TX-P2/ HS7001-EDLR-TX-P2 12 mm 28 mm 8 mm 2.70 KN 1.63 KN 0.02 kg
9067 HS7001AC/ HS7001AC 12 mm 28 mm 8 mm 2.50 KN 1.50 KN 0.02 kg
9068 HS7001C/ HS7001C 12 mm 28 mm 8 mm 2.70 KN 1.63 KN 0.02 kg
9069 HS7001E/ HS7001E 12 mm 28 mm 8 mm 2.55 KN 1.53 KN 0.02 kg
9070 HC7001C/ HC7001C 12 mm 28 mm 8 mm 1.86 KN 1.12 KN 0.02 kg
9071 HC7001E/ HC7001E 12 mm 28 mm 8 mm 1.76 KN 1.08 KN 0.02 kg
9072 XC7001C/ XC7001C 12 mm 28 mm 8 mm 4.15 KN 1.12 KN 0.02 kg
9073 XC7001E/ XC7001E 12 mm 28 mm 8 mm 3.90 KN 1.08 KN 0.02 kg
9074 B7201-C-P2-DT-H/ B7201-C-P2-DT-H 12 mm 32 mm 10 mm 7.65 KN 3.90 KN 0.04 kg
9075 B7201-C-P2-U/ B7201-C-P2-U 12 mm 32 mm 10 mm 7.65 KN 3.90 KN 0.04 kg
9076 B7201C/ B7201C 12 mm 32 mm 10 mm 7.65 KN 3.90 KN 0.04 kg
9077 B7201-E-P2-DU/ B7201-E-P2-DU 12 mm 32 mm 10 mm 7.35 KN 3.75 KN 0.04 kg
9078 B7201E/ B7201E 12 mm 32 mm 10 mm 7.35 KN 3.75 KN 0.04 kg
9079 HCB7201-C-P2-DB/ HCB7201-C-P2-DB 12 mm 32 mm 10 mm 5.30 KN 2.70 KN 0.03 kg
9080 HCB7201-CDLR-TX-P2/ HCB7201-CDLR-TX-P2 12 mm 32 mm 10 mm 5.30 KN 2.70 KN 0.03 kg
9081 HCB7201C/ HCB7201C 12 mm 32 mm 10 mm 5.30 KN 2.70 KN 0.03 kg
9082 HCB7201-E-P2-DT/ HCB7201-E-P2-DT 12 mm 32 mm 10 mm 5.10 KN 2.60 KN 0.03 kg
9083 HCB7201-EDLR-TX-P2/ HCB7201-EDLR-TX-P2 12 mm 32 mm 10 mm 5.10 KN 2.60 KN 0.03 kg
9084 HCB7201E/ HCB7201E 12 mm 32 mm 10 mm 5.10 KN 2.60 KN 0.03 kg
9085 B71802-C-P2-DT-H/ B71802-C-P2-DT-H 15 mm 24 mm 5 mm 2.28 KN 1.50 KN 0.01 kg
9086 B71802-C-P2-U/ B71802-C-P2-U 15 mm 24 mm 5 mm 2.28 KN 1.50 KN 0.01 kg
9087 B71802C/ B71802C 15 mm 24 mm 5 mm 2.28 KN 1.50 KN 0.01 kg
9088 B71802-E-P2-DU/ B71802-E-P2-DU 15 mm 24 mm 5 mm 2.16 KN 1.40 KN 0.01 kg
9089 B71802E/ B71802E 15 mm 24 mm 5 mm 2.16 KN 1.40 KN 0.01 kg
9090 HCB71802-C-P2-DB/ HCB71802-C-P2-DB 15 mm 24 mm 5 mm 1.60 KN 1.04 KN 0.01 kg
9091 HCB71802-CDLR-TX-P2/ HCB71802-CDLR-TX-P2 15 mm 24 mm 5 mm 1.60 KN 1.04 KN 0.01 kg
9092 HCB71802C/ HCB71802C 15 mm 24 mm 5 mm 1.60 KN 1.04 KN 0.01 kg
9093 XCB71802-CDLR-TX-P2/ XCB71802-CDLR-TX-P2 15 mm 24 mm 5 mm 1.60 KN 1.04 KN 0.01 kg
9094 HCB71802-E-P2-DT/ HCB71802-E-P2-DT 15 mm 24 mm 5 mm 1.50 KN 0.98 KN 0.01 kg
9095 HCB71802-EDLR-TX-P2/ HCB71802-EDLR-TX-P2 15 mm 24 mm 5 mm 1.50 KN 0.98 KN 0.01 kg
9096 HCB71802E/ HCB71802E 15 mm 24 mm 5 mm 1.50 KN 0.98 KN 0.01 kg
9097 B71902-C-P2-U/ B71902-C-P2-U 15 mm 28 mm 7 mm 5.00 KN 2.90 KN 0.02 kg
9098 B71902C/ B71902C 15 mm 28 mm 7 mm 5.00 KN 2.90 KN 0.02 kg
9099 B71902-E-P2-DU/ B71902-E-P2-DU 15 mm 28 mm 7 mm 4.80 KN 2.75 KN 0.02 kg
9100 B71902E/ B71902E 15 mm 28 mm 7 mm 4.80 KN 2.75 KN 0.02 kg
