HT

HT

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

HT

QIBR

Model Selection

Filters

NO. Product Product Number Outer diameter (Do) External bolt circle diameter (Lo) Number of bolt holes at outer ring (no) Internal bolt circle diameter (Li) Inner diameter (di) Gear Type
1 QHT10-30P1Z/ QHT10-30P1Z 36.000in 33.250in 24 26.750in 24.000in No Gear
2 QHT10-36P1Z/ QHT10-36P1Z 42.000in 39.250in 28 32.750in 30.000in No Gear
3 QHT10-42P1Z/ QHT10-42P1Z 48.000in 45.250in 32 38.750in 36.000in No Gear
4 QHT10-48P1Z/ QHT10-48P1Z 54.000in 51.250in 36 44.750in 42.000in No Gear
5 QHT10-54P1Z/ QHT10-54P1Z 60.000in 57.250in 40 50.750in 48.000in No Gear
6 QHT10-60P1Z/ QHT10-60P1Z 66.000in 63.250in 44 56.750in 54.000in No Gear
7 QHT10-30N1Z/ QHT10-30N1Z 36.000in 33.250in 24 27.250in 24.160in Internal Gear
8 QHT10-36N1Z/ QHT10-36N1Z 42.000in 39.250in 28 33.250in 30.160in Internal Gear
9 QHT10-42N1Z/ QHT10-42N1Z 48.000in 45.250in 32 39.250in 36.160in Internal Gear
10 QHT10-48N1Z/ QHT10-48N1Z 54.000in 51.250in 36 45.250in 42.160in Internal Gear
11 QHT10-54N1Z/ QHT10-54N1Z 60.000in 57.250in 40 51.250in 48.160in Internal Gear
12 QHT10-60N1Z/ QHT10-60N1Z 66.000in 63.250in 44 57.250in 54.160in Internal Gear
13 QHT10-30E1Z/ QHT10-30E1Z 35.840in 32.750in 24 26.750in 24.000in External Gear
14 QHT10-36E1Z/ QHT10-36E1Z 41.840in 38.750in 28 32.750in 30.000in External Gear
15 QHT10-42E1Z/ QHT10-42E1Z 47.840in 44.750in 32 38.750in 36.000in External Gear
16 QHT10-48E1Z/ QHT10-48E1Z 53.840in 50.750in 36 44.750in 42.000in External Gear
17 QHT10-54E1Z/ QHT10-54E1Z 59.840in 56.750in 40 50.750in 48.000in External Gear
18 QHT10-60E1Z/ QHT10-60E1Z 65.840in 62.750in 44 56.750in 54.000in External Gear
