Hanger Bearing Units-Metric

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

40~150mm

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Filters

NO. Product Product Number Inner diameter (d) Diameter of housing abutment (Db MAX) Housing width (L) Distance shaft axis (H) Bolt size Length of housing fixed end (Y)
1 01 01 H 40M+01 B 40M EX 40 mm 100 mm 108 mm 66 mm M30 50 mm
2 01 01 H 50M+01E B 50M EX 50 mm 118 mm 108 mm 76 mm M30 50 mm
3 01 01 H 60M+01E B 60M EX 60 mm 134 mm 108 mm 82 mm M30 50 mm
4 01 01 H 65M+01E B 65M EX 65 mm 134 mm 108 mm 82 mm M30 50 mm
5 01 01 H 70M+01E B 70M EX 70 mm 158 mm 130 mm 92 mm M30 50 mm
6 100 100 H 75M+100 B 75M EX 75 mm 134 mm 108 mm 82 mm M30 50 mm
7 01 01 H 75M+01E B 75M EX 75 mm 158 mm 130 mm 92 mm M30 50 mm
8 01E 01E H 80M+01E B 80M EX 80 mm 178 mm 146 mm 114 mm M36 76 mm
9 100 100 H 85M+100 B 85M EX 85 mm 158 mm 130 mm 92 mm M30 50 mm
10 01E 01E H 85M+01E B 85M EX 85 mm 178 mm 146 mm 114 mm M36 76 mm
11 01E 01E H 90M+01E B 90M EX 90 mm 178 mm 146 mm 114 mm M36 76 mm
12 100 100 H 100M+100 B 100M EX 100 mm 178 mm 146 mm 114 mm M36 76 mm
13 01E 01E H 100M+01E B 100M EX 100 mm 203 mm 152 mm 127 mm M36 76 mm
14 01E 01E H 105M+01E B 105M EX 105 mm 203 mm 152 mm 127 mm M36 76 mm
15 100 100 H 110M+100 B 110M EX 110 mm 203 mm 152 mm 127 mm M36 76 mm
16 01 01 H 110M+01 B 110M EX 110 mm 232 mm 156 mm 140 mm M36 76 mm
17 01 01 H 115M+01 B 115M EX 115 mm 232 mm 156 mm 140 mm M36 76 mm
18 100 100 H 120M+100 B 120M EX 120 mm 232 mm 156 mm 140 mm M36 76 mm
19 01 01 H 120M+01 B 120M EX 120 mm 276 mm 162 mm 156 mm M36 76 mm
20 01 01 H 125M+01 B 125M EX 125 mm 276 mm 162 mm 156 mm M36 76 mm
21 100 100 H 130M+100 B 130M EX 130 mm 232 mm 156 mm 140 mm M36 76 mm
22 01 01 H 130M+01 B 130M EX 130 mm 276 mm 162 mm 156 mm M36 76 mm
23 01 01 H 135M+01 B 135M EX 135 mm 280 mm 158 mm 160 mm M36 76 mm
24 100 100 H 140M+100 B 140M EX 140 mm 276 mm 162 mm 156 mm M36 76 mm
25 01 01 H 140M+01 B 140M EX 140 mm 280 mm 158 mm 160 mm M36 76 mm
26 100 100 H 150M+100 B 150M EX 150 mm 280 mm 158 mm 160 mm M36 76 mm
27 01 01 H 50M TRIPLE BOSS+01E B 50M EX 50 mm 160 mm 109 mm 76 mm M36
28 01 01 H 75M TRIPLE BOSS+01E B 75M EX 75 mm 190 mm 130 mm 92 mm M36
29 100 100 H 85M TRIPLE BOSS+100 B 85M EX 85 mm 190 mm 130 mm 92 mm M36
30 01 01 H 110M TRIPLE BOSS+01 B 110M EX 110 mm 290 mm 170 mm 140 mm M36
31 100 100 H 120M TRIPLE BOSS+100 B 120M EX 120 mm 290 mm 170 mm 140 mm M36
32 100 100 H 130M TRIPLE BOSS+100 B 130M EX 130 mm 290 mm 170 mm 140 mm M36
