Plummer Bearing Units-Imperial

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

1 3/16~24inch

Applications

Agricultural Machinery, Mining & Construction Equipment, Conveying Systems, Paper & Printing Machinery,etc

Filters

NO. Product Product Number Bolt size Inner diameter (d) Length total (a) Distance shaft axis (H) MAX distance fixing bore (E) MIN distance fixing bore (E)
101 P13+01 P13+01 B 800 M24 8 inch 572 mm 248 mm 434 mm 410 mm
102 P34+02 P34+02 B 800 M30 8 inch 686 mm 305 mm 528 mm 488 mm
103 P61+03 P61+03 B 800 M36 8 inch 838 mm 311 mm 656 mm 616 mm
104 P14+01 P14+01 B 900 M30 9 inch 636 mm 270 mm 480 mm 440 mm
105 P35+02 P35+02 B 900 M36 9 inch 750 mm 324 mm 570 mm 530 mm
106 P62+03 P62+03 B 900 M42 9 inch 952 mm 349 mm 756 mm 716 mm
107 P15+01 P15+01 B 1000 M30 10 inch 686 mm 292 mm 522 mm 482 mm
108 P36+02 P36+02 B 1000 M36 10 inch 812 mm 356 mm 616 mm 576 mm
109 P63+03 P63+03 B 1000 M42 10 inch 914 mm 394 mm 690 mm 650 mm
110 P16+01 P16+01 B 1100 M30 11 inch 724 mm 311 mm 554 mm 514 mm
111 P37+02 P37+02 B 1100 M30 11 inch 914 mm 378 mm 554 mm 514 mm
112 P64+03X P64+03X B 1100 M36 11 inch 1028 mm 425 mm 630 mm 590 mm
113 P83+03E P83+03E B 1100 M36 11 inch 940 mm 368 mm 522 mm 482 mm
114 P17+01 P17+01 B 1200 M30 12 inch 762 mm 343 mm 604 mm 564 mm
115 P38+02 P38+02 B 1200 M30 12 inch 958 mm 394 mm 586 mm 546 mm
116 P65+03 P65+03 B 1200 M36 12 inch 1092 mm 457 mm 694 mm 654 mm
117 P18+01 P18+01 B 1300 M36 13 inch 812 mm 368 mm 642 mm 602 mm
118 P39+02 P39+02 B 1300 M30 13 inch 1016 mm 419 mm 630 mm 590 mm
119 P66+03 P66+03 B 1300 M36 13 inch 1194 mm 518 mm 782 mm 742 mm
120 P19+01 P19+01 B 1400 M36 14 inch 850 mm 387 mm 674 mm 634 mm
121 P40+02 P40+02 B 1400 M36 14 inch 1092 mm 451 mm 680 mm 640 mm
122 P86+03E P86+03E B 1400 M42 14 inch 1220 mm 470 mm 686 mm 634 mm
123 P20+01 P20+01 B 1500 M36 15 inch 902 mm 397 mm 696 mm 656 mm
124 P41+02 P41+02 B 1500 M36 15 inch 1092 mm 464 mm 702 mm 662 mm
125 P68+03 P68+03 B 1500 M42 15 inch 1270 mm 559 mm 832 mm 780 mm
126 P21+01 P21+01 B 1600 M36 16 inch 940 mm 432 mm 744 mm 704 mm
127 P42+02 P42+02 B 1600 M36 16 inch 1168 mm 495 mm 750 mm 710 mm
128 P22+01 P22+01 B 1700 M36 17 inch 966 mm 445 mm 776 mm 736 mm
129 P43+02 P43+02 B 1700 M36 17 inch 1194 mm 514 mm 788 mm 748 mm
130 P89+03E P89+03E B 1700 M48 17 inch 1270 mm 508 mm 716 mm 664 mm
131 P23+01 P23+01 B 1800 M42 18 inch 1042 mm 464 mm 808 mm 768 mm
132 P44+02 P44+02 B 1800 M36 18 inch 1244 mm 533 mm 808 mm 768 mm
133 P90+03E P90+03E B 1800 M48 18 inch 1370 mm 550 mm 806 mm 754 mm
134 P24+01 P24+01 B 1900 M42 19 inch 1092 mm 483 mm 836 mm 796 mm
135 P45+02 P45+02 B 1900 M36 19 inch 1270 mm 552 mm 832 mm 792 mm
136 P25+01 P25+01 B 2000 M42 20 inch 1092 mm 489 mm 864 mm 824 mm
137 P46+02 P46+02 B 2000 M36 20 inch 1296 mm 572 mm 864 mm 824 mm
138 P94+03 P94+03 B 2000 M56 20 inch 1600 mm 622 mm 966 mm 914 mm
139 P26+01 P26+01 B 2100 M42 21 inch 1194 mm 533 mm 924 mm 884 mm
140 P47+02 P47+02 B 2100 M36 21 inch 1398 mm 591 mm 910 mm 870 mm
141 P27+01 P27+01 B 2200 M42 22 inch 1220 mm 552 mm 956 mm 916 mm
142 P48+02 P48+02 B 2200 M42 22 inch 1422 mm 616 mm 956 mm 904 mm
143 P94+03E P94+03E B 2200 M56 22 inch 1600 mm 622 mm 966 mm 914 mm
144 P28+01 P28+01 B 2300 M36 23 inch 1346 mm 578 mm 896 mm 857 mm
145 P49+02 P49+02 B 2300 M42 23 inch 1448 mm 635 mm 984 mm 932 mm
146 P95+03E P95+03E B 2300 M56 23 inch 1600 mm 622 mm 966 mm 914 mm
147 P29+01 P29+01 B 2400 M36 24 inch 1372 mm 597 mm 928 mm 888 mm
148 P50+02 P50+02 B 2400 M42 24 inch 1524 mm 673 mm 1036 mm 984 mm
