Model Selection
| NO. | Product | Product Number | Overall height (H) | Outer diameter (Do) | Height of outer ring (Ho) | Inner diameter (di) | Gear Type | Height of inner ring (Hi) |
|---|---|---|---|---|---|---|---|---|
| 1 |
|
Q16349001 | 7.300in | 48.560in | 6.880in | 33.000in | No Gear | 6.380in |
| 2 |
|
Q16350001 | 8.661in | 56.890in | 8.150in | 41.535in | No Gear | 6.772in |
| 3 |
|
Q16351001 | 7.550in | 77.250in | 7.000in | 59.880in | No Gear | 7.120in |
| 4 |
|
Q16352001 | 9.050in | 93.000in | 8.630in | 72.500in | No Gear | 8.620in |
| 5 |
|
Q16353001 | 7.677in | 118.583in | 7.283in | 97.638in | No Gear | 6.102in |
| 6 |
|
Q16354001 | 5.945in | 122.480in | 5.472in | 107.638in | No Gear | 4.646in |
| 7 |
|
Q16356001 | 9.000in | 158.000in | 8.500in | 136.500in | No Gear | 7.250in |
| 8 |
|
Q16387001 | 8.819in | 207.480in | 8.425in | 187.795in | No Gear | 8.425in |
| 9 |
|
Q16366001 | 12.205in | 236.220in | 9.842in | 210.236in | No Gear | 11.811in |
| 10 |
|
Q16376001 | 4.720in | 54.530in | 4.410in | 41.760in | Internal Gear | 3.700in |
| 11 |
|
Q16377001 | 7.874in | 64.173in | 7.283in | 46.850in | Internal Gear | 6.299in |
| 12 |
|
Q16378001 | 8.620in | 70.500in | 8.120in | 50.200in | Internal Gear | 6.750in |
| 13 |
|
Q16379001 | 6.969in | 87.244in | 6.772in | 68.032in | Internal Gear | 5.315in |
| 14 |
|
Q16380001 | 8.504in | 108.189in | 8.150in | 85.433in | Internal Gear | 6.850in |
| 15 |
|
Q16381001 | 13.701in | 120.866in | 10.157in | 97.008in | Internal Gear | 11.732in |
| 16 |
|
Q16382001 | 8.380in | 125.620in | 6.810in | 106.333in | Internal Gear | 6.880in |
| 17 |
|
Q16383001 | 9.055in | 155.512in | 8.661in | 131.339in | Internal Gear | 7.284in |
| 18 |
|
Q16384001 | 9.252in | 187.402in | 8.858in | 162.992in | Internal Gear | 7.480in |
| 19 |
|
Q16385001 | 11.750in | 228.000in | 11.250in | 198.000in | External Gear | 9.250in |
| 20 |
|
Q16367001 | 5.000in | 57.100in | 4.500in | 42.500in | External Gear | 4.500in |
| 21 |
|
Q16368001 | 5.850in | 71.338in | 4.790in | 57.000in | External Gear | 4.630in |
| 22 |
|
Q16369001 | 7.126in | 97.795in | 5.472in | 76.850in | External Gear | 6.772in |
| 23 |
|
Q16370001 | 10.750in | 115.800in | 8.500in | 90.500in | External Gear | 10.250in |
| 24 |
|
Q16371001 | 10.039in | 152.756in | 8.071in | 129.921in | External Gear | 9.646in |
| 25 |
|
Q16372001 | 9.941in | 170.079in | 7.638in | 144.882in | External Gear | 9.449in |
| 26 |
|
Q16373001 | 8.819in | 210.968in | 8.425in | 187.795in | External Gear | 8.425in |
| 27 |
|
Q16388001 | 11.750in | 233.000in | 9.250in | 203.000in | External Gear | 11.250in |
