KD600-type 621

KD600-type 621

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

KD600-type 621

QIBR

Model Selection

Filters

NO. Product Product Number Outer Diameter (Da) Inner diameter (Di) Overall height (H) External bolt circle diameter (La) Internal bolt circle diameter (Li) Gear Type
1 060.20.0414.500.01.1503/ 060.20.0414.500.01.1503 486mm 342mm 56mm 460mm 368mm No Gear
2 060.20.0544.500.01.1503/ 060.20.0544.500.01.1503 616mm 472mm 56mm 590mm 498mm No Gear
3 060.20.0644.500.01.1503/ 060.20.0644.500.01.1503 716mm 572mm 56mm 690mm 598mm No Gear
4 060.20.0744.500.01.1503/ 060.20.0744.500.01.1503 816mm 672mm 56mm 790mm 698mm No Gear
5 060.20.0844.500.01.1503/ 060.20.0844.500.01.1503 916mm 772mm 56mm 890mm 798mm No Gear
6 060.20.0944.500.01.1503/ 060.20.0944.500.01.1503 1016mm 872mm 56mm 990mm 898mm No Gear
7 060.20.1094.500.01.1503/ 060.20.1094.500.01.1503 1166mm 1022mm 56mm 1140mm 1048mm No Gear
8 061.20.0414.500.01.1503/ 061.20.0414.500.01.1503 504mm 342mm 56mm 455mm 368mm External Gear
9 061.20.0544.500.01.1503/ 061.20.0544.500.01.1503 640.8mm 472mm 56mm 585mm 498mm External Gear
11 061.20.0744.500.01.1503/ 061.20.0744.500.01.1503 838.8mm 672mm 56mm 785mm 698mm External Gear
12 061.20.0844.500.01.1503/ 061.20.0844.500.01.1503 950.4mm 772mm 56mm 885mm 798mm External Gear
13 061.20.0944.500.01.1503/ 061.20.0944.500.01.1503 1046.4mm 872mm 56mm 985mm 898mm External Gear
14 061.20.1094.500.01.1503/ 061.20.1094.500.01.1503 1198.4mm 1022mm 56mm 1135mm 1048mm External Gear
15 062.20.0414.500.01.1503/ 062.20.0414.500.01.1503 486mm 326.5mm 56mm 460mm 375mm Internal Gear
16 062.20.0544.500.01.1503/ 062.20.0544.500.01.1503 616mm 445.2mm 56mm 590mm 505mm Internal Gear
17 062.20.0644.500.01.1503/ 062.20.0644.500.01.1503 716mm 547.2mm 56mm 690mm 605mm Internal Gear
18 062.20.0744.500.01.1503/ 062.20.0744.500.01.1503 816mm 649.2mm 56mm 790mm 705mm Internal Gear
19 062.20.0844.500.01.1503/ 062.20.0844.500.01.1503 916mm 737.6mm 56mm 890mm 805mm Internal Gear
20 062.20.0944.500.01.1503/ 062.20.0944.500.01.1503 1016mm 841.6mm 56mm 990mm 905mm Internal Gear
21 062.20.1094.500.01.1503/ 062.20.1094.500.01.1503 1166mm 985.6mm 56mm 1140mm 1055mm Internal Gear
22 060.20.0414.575.01.1403/ 060.20.0414.575.01.1403 484.5 -0.10mm 343.5 +0.09mm 56mm 460mm 368mm No Gear
23 060.20.0544.575.01.1403/ 060.20.0544.575.01.1403 614.5 -0.11mm 473.5 +0.10mm 56mm 590mm 498mm No Gear
24 060.20.0644.575.01.1403/ 060.20.0644.575.01.1403 714.5 -0.13mm 573.5 +0.11mm 56mm 690mm 598mm No Gear
25 060.20.0744.575.01.1403/ 060.20.0744.575.01.1403 814.5 -0.14mm 673.5 +0.13mm 56mm 790mm 698mm No Gear
26 060.20.0844.575.01.1403/ 060.20.0844.575.01.1403 914.5 -0.14mm 773.5 +0.13mm 56mm 890mm 798mm No Gear
27 060.20.0944.575.01.1403/ 060.20.0944.575.01.1403 1014.5 -0.17mm 873.5 +0.14mm 56mm 990mm 898mm No Gear
28 060.20.1094.575.01.1403/ 060.20.1094.575.01.1403 1164.5 -0.17mm 1023.5 +0.17mm 56mm 1140mm 1048mm No Gear
29 061.20.0414.575.01.1403/ 061.20.0414.575.01.1403 504mm 343.5 +0.09mm 56mm 455mm 368mm External Gear
30 061.20.0544.575.01.1403/ 061.20.0544.575.01.1403 640.8mm 473.5 +0.10mm 56mm 585mm 498mm External Gear
31 061.20.0644.575.01.1403/ 061.20.0644.575.01.1403 742.8mm 573.5 +0.11mm 56mm 685mm 598mm External Gear
32 061.20.0744.575.01.1403/ 061.20.0744.575.01.1403 838.8mm 673.5 +0.13mm 56mm 785mm 698mm External Gear
33 061.20.0844.575.01.1403/ 061.20.0844.575.01.1403 950.4mm 773.5 +0.13mm 56mm 885mm 798mm External Gear
34 061.20.0944.575.01.1403/ 061.20.0944.575.01.1403 1046.4mm 873.5 +0.14mm 56mm 985mm 898mm External Gear
35 061.20.1094.575.01.1403/ 061.20.1094.575.01.1403 1198.4mm 1023.5 +0.17mm 56mm 1135mm 1048mm External Gear
36 062.20.0414.575.01.1403/ 062.20.0414.575.01.1403 484.5 -0.10mm 326.5mm 56mm 460mm 375mm Internal Gear
37 062.20.0544.575.01.1403/ 062.20.0544.575.01.1403 614.5 -0.11mm 445.2mm 56mm 590mm 505mm Internal Gear
38 062.20.0644.575.01.1403/ 062.20.0644.575.01.1403 714.5 -0.13mm 547.2mm 56mm 690mm 605mm Internal Gear
39 062.20.0744.575.01.1403/ 062.20.0744.575.01.1403 814.5 -0.14mm 649.2mm 56mm 790mm 705mm Internal Gear
40 062.20.0844.575.01.1403/ 062.20.0844.575.01.1403 914.5 -0.14mm 737.6mm 56mm 890mm 805mm Internal Gear
41 062.20.0944.575.01.1403/ 062.20.0944.575.01.1403 1014.5 -0.17mm 841.6mm 56mm 990mm 905mm Internal Gear
42 062.20.1094.575.01.1403/ 062.20.1094.575.01.1403 1164.5 -0.17mm 985.6mm 56mm 1140mm 1055mm Internal Gear
