Search for the bearing model you need
Standard
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material
High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15
Brand
QIBR/OEM/Neutral
Package
QIBR/Standard Industrial Package/OEM
Bore
1 15/16~5 15/16inch
Applications
Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc
| NO. | Product | Product Number | Bore | Length total (a) | Distance shaft axis (H) | MAX distance fixing bore (E) | MIN distance fixing bore (E) |
|---|---|---|---|---|---|---|---|
| 1 |
|
SAFC511+01E B 115 | 9 5/8 inch | 2 3/4 inch | 7 7/8 inch | 7 3/8 inch | |
| 2 |
|
SAFC513+01E B 203 | 11 inch | 3 inch | 9 1/2 inch | 8 1/8 inch | |
| 3 |
|
SAFC515+01E B 207 | 11 1/4 inch | 3 1/4 inch | 9 5/8 inch | 8 5/8 inch | |
| 4 |
|
SAFC516+01E B 211 | 13 inch | 3 1/2 inch | 11 inch | 9 5/8 inch | |
| 5 |
|
SAFC517+01E B 215 | 13 inch | 3/4 inch | 11 inch | 9 7/8 inch | |
| 6 |
|
SAFC517+02 B 215 | 13 inch | 3/4 inch | 10 7/8 inch | 10 inch | |
| 7 |
|
SAFC518+01E B 303 | 13 3/8 inch | 4 inch | 11 5/8 inch | 10 3/8 inch | |
| 8 |
|
SAFC520+01E B 307 | 15 1/4 inch | 4 1/2 inch | 13 1/8 inch | 11 5/8 inch | |
| 9 |
|
FSAFC520+02 B 307 | 15 1/4 inch | 4 1/2 inch | 13 1/8 inch | 11 5/8 inch | |
| 10 |
|
SAFC522+02 B 315 | 16 1/2 inch | 4 15/16 inch | 14 1/2 inch | 12 5/8 inch | |
| 11 |
|
SAFC526+02 B 407 | 18 3/8 inch | 6 inch | 16 inch | 14 5/8 inch | |
| 12 |
|
SAFC528(3)+02 B 415(3) | 20 1/8 inch | 6 inch | 17 1/8 inch | 16 inch | |
| 13 |
|
SAFC532+02 B 507 | 22 inch | 6 11/16 inch | 19 1/4 inch | 17 3/8 inch | |
| 14 |
|
SAFC534+02 B 515 | 24 3/4 inch | 7 1/16 inch | 21 5/8 inch | 19 3/8 inch |
