KD 210-type 21

KD 210-type 21

Standards

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN/VDEh,DIN/VDEh

Inner Diameter

120mm-8000mm

Outer Diameter

280mm-8000mm

Weight

20kg-8000kg

Structures

Outer Ring, Inner Ring, Spacer, Rolling element, Seal

Brand

QIBR/OEM/Neutral

Package

Standard Export Package

Material

42CrMo, 50Mn, or Stainless Steel

Applications

Hoisting machinery, construction machinery, material handling machinery, mining machinery, metallurgical machinery, medical instruments,ships and warships, radar,wind turbine

KD 210-type 21

QIBR

Model Selection

Filters

NO. Product Product Number Outer Diameter (Da) Inner diameter (Di) Overall height (H) Weight Gear Type Ball track diameter (DL)
1 230.20.0400.013 230.20.0400.013 Typ 21/520.0 518mm 304mm 56mm 23.4kg No Gear 414mm
2 230.20.0500.013 230.20.0500.013 Typ 21/650.0 648mm 434mm 56mm 31kg No Gear 544mm
3 230.20.0600.013 230.20.0600.013 Typ 21/750.0 748mm 534mm 56mm 36.4kg No Gear 644mm
4 230.20.0700.013 230.20.0700.013 Typ 21/850.0 848mm 634mm 56mm 42.8kg No Gear 744mm
5 230.20.0800.013 230.20.0800.013 Typ 21/950.0 948mm 734mm 56mm 47.8kg No Gear 844mm
6 230.20.0900.013 230.20.0900.013 Typ 21/1050.0 1048mm 834mm 56mm 53.1kg No Gear 944mm
7 230.20.1000.013 230.20.1000.013 Typ 21/1200.0 1198mm 984mm 56mm 61.9kg No Gear 1094mm
8 231.20.0400.013 231.20.0400.013 Typ 21/520.1 504.4mm 304mm 56mm 29.3kg No Gear 414mm
9 231.20.0500.013 231.20.0500.013 Typ 21/650.1 640.8mm 434mm 56mm 39.5kg No Gear 544mm
10 231.20.0600.013 231.20.0600.013 Typ 21/750.1 742.8mm 534mm 56mm 47.6kg No Gear 644mm
11 231.20.0700.013 231.20.0700.013 Typ 21/850.1 838.8mm 634mm 56mm 53.5kg No Gear 744mm
12 231.20.0800.013 231.20.0800.013 Typ 21/950.1 950.4mm 734mm 56mm 65.1kg No Gear 844mm
13 231.20.0900.013 231.20.0900.013 Typ 21/1050.1 1046.4mm 834mm 56mm 69.6kg No Gear 944mm
14 231.20.1000.013 231.20.1000.013 Typ 21/1200.1 1198.4mm 984mm 56mm 83kg No Gear 1094mm
15 232.20.0400.013 232.20.0400.013 Typ 21/520.2 518mm 326.5mm 56mm 27.1kg No Gear 414mm
16 232.20.0500.013 232.20.0500.013 Typ 21/650.2 648mm 445.2mm 56mm 36.9kg No Gear 544mm
17 232.20.0600.013 232.20.0600.013 Typ 21/750.2 748mm 547.2mm 56mm 43.7kg No Gear 644mm
18 232.20.0700.013 232.20.0700.013 Typ 21/850.2 848mm 649.2mm 56mm 51.1kg No Gear 744mm
19 232.20.0800.013 232.20.0800.013 Typ 21/950.2 948mm 737.6mm 56mm 61.6kg No Gear 844mm
20 232.20.0900.013 232.20.0900.013 Typ 21/1050.2 1048mm 841.6mm 56mm 65.8kg No Gear 944mm
21 232.20.1000.013 232.20.1000.013 Typ 21/1200.2 1198mm 985.6mm 56mm 80.7kg No Gear 1094mm
22 230.20.0400.503 230.20.0400.503 Typ 21/520.0 518mm 304mm 56mm 23kg No Gear 414mm
23 230.20.0500.503 230.20.0500.503 Typ 21/650.0 648mm 434mm 56mm 30.4kg No Gear 544mm
24 230.20.0600.503 230.20.0600.503 Typ 21/750.0 748mm 534mm 56mm 35.8kg No Gear 644mm
25 230.20.0700.503 230.20.0700.503 Typ 21/850.0 848mm 634mm 56mm 42.2kg No Gear 744mm
26 230.20.0800.503 230.20.0800.503 Typ 21/950.0 948mm 734mm 56mm 47.1kg No Gear 844mm
27 230.20.0900.503 230.20.0900.503 Typ 21/1050.0 1048mm 834mm 56mm 52.3kg No Gear 944mm
28 230.20.1000.503 230.20.1000.503 Typ 21/1200.0 1198mm 984mm 56mm 61.1kg No Gear 1094mm
29 231.20.0400.503 231.20.0400.503 Typ 21/520.1 504.4mm 304mm 56mm 29.0kg No Gear 414mm
30 231.20.0500.503 231.20.0500.503 Typ 21/650.1 640.8mm 434mm 56mm 39.2kg No Gear 544mm
31 231.20.0600.503 231.20.0600.503 Typ 21/750.1 742.8mm 534mm 56mm 47.2kg No Gear 644mm
32 231.20.0700.503 231.20.0700.503 Typ 21/850.1 838.8mm 634mm 56mm 53.1kg No Gear 744mm
33 231.20.0800.503 231.20.0800.503 Typ 21/950.1 950.4mm 734mm 56mm 64.7kg No Gear 844mm
34 231.20.0900.503 231.20.0900.503 Typ 21/1050.1 1046.4mm 834mm 56mm 69.1kg No Gear 944mm
35 231.20.1000.503 231.20.1000.503 Typ 21/1200.1 1198.4mm 984mm 56mm 82.5kg No Gear 1094mm
36 232.20.0400.503 232.20.0400.503 Typ 21/520.2 518mm 326.5mm 56mm 26.9kg No Gear 414mm
37 232.20.0500.503 232.20.0500.503 Typ 21/650.2 648mm 445.2mm 56mm 36.7kg No Gear 544mm
38 232.20.0600.503 232.20.0600.503 Typ 21/750.2 748mm 547.2mm 56mm 43.4kg No Gear 644mm
39 232.20.0700.503 232.20.0700.503 Typ 21/850.2 848mm 649.2mm 56mm 50.8kg No Gear 744mm
40 232.20.0800.503 232.20.0800.503 Typ 21/950.2 948mm 737.6mm 56mm 61.3kg No Gear 844mm
41 232.20.0900.503 232.20.0900.503 Typ 21/1050.2 1048mm 841.6mm 56mm 65.4kg No Gear 944mm
42 232.20.1000.503 232.20.1000.503 Typ 21/1200.2 1198mm 985.6mm 56mm 80.3kg No Gear 1094mm
43 230.21.0475.013 230.21.0475.013 Typ 21/520.0 517 -0.11mm 305 +0.08mm 56mm 23.4kg No Gear 414mm
44 230.21.0575.013 230.21.0575.013 Typ 21/650.0 647 -0.13mm 435 +0.10mm 56mm 31kg No Gear 544mm
45 230.21.0675.013 230.21.0675.013 Typ 21/750.0 747 -0.13mm 535 +0.11mm 56mm 36.4kg No Gear 644mm
46 230.21.0775.013 230.21.0775.013 Typ 21/850.0 847 -0.14mm 635 +0.13mm 56mm 42.8kg No Gear 744mm
47 230.21.0875.013 230.21.0875.013 Typ 21/950.0 947 -0.14mm 735 +0.13mm 56mm 47.8kg No Gear 844mm
48 230.21.0975.013 230.21.0975.013 Typ 21/1050.0 1047 -0.17mm 835 +0.14mm 56mm 53.1kg No Gear 944mm
49 230.21.1075.013 230.21.1075.013 Typ 21/1200.0 1197 -0.17mm 985 +0.14mm 56mm 61.9kg No Gear 1094mm
50 231.21.0475.013 231.21.0475.013 Typ 21/520.1 504.8mm 305 +0.08mm 56mm 29.3kg No Gear 414mm
51 231.21.0575.013 231.21.0575.013 Typ 21/650.1 640.8mm 435 +0.10mm 56mm 39.5kg No Gear 544mm
52 231.21.0675.013 231.21.0675.013 Typ 21/750.1 742.8mm 535 +0.11mm 56mm 47.6kg No Gear 644mm
53 231.21.0775.013 231.21.0775.013 Typ 21/850.1 838.8mm 635 +0.13mm 56mm 53.5kg No Gear 744mm
54 231.21.0875.013 231.21.0875.013 Typ 21/950.1 950.4mm 735 +0.13mm 56mm 65.1kg No Gear 844mm
55 231.21.0975.013 231.21.0975.013 Typ 21/1050.1 1046.4mm 835 +0.14mm 56mm 69.6kg No Gear 944mm
56 231.21.1075.013 231.21.1075.013 Typ 21/1200.1 1198.4mm 985 +0.14mm 56mm 83.0kg No Gear 1094mm
57 232.21.0475.013 232.21.0475.013 Typ 21/520.2 517 -0.11mm 326.5mm 56mm 27.1kg No Gear 414mm
58 232.21.0575.013 232.21.0575.013 Typ 21/650.2 647 -0.13mm 445.2mm 56mm 36.9kg No Gear 544mm
59 232.21.0675.013 232.21.0675.013 Typ 21/750.2 747 -0.13mm 547.2mm 56mm 43.7kg No Gear 644mm
60 232.21.0775.013 232.21.0775.013 Typ 21/850.2 847 -0.14mm 649.2mm 56mm 51.1kg No Gear 744mm
61 232.21.0875.013 232.21.0875.013 Typ 21/950.2 947 -0.14mm 737.6mm 56mm 61.6kg No Gear 844mm
62 232.21.0975.013 232.21.0975.013 Typ 21/1050.2 1047 -0.17mm 841.6mm 56mm 65.8kg No Gear 944mm
63 232.21.1075.013 232.21.1075.013 Typ 21/1200.2 1197 -0.17mm 985.6mm 56mm 80.7kg No Gear 1094mm
64 280.30.0900.013 280.30.0900.013 Typ 110/1100.0 1100mm 805mm 90mm 131kg No Gear 955mm
65 280.30.1000.013 280.30.1000.013 Typ 110/1200.0 1200mm 905mm 90mm 145kg No Gear 1055mm
66 280.30.1100.013 280.30.1100.013 Typ 110/1300.0 1300mm 1005mm 90mm 159kg No Gear 1155mm
67 280.30.1200.013 280.30.1200.013 Typ 110/1400.0 1400mm 1105mm 90mm 172kg No Gear 1255mm
68 280.30.1300.013 280.30.1300.013 Typ 110/1500.0 1500mm 1205mm 90mm 186kg No Gear 1355mm
69 280.30.1400.013 280.30.1400.013 Typ 110/1600.0 1600mm 1305mm 90mm 200kg No Gear 1455mm
70 281.30.0900.013 281.30.0900.013 Typ 110/1100.1 1096.2mm 805mm 90mm 165kg No Gear 955mm
71 281.30.1000.013 281.30.1000.013 Typ 110/1200.1 1198.2mm 905mm 90mm 183kg No Gear 1055mm
72 281.30.1100.013 281.30.1100.013 Typ 110/1300.1 1298.2mm 1005mm 90mm 200kg No Gear 1155mm
73 281.30.1200.013 281.30.1200.013 Typ 110/1400.1 1398.2mm 1105mm 90mm 216kg No Gear 1255mm
74 281.30.1300.013 281.30.1300.013 Typ 110/1500.1 1498.2mm 1205mm 90mm 234kg No Gear 1355mm
75 281.30.1400.013 281.30.1400.013 Typ 110/1600.1 1598.2mm 1305mm 90mm 250kg No Gear 1455mm
76 282.30.0900.013 282.30.0900.013 Typ 110/1100.2 1100mm 812mm 90mm 159kg No Gear 955mm
77 282.30.1000.013 282.30.1000.013 Typ 110/1200.2 1200mm 912mm 90mm 176kg No Gear 1055mm
78 282.30.1100.013 282.30.1100.013 Typ 110/1300.2 1300mm 1012mm 90mm 192kg No Gear 1155mm
79 282.30.1200.013 282.30.1200.013 Typ 110/1400.2 1400mm 1112mm 90mm 208kg No Gear 1255mm
80 282.30.1300.013 282.30.1300.013 Typ 110/1500.2 1500mm 1212mm 90mm 226kg No Gear 1355mm
81 282.30.1400.013 282.30.1400.013 Typ 110/1600.2 1600mm 1310mm 90mm 243kg No Gear 1455mm
82 280.30.0975.013 280.30.0975.013 Typ 110/1100.0 1098 -0.17mm 807 +0.14mm 90mm 131kg No Gear 955mm
83 280.30.1075.013 280.30.1075.013 Typ 110/1200.0 1198 -0.17mm 907 +0.14mm 90mm 145kg No Gear 1055mm
84 280.30.1175.013 280.30.1175.013 Typ 110/1300.0 1298 -0.20mm 1007 +0.17mm 90mm 159kg No Gear 1155mm
85 280.30.1275.013 280.30.1275.013 Typ 110/1400.0 1398 -0.20mm 1107 +0.17mm 90mm 172kg No Gear 1255mm
86 280.30.1375.013 280.30.1375.013 Typ 110/1500.0 1498 -0.20mm 1207 +0.17mm 90mm 186kg No Gear 1355mm
87 280.30.1475.013 280.30.1475.013 Typ 110/1600.0 1598 -0.20mm 1307 +0.20mm 90mm 200kg No Gear 1455mm
88 281.30.0975.013 281.30.0975.013 Typ 110/1100.1 1096.2mm 807 +0.14mm 90mm 165kg No Gear 955mm
89 281.30.1075.013 281.30.1075.013 Typ 110/1200.1 1198mm 907 +0.14mm 90mm 183kg No Gear 1055mm
90 281.30.1175.013 281.30.1175.013 Typ 110/1300.1 1298mm 1007 +0.17mm 90mm 200kg No Gear 1155mm
91 281.30.1275.013 281.30.1275.013 Typ 110/1400.1 1398mm 1107 +0.17mm 90mm 216kg No Gear 1255mm
92 281.30.1375.013 281.30.1375.013 Typ 110/1500.1 1498mm 1207 +0.17mm 90mm 234kg No Gear 1355mm
93 281.30.1475.013 281.30.1475.013 Typ 110/1600.1 1598mm 1307 +0.20mm 90mm 250kg No Gear 1455mm
94 282.30.0975.013 282.30.0975.013 Typ 110/1100.2 1098 -0.17mm 812mm 90mm 159kg No Gear 955mm
95 282.30.1075.013 282.30.1075.013 Typ 110/1200.2 1198 -0.17mm 912mm 90mm 176kg No Gear 1055mm
96 282.30.1175.013 282.30.1175.013 Typ 110/1300.2 1298 -0.20mm 1012mm 90mm 192kg No Gear 1155mm
97 282.30.1275.013 282.30.1275.013 Typ 110/1400.2 1398 -0.20mm 1112mm 90mm 208kg No Gear 1255mm
98 282.30.1375.013 282.30.1375.013 Typ 110/1500.2 1498 -0.20mm 1212mm 90mm 226kg No Gear 1355mm
99 282.30.1475.013 282.30.1475.013 Typ 110/1600.2 1598 -0.20mm 1310mm 90mm 243kg No Gear 1455mm
