Flanged Bearing Units-Imperial

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

1 3/16~16inch

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Filters

NO. Product Product Number Bolt size Hight (W) Inner diameter (d) Number of mounting holes (n) Thickness of flange (k) Distance shaft axis (H)
101 DF02+01E DF02+01E B 111 M12 165 mm 1 11/16 inch 13 mm 52 mm
102 DF02+01E DF02+01E B 112 M12 165 mm 1 3/4 inch 13 mm 52 mm
103 DF02+01E DF02+01E B 115 M12 165 mm 1 15/16 inch 13 mm 52 mm
104 DF02+02 DF02+02 B 200 M12 165 mm 2 inch 13 mm 52 mm
105 DF03+01E DF03+01E B 203 M16 184 mm 2 3/16 inch 16 mm 55 mm
106 DF03+01E DF03+01E B 204 M16 184 mm 2 1/4 inch 16 mm 55 mm
107 DF03+01E DF03+01E B 207 M16 184 mm 2 7/16 inch 16 mm 55 mm
108 DF03+01E DF03+01E B 208 M16 184 mm 2 1/2 inch 16 mm 55 mm
109 DF04+01E DF04+01E B 211 M20 217 mm 2 11/16 inch 16 mm 60 mm
110 DF04+01E DF04+01E B 212 M20 217 mm 2 3/4 inch 16 mm 60 mm
111 DF03+100 DF03+100 B 215 M16 184 mm 2 15/16 inch 16 mm 55 mm
112 DF04+01E DF04+01E B 215 M20 217 mm 2 15/16 inch 16 mm 60 mm
113 DF03+100 DF03+100 B 300 M16 184 mm 3 inch 16 mm 55 mm
114 DF04+01E DF04+01E B 215 M20 217 mm 3 inch 16 mm 60 mm
115 DF04+100 DF04+100 B 307 M20 217 mm 3 7/16 inch 16 mm 60 mm
