Rod Ends Bearing Units-Imperial

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

1 3/16~6inch

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Filters

NO. Product Product Number Bore Guide groove width (O) Length of housing fixed end (Y) Width of housing fixed end (J) Distance shaft axis (H) Length total (a)
101 100 100 BCRES 300 3 inch 113 mm 79 mm 190 mm
102 01E 01E BCRES 300 3 inch 126 mm 108 mm 248 mm
103 02 02 BCRES 300 3 inch 152 mm 130 mm 248 mm
104 01E 01E BCRES 303 3 3/16 inch 148 mm 133 mm 264 mm
105 02 02 BCRES 303 3 3/16 inch 173 mm 149 mm 334 mm
106 01E 01E BCRES 304 3 1/4 inch 148 mm 133 mm 264 mm
107 02 02 BCRES 304 3 1/4 inch 173 mm 149 mm 334 mm
108 100 100 BCRES 307 3 7/16 inch 126 mm 108 mm 248 mm
109 01E 01E BCRES 307 3 7/16 inch 148 mm 133 mm 264 mm
110 02 02 BCRES 307 3 7/16 inch 173 mm 149 mm 334 mm
111 01E 01E BCRES 308 3 1/2 inch 148 mm 133 mm 264 mm
112 02 02 BCRES 308 3 1/2 inch 173 mm 149 mm 334 mm
113 01E 01E BCRES 311 3 11/16 inch 146 mm 125 mm 308 mm
114 02 02 BCRES 311 3 11/16 inch 171 mm 149 mm 354 mm
115 01E 01E BCRES 312 3 3/4 inch 146 mm 125 mm 308 mm
116 02 02 BCRES 312 3 3/4 inch 171 mm 149 mm 354 mm
117 100 100 BCRES 315 3 15/16 inch 148 mm 130 mm 248 mm
118 01E 01E BCRES 315 3 15/16 inch 146 mm 125 mm 308 mm
119 02 02 BCRES 315 3 15/16 inch 171 mm 149 mm 354 mm
120 100 100 BCRES 400 4 inch 148 mm 130 mm 248 mm
121 01E 01E BCRES 400 4 inch 146 mm 125 mm 308 mm
122 02 02 BCRES 400 4 inch 171 mm 149 mm 354 mm
123 01 01 BCRES 403 4 3/16 inch 154 mm 149 mm 354 mm
124 02 02 BCRES 403 4 3/16 inch 187 mm 162 mm 400 mm
125 100 100 BCRES 407 4 7/16 inch 146 mm 125 mm 308 mm
126 01 01 BCRES 407 4 7/16 inch 154 mm 149 mm 354 mm
127 02 02 BCRES 407 4 7/16 inch 187 mm 162 mm 400 mm
128 100 100 BCRES 408 4 1/2 inch 146 mm 125 mm 308 mm
129 01 01 BCRES 408 4 1/2 inch 154 mm 149 mm 354 mm
130 02 02 BCRES 408 4 1/2 inch 187 mm 162 mm 400 mm
131 100 100 BCRES 415 4 15/16 inch 154 mm 149 mm 354 mm
132 01 01 BCRES 415 4 15/16 inch 168 mm 158 mm 400 mm
133 02 02 BCRES 415 4 15/16 inch 209 mm 177 mm 442 mm
134 100 100 BCRES 500 5 inch 154 mm 149 mm 354 mm
135 01 01 BCRES 500 5 inch 168 mm 158 mm 400 mm
136 02 02 BCRES 500 5 inch 209 mm 177 mm 442 mm
137 01 01 BCRES 503 5 3/16 inch 187 mm 177 mm 442 mm
138 02 02 BCRES 503 5 3/16 inch 213 mm 177 mm 442 mm
139 100 100 BCRES 507 5 7/16 inch 168 mm 158 mm 400 mm
140 01 01 BCRES 507 5 7/16 inch 187 mm 177 mm 442 mm
141 02 02 BCRES 507 5 7/16 inch 213 mm 177 mm 442 mm
142 100 100 BCRES 508 5 1/2 inch 168 mm 158 mm 400 mm
143 01 01 BCRES 508 5 1/2 inch 187 mm 177 mm 442 mm
144 02 02 BCRES 508 5 1/2 inch 213 mm 177 mm 442 mm
145 100 100 BCRES 515 5 15/16 inch 187 mm 177 mm 442 mm
146 01 01 BCRES 515 5 15/16 inch 193 mm 177 mm 442 mm
147 02 02 BCRES 515 5 15/16 inch 229 mm 203 mm 444 mm
148 100 100 BCRES 600 6 inch 187 mm 177 mm 442 mm
149 01 01 BCRES 600 6 inch 193 mm 177 mm 442 mm
150 02 02 BCRES 600 6 inch 229 mm 203 mm 444 mm
