Hanger Bearing Units-Imperial

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

1 1/4~6inch

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Filters

NO. Product Product Number Inner diameter (d) Diameter of housing abutment (Db MAX) Housing width (L) Distance shaft axis (H) Bolt size Length of housing fixed end (Y)
1 01 01 H 104+01 B 104 EX 1 1/4 inch 100 mm 108 mm 66 mm M36 50 mm
2 01 01 H 108+01 B 108 EX 1 1/2 inch 100 mm 108 mm 66 mm M36 50 mm
3 01 01 H 111+01E B 111 EX 1 11/16 inch 118 mm 108 mm 76 mm M36 50 mm
4 01 01 H 112+01E B 112 EX 1 3/4 inch 118 mm 108 mm 76 mm M36 50 mm
5 01 01 H 115+01E B 115 EX 1 15/16 inch 118 mm 108 mm 76 mm M36 50 mm
6 01 01 H 200+01E B 200 EX 2 inch 118 mm 108 mm 76 mm M36 50 mm
7 01 01 H 203+01E B 203 EX 2 3/16 inch 134 mm 108 mm 82 mm M36 50 mm
8 01 01 H 204+01E B 204 EX 2 1/4 inch 134 mm 108 mm 82 mm M36 50 mm
9 01 01 H 207+01E B 207 EX 2 7/16 inch 134 mm 108 mm 82 mm M36 50 mm
10 01 01 H 208+01E B 208 EX 2 1/2 inch 134 mm 108 mm 82 mm M36 50 mm
11 01 01 H 211+01E B 211 EX 2 11/16 inch 158 mm 130 mm 92 mm M36 50 mm
12 01 01 H 212+01E B 212 EX 2 3/4 inch 158 mm 130 mm 92 mm M36 50 mm
13 100 100 H 215+100 B 215 EX 2 15/16 inch 134 mm 108 mm 82 mm M36 50 mm
14 01 01 H 215+01E B 215 EX 2 15/16 inch 158 mm 130 mm 92 mm M36 50 mm
15 100 100 H 300+100 B 300 EX 3 inch 134 mm 108 mm 82 mm M36 50 mm
16 01 01 H 300+01E B 300 EX 3 inch 158 mm 130 mm 92 mm M36 50 mm
17 01 01 H 303+01E B 303 EX 3 3/16 inch 178 mm 146 mm 114 mm M36 76 mm
18 01 01 H 304+01E B 304 EX 3 1/4 inch 178 mm 146 mm 114 mm M36 76 mm
19 100 100 H 307+100 B 307 EX 3 7/16 inch 158 mm 130 mm 92 mm M36 50 mm
20 01 01 H 307+01E B 307 EX 3 7/16 inch 178 mm 146 mm 114 mm M36 76 mm
21 01 01 H 308+01E B 308 EX 3 1/2 inch 178 mm 146 mm 114 mm M36 76 mm
22 01 01 H 311+01E B 311 EX 3 11/16 inch 203 mm 152 mm 127 mm M36 76 mm
23 01 01 H 312+01E B 312 EX 3 3/4 inch 203 mm 152 mm 127 mm M36 76 mm
24 100 100 H 315+100 B 315 EX 3 15/16 inch 178 mm 146 mm 114 mm M36 76 mm
25 01 01 H 315+01E B 315 EX 3 15/16 inch 203 mm 152 mm 127 mm M36 76 mm
26 100 100 H 400+100 B 400 EX 4 inch 178 mm 146 mm 114 mm M36 76 mm
27 01 01 H 400+01E B 400 EX 4 inch 203 mm 152 mm 127 mm M36 76 mm
28 01 01 H 403+01 B 403 EX 4 3/16 inch 232 mm 156 mm 140 mm M36 76 mm
29 100 100 H 407+100 B 407 EX 4 7/16 inch 203 mm 152 mm 127 mm M36 76 mm
30 01 01 H 407+01 B 407 EX 4 7/16 inch 232 mm 156 mm 140 mm M36 76 mm
31 100 100 H 408+100 B 408 EX 4 1/2 inch 203 mm 152 mm 127 mm M36 76 mm
32 01 01 H 408+01 B 408 EX 4 1/2 inch 232 mm 156 mm 140 mm M36 76 mm
33 100 100 H 415+100 B 415 EX 4 15/16 inch 232 mm 156 mm 140 mm M36 76 mm
34 01 01 H 415+01 B 415 EX 4 15/16 inch 276 mm 162 mm 156 mm M36 76 mm
35 100 100 H 500+100 B 500 EX 5 inch 232 mm 156 mm 140 mm M36 76 mm
36 01 01 H 500+01 B 500 EX 5 inch 276 mm 162 mm 156 mm M36 76 mm
37 01 01 H 503+01 B 503 EX 5 3/16 inch 280 mm 158 mm 160 mm M36 76 mm
38 100 100 H 507+100 B 507 EX 5 7/16 inch 276 mm 162 mm 156 mm M36 76 mm
39 01 01 H 507+01 B 507 EX 5 7/16 inch 280 mm 158 mm 160 mm M36 76 mm
40 100 100 H 508+100 B 508 EX 5 1/2 inch 276 mm 162 mm 156 mm M36 76 mm
41 01 01 H 508+01 B 508 EX 5 1/2 inch 280 mm 158 mm 160 mm M36 76 mm
42 100 100 H 515+100 B 515 EX 5 15/16 inch 280 mm 158 mm 160 mm M36 76 mm
43 100 100 H 600+100 B 600 EX 6 inch 280 mm 158 mm 160 mm M36 76 mm
44 01 01 H 115 TRIPLE BOSS+01 E B 115 EX 1 15/16 inch 160 mm 109 mm 76 mm 1"-8 UNC
45 01 01 H 200 TRIPLE BOSS+01 E B 200 EX 2 inch 160 mm 109 mm 76 mm 1"-8 UNC
46 01 01 H 215 TRIPLE BOSS+01 E B 215 EX 2 15/16 inch 190 mm 130 mm 92 mm 1"-8 UNC
47 01 01 H 300 TRIPLE BOSS+01 E B 300 EX 3 inch 190 mm 130 mm 92 mm 1"-8 UNC
48 100 100 H 307 TRIPLE BOSS+100 B 307 EX 3 7/16 inch 190 mm 130 mm 92 mm 1"-8 UNC
49 01 01 H 407 TRIPLE BOSS+01 B 407 EX 4 7/16 inch 290 mm 170 mm 140 mm 1½"-6 UNC
50 01 01 H 408 TRIPLE BOSS+01 B 408 EX 4 1/2 inch 290 mm 170 mm 140 mm 1½"-6 UNC
51 100 100 H 415 TRIPLE BOSS+100 B 415 EX 4 15/16 inch 290 mm 170 mm 140 mm 1½"-6 UNC
52 100 100 H 500 TRIPLE BOSS+100 B 500 EX 5 inch 290 mm 170 mm 140 mm 1½"-6 UNC
