MT

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

QIBR Model Selection

Filters

Inner diameter (Di)

Overall height (H)

Outer diameter (Do)

Height of outer ring (Ho)

Weight (G APPROX)

Gear Type

NO.	Product Number	Inner diameter (Di)	Overall height (H)	Outer diameter (Do)	Height of outer ring (Ho)	Weight (G APPROX)	Gear Type
1	QMTO-050	1.968in	0.787in	4.331in	0.728in	2lbs	No Gear
2	QMTO-050T	1.968in	0.787in	4.331in	0.728in	2lbs	No Gear
3	QMTO-065	2.559in	0.866in	5.315in	0.787in	4lbs	No Gear
4	QMTO-065T	2.559in	0.866in	5.315in	0.787in	4lbs	No Gear
5	QMTO-122	4.803in	1.339in	8.898in	1.142in	13lbs	No Gear
6	QMTO-122T	4.803in	1.339in	8.898in	1.142in	13lbs	No Gear
7	QMTO-143	5.630in	1.339in	9.803in	1.142in	15lbs	No Gear
8	QMTO-143T	5.630in	1.339in	9.803in	1.142in	15lbs	No Gear
9	QMTO-145	5.709in	1.968in	11.811in	1.732in	37lbs	No Gear
10	QMTO-145T	5.709in	1.968in	11.811in	1.732in	37lbs	No Gear
11	QMTO-145X	5.709in	1.968in	12.286in	1.732in	41lbs	No Gear
12	QMTO-170	6.693in	1.811in	12.205in	1.614in	33lbs	No Gear
13	QMTO-170T	6.693in	1.811in	12.205in	1.614in	33lbs	No Gear
14	QMTO-210	8.268in	1.575in	14.370in	1.496in	38lbs	No Gear
15	QMTO-210T	8.268in	1.575in	14.370in	1.496in	38lbs	No Gear
16	QMTO-210X	8.268in	1.968in	14.686in	1.732in	48lbs	No Gear
17	QMTO-265	10.433in	1.968in	16.535in	1.732in	54lbs	No Gear
18	QMTO-265T	10.433in	1.968in	16.535in	1.732in	54lbs	No Gear
19	QMTO-265X	10.433in	1.968in	17.086in	1.732in	61lbs	External Gear
20	QMTO-324T	12.750in	2.062in	20.486in	2.022in	105lbs	No Gear
21	QMTO-324X	12.770in	2.375in	20.486in	2.063in	105lbs	No Gear
22	QMTE-145	5.709in	1.968in	12.286in	1.732in	38lbs	External Gear
23	QMTE-145T	5.709in	1.968in	12.286in	1.732in	38lbs	External Gear
24	QMTE-145X	5.709in	1.968in	12.286in	1.732in	38lbs	External Gear
25	QMTE-210	8.268in	1.575in	14.686in	1.496in	38lbs	External Gear
26	QMTE-210T	8.268in	1.575in	14.686in	1.496in	38lbs	External Gear
27	QMTE-210X	8.268in	1.968in	14.686in	1.732in	44lbs	External Gear
28	QMTE-265	10.433in	1.968in	17.086in	1.732in	57lbs	External Gear
29	QMTE-265T	10.433in	1.968in	17.086in	1.732in	57lbs	External Gear
30	QMTE-265X	10.433in	1.968in	17.086in	1.732in	57lbs	External Gear
31	QMTE-324T	12.750in	2.062in	20.486in	2.022in	98lbs	External Gear
32	QMTE-324X	12.770in	2.375in	20.486in	2.063in	99lbs	External Gear
33	QMTE-415	16.250in	2.375in	24.650in	2.063in	132lbs	External Gear
34	QMTE-415T	16.250in	2.375in	24.650in	2.063in	132lbs	External Gear
35	QMTE-470	18.500in	2.375in	26.900in	2.063in	147lbs	External Gear
36	QMTE-470T	18.500in	2.375in	26.900in	2.063in	147lbs	External Gear
37	QMTE-540	21.250in	2.375in	29.650in	2.063in	163lbs	External Gear
38	QMTE-540T	21.250in	2.375in	29.650in	2.063in	163lbs	External Gear
39	QMTE-590	23.125in	2.875in	33.534in	2.563in	283lbs	External Gear
40	QMTE-590T	23.125in	2.875in	33.534in	2.563in	283lbs	External Gear
41	QMTE-705	27.750in	2.875in	38.201in	2.563in	325lbs	External Gear
42	QMTE-705T	27.750in	2.875in	38.201in	2.563in	325lbs	External Gear
43	QMTE-730	28.750in	3.250in	41.85in	2.880in	491lbs	External Gear
44	QMTE-730T	28.750in	3.250in	41.85in	2.880in	491lbs	External Gear
45	QMTE-870	34.250in	4.250in	47.444in	3.875in	771lbs	External Gear
46	QMTE-870T	34.250in	4.250in	47.444in	3.875in	771lbs	External Gear
