Interchangeable Bearing Units-Metric

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

60~300mm

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Filters

NO. Product Product Number Bolt size Inner diameter (d) Length total (a) Distance shaft axis (H) MAX distance fixing bore (E) MIN distance fixing bore (E)
1 SNC513+01E SNC513+01E B 60M M16 60 mm 280 mm 80 mm 242 mm 226 mm
2 SNC515+01E SNC515+01E B 65M M16 65 mm 280 mm 80 mm 242 mm 226 mm
3 SNC516+01E SNC516+01E B 70M M20 70 mm 315 mm 95 mm 266 mm 254 mm
4 SNC517+01E SNC517+01E B 75M M20 75 mm 315 mm 95 mm 266 mm 254 mm
5 SNC518+01E SNC518+01E B 80M M20 80 mm 345 mm 100 mm 296 mm 284 mm
6 SNC519+01E SNC519+01E B 85M M20 85 mm 345 mm 112 mm 296 mm 284 mm
7 SNC520+01E SNC520+01E B 90M M24 90 mm 380 mm 112 mm 328 mm 312 mm
8 SNC522+01E SNC522+01E B 100M M24 100 mm 420 mm 125 mm 366 mm 342 mm
9 SNC524+01 SNC524+01 B 110M M24 110 mm 410 mm 140 mm 356 mm 344 mm
10 SNC526+01 SNC526+01 B 115M M24 115 mm 450 mm 150 mm 388 mm 372 mm
11 SNC528+01 SNC528+01 B 125M M30 125 mm 500 mm 150 mm 426 mm 414 mm
12 SNC530+01 SNC530+01 B 135M M30 135 mm 530 mm 160 mm 456 mm 444 mm
13 SNC532+01 SNC532+01 B 140M M30 140 mm 558 mm 170 mm 478 mm 462 mm
14 SDC3134+01 SDC3134+01 B 150M M24 150 mm 510 mm 170 mm 436 mm 424 mm
15 SDC3136+01 SDC3136+01 B 160M M24 160 mm 530 mm 180 mm 462 mm 438 mm
16 SDC3138+01 SDC3138+01 B 170M M24 170 mm 560 mm 190 mm 492 mm 468 mm
17 SDC3140+01 SDC3140+01 B 180M M30 180 mm 600 mm 210 mm 517 mm 503 mm
18 SDC3144+01 SDC3144+01 B 200M M30 200 mm 640 mm 220 mm 547 mm 533 mm
19 SDC3148+01 SDC3148+01 B 220M M30 220 mm 700 mm 240 mm 607 mm 593 mm
20 SDC3152+01 SDC3152+01 B 240M M36 240 mm 770 mm 260 mm 658 mm 642 mm
21 SDC3156+01 SDC3156+01 B 260M M36 260 mm 790 mm 280 mm 678 mm 662 mm
22 SDC3160+01 SDC3160+01 B 280M M36 280 mm 830 mm 300 mm 718 mm 702 mm
23 SDC3164+01 SDC3164+01 B 300M M36 300 mm 880 mm 320 mm 758 mm 742 mm
