HS

HS

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

HS

QIBR

Model Selection

Filters

NO. Product Product Number Inner diameter (Di) Outer diameter (Do) Weight (G APPROX) External bolt circle diameter (Lo) Number of bolt holes at outer ring (no) Gear Type
1 QHS6-16P1Z/ QHS6-16P1Z 12.000in 20.400in 103lbs 19.000in 8 No Gear
2 QHS6-21P1Z/ QHS6-21P1Z 17.000in 25.500in 137lbs 24.000in 12 No Gear
3 QHS6-25P1Z/ QHS6-25P1Z 21.000in 29.500in 162lbs 28.000in 15 No Gear
4 QHS6-29P1Z/ QHS6-29P1Z 25.000in 33.400in 186lbs 32.000in 15 No Gear
5 QHS6-33P1Z/ QHS6-33P1Z 28.830in 37.400in 216lbs 35.750in 18 No Gear
6 QHS6-37P1Z/ QHS6-37P1Z 32.830in 41.250in 233lbs 39.750in 18 No Gear
7 QHS6-43P1Z/ QHS6-43P1Z 38.750in 47.180in 269lbs 45.620in 20 No Gear
8 QHS6-16N1Z/ QHS6-16N1Z 12.850in 20.400in 92lbs 19.000in 8 Internal Gear
9 QHS6-21N1Z/ QHS6-21N1Z 17.600in 25.500in 117lbs 24.000in 12 Internal Gear
10 QHS6-25N1Z/ QHS6-25N1Z 21.600in 29.500in 148lbs 28.000in 15 Internal Gear
11 QHS6-29N1Z/ QHS6-29N1Z 25.600in 33.400in 171lbs 32.000in 15 Internal Gear
12 QHS6-33N1Z/ QHS6-33N1Z 29.130in 37.400in 205lbs 35.750in 18 Internal Gear
13 QHS6-37N1Z/ QHS6-37N1Z 33.133in 41.250in 226lbs 39.750in 18 Internal Gear
14 QHS6-43N1Z/ QHS6-43N1Z 39.130in 47.180in 253lbs 45.620in 20 Internal Gear
15 QHS6-16E1Z/ QHS6-16E1Z 12.000in 19.900in 85lbs 18.000in 14 External Gear
16 QHS6-21E1Z/ QHS6-21E1Z 17.000in 25.150in 108lbs 23.250in 18 External Gear
17 QHS6-25E1Z/ QHS6-25E1Z 21.000in 29.150in 137lbs 27.250in 20 External Gear
18 QHS6-29E1Z/ QHS6-29E1Z 25.000in 32.900in 158lbs 31.000in 24 External Gear
19 QHS6-33E1Z/ QHS6-33E1Z 28.830in 37.200in 188lbs 35.000in 28 External Gear
20 QHS6-37E1Z/ QHS6-37E1Z 32.830in 41.200in 207lbs 38.880in 28 External Gear
21 QHS6-43E1Z/ QHS6-43E1Z 38.750in 46.870in 237lbs 44.630in 32 External Gear
