Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

XT

QIBR

Model Selection

Filters

NO. Product Product Number Inner diameter (Di) Overall height (H) Outer diameter (Do) Height of outer ring (Ho) Weight (G APPROX) Gear Type
1 Q12740001/ Q12740001 16.250in 2.375in 24.650in 2.063in 145lbs No Gear
2 Q12750001/ Q12750001 18.500in 2.375in 26.900in 2.063in 155lbs No Gear
3 Q12770001/ Q12770001 21.250in 2.375in 29.650in 2.063in 180lbs No Gear
4 Q12775001/ Q12775001 23.125in 2.875in 33.534in 2.563in 305lbs No Gear
5 Q12780001/ Q12780001 27.750in 2.875in 38.201in 2.563in 350lbs No Gear
6 Q12785001/ Q12785001 28.750in 3.250in 41.850in 2.880in 530lbs No Gear
7 Q12790001/ Q12790001 34.250in 4.250in 47.444in 3.875in 835lbs No Gear
8 Q16289001/ Q16289001 52.325in 3.540in 61.250in 2.800in 585lbs No Gear
9 Q16389001/ Q16389001 69.094in 6.024in 87.992in 5.512in 3,330lbs No Gear
10 Q16290001/ Q16290001 113.000in 5.500in 129.000in 5.000in 3,950lbs No Gear
11 Q16291001/ Q16291001 162.000in 5.500in 178.000in 5.000in 5,350lbs No Gear
12 Q16292001/ Q16292001 9.714in 1.968in 16.625in 1.732in 65lbs Internal Gear
13 Q16293001/ Q16293001 12.750in 2.060in 20.486in 2.000in 105lbs Internal Gear
14 Q16294001/ Q16294001 16.850in 2.750in 25.750in 2.375in 180lbs Internal Gear
15 Q16295001/ Q16295001 19.600in 2.834in 28.937in 2.480in 225lbs Internal Gear
16 Q16296001/ Q16296001 24.921in 2.834in 34.252in 2.480in 270lbs Internal Gear
17 Q16390001/ Q16390001 30.560in 3.380in 40.880in 2.560in 375lbs Internal Gear
18 Q16374001/ Q16374001 36.400in 4.000in 48.250in 3.500in 660lbs Internal Gear
19 Q16297001/ Q16297001 41.280in 5.000in 54.375in 3.875in 1,090lbs Internal Gear
20 Q16298001/ Q16298001 47.760in 4.875in 62.250in 4.375in 1,370lbs Internal Gear
21 Q16299001/ Q16299001 57.000in 6.000in 72.500in 5.000in 1,900lbs Internal Gear
22 Q16300001/ Q16300001 62.267in 6.500in 81.750in 5.625in 3,080lbs Internal Gear
23 Q16301001/ Q16301001 85.360in 7.440in 102.500in 6.780in 3,750lbs Internal Gear
24 Q16302001/ Q16302001 93.600in 7.125in 117.000in 6.500in 6,200lbs Internal Gear
25 Q16303001/ Q16303001 135.039in 4.724in 148.425in 4.134in 3,000lbs Internal Gear
26 Q16304001/ Q16304001 151.700in 6.000in 168.000in 5.500in 5,500lbs Internal Gear
27 Q16305001/ Q16305001 4.813in 1.344in 9.500in 1.141in 15lbs External Gear
28 Q16306001/ Q16306001 12.438in 2.812in 21.286in 2.656in 140lbs External Gear
29 Q16307001/ Q16307001 19.000in 3.625in 30.457in 3.250in 330lbs External Gear
30 Q12440001/ Q12440001 29.500in 3.875in 39.400in 3.031in 390lbs External Gear
31 Q16308001/ Q16308001 37.750in 4.000in 50.640in 3.620in 770lbs External Gear
32 Q12288001/ Q12288001 42.000in 4.625in 54.300in 3.625in 770lbs External Gear
33 Q16309001/ Q16309001 41.370in 4.750in 56.240in 3.850in 1,133lbs External Gear
34 Q16310001/ Q16310001 47.125in 5.875in 61.300in 4.688in 1,420lbs External Gear
35 Q16311001/ Q16311001 54.500in 6.500in 75.000in 5.875in 2,865lbs External Gear
36 Q16312001/ Q16312001 66.750in 7.120in 85.067in 6.500in 3,410lbs External Gear
37 Q16313001/ Q16313001 78.400in 6.625in 98.800in 6.000in 4,000lbs External Gear
38 Q16314001/ Q16314001 118.110in 5.512in 134.331in 5.000in 3,600lbs External Gear
39 Q16315001/ Q16315001 146.850in 6.024in 170.079in 5.512in 8,030lbs External Gear
40 Q16316001/ Q16316001 173.622in 7.000in 196.850in 6.250in 10,100lbs External Gear
41 Q16317001/ Q16317001 197.244in 5.512in 218.268in 5.039in 8,700lbs External Gear
