Rod Ends Bearing Units-Metric

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

40~155mm

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Filters

NO. Product Product Number Bore Guide groove width (O) Length of housing fixed end (Y) Width of housing fixed end (J) Distance shaft axis (H) Length total (a)
1 01 01 BCRET 40M 40 mm 92 mm 86 mm 30 mm 76 mm 140 mm
2 01E 01E BCRET 45M 45 mm 104 mm 102 mm 32 mm 102 mm 166 mm
3 01E 01E BCRET 50M 50 mm 104 mm 102 mm 32 mm 102 mm 166 mm
4 02 02 BCRET 50M 50 mm 123 mm 115 mm 38 mm 95 mm 197 mm
5 01E 01E BCRET 60M 60 mm 113 mm 115 mm 38 mm 95 mm 197 mm
6 02 02 BCRET 60M 60 mm 138 mm 128 mm 44 mm 108 mm 216 mm
7 01E 01E BCRET 65M 65 mm 113 mm 115 mm 38 mm 95 mm 197 mm
8 02 02 BCRET 65M 65 mm 138 mm 128 mm 44 mm 108 mm 216 mm
9 01E 01E BCRET 70M 70 mm 126 mm 128 mm 44 mm 108 mm 216 mm
10 02 02 BCRET 70M 70 mm 152 mm 146 mm 48 mm 127 mm 248 mm
11 100 100 BCRET 75M 75 mm 113 mm 115 mm 38 mm 95 mm 197 mm
12 01E 01E BCRET 75M 75 mm 126 mm 128 mm 44 mm 108 mm 216 mm
13 02 02 BCRET 75M 75 mm 152 mm 146 mm 48 mm 127 mm 248 mm
14 01E 01E BCRET 80M 80 mm 148 mm 146 mm 48 mm 127 mm 248 mm
15 02 02 BCRET 80M 80 mm 173 mm 170 mm 76 mm 200 mm 308 mm
16 100 100 BCRET 85M 85 mm 126 mm 128 mm 44 mm 108 mm 216 mm
17 01E 01E BCRET 85M 85 mm 148 mm 146 mm 48 mm 127 mm 248 mm
18 02 02 BCRET 85M 85 mm 173 mm 170 mm 76 mm 200 mm 308 mm
19 01E 01E BCRET 90M 90 mm 148 mm 146 mm 48 mm 127 mm 248 mm
20 02 02 BCRET 90M 90 mm 173 mm 170 mm 76 mm 200 mm 308 mm
21 100 100 BCRET 100M 100 mm 148 mm 146 mm 48 mm 127 mm 248 mm
22 01E 01E BCRET 100M 100 mm 146 mm 170 mm 76 mm 200 mm 308 mm
23 02 02 BCRET 100M 100 mm 171 mm 190 mm 86 mm 222 mm 334 mm
24 01E 01E BCRET 105M 105 mm 146 mm 170 mm 76 mm 200 mm 308 mm
25 02 02 BCRET 105M 105 mm 171 mm 190 mm 86 mm 222 mm 334 mm
26 100 100 BCRET 110M 110 mm 146 mm 170 mm 76 mm 200 mm 308 mm
27 01 01 BCRET 110M 110 mm 154 mm 190 mm 86 mm 222 mm 334 mm
28 02 02 BCRET 110M 110 mm 187 mm 190 mm 86 mm 222 mm 375 mm
29 01 01 BCRET 115M 115 mm 154 mm 190 mm 86 mm 222 mm 334 mm
30 02 02 BCRET 115M 115 mm 187 mm 190 mm 86 mm 222 mm 375 mm
31 100 100 BCRET 120M 120 mm 154 mm 190 mm 86 mm 222 mm 334 mm
32 01 01 BCRET 120M 120 mm 168 mm 190 mm 86 mm 222 mm 375 mm
33 02 02 BCRET 120M 120 mm 209 mm 204 mm 102 mm 279 mm 442 mm
34 01 01 BCRET 125M 125 mm 168 mm 190 mm 86 mm 222 mm 375 mm
35 02 02 BCRET 125M 125 mm 209 mm 204 mm 102 mm 279 mm 442 mm
36 100 100 BCRET 130M 130 mm 154 mm 190 mm 86 mm 222 mm 334 mm
37 01 01 BCRET 130M 130 mm 168 mm 190 mm 86 mm 222 mm 375 mm
38 02 02 BCRET 130M 130 mm 209 mm 204 mm 102 mm 279 mm 442 mm
39 01 01 BCRET 135M 135 mm 187 mm 204 mm 102 mm 279 mm 442 mm
40 100 100 BCRET 140M 140 mm 168 mm 190 mm 86 mm 222 mm 375 mm
41 01 01 BCRET 140M 140 mm 187 mm 204 mm 102 mm 279 mm 442 mm
42 02 02 BCRET 140M 140 mm 213 mm 204 mm 102 mm 279 mm 445 mm
43 100 100 BCRET 150M 150 mm 187 mm 204 mm 102 mm 279 mm 442 mm
44 01 01 BCRET 150M 150 mm 193 mm 204 mm 102 mm 279 mm 442 mm
45 02 02 BCRET 150M 150 mm 229 mm 204 mm 102 mm 279 mm 445 mm
46 01 01 BCRET 155M 155 mm 193 mm 204 mm 102 mm 279 mm 442 mm
47 02 02 BCRET 155M 155 mm 229 mm 204 mm 102 mm 279 mm 445 mm
48 01 01 BCRES 40M 40 mm 92 mm 65 mm 160 mm
49 01E 01E BCRES 45M 45 mm 104 mm 70 mm 166 mm
50 01E 01E BCRES 50M 50 mm 104 mm 70 mm 166 mm
51 02 02 BCRES 50M 50 mm 123 mm 76 mm 190 mm
52 01E 01E BCRES 60M 60 mm 113 mm 79 mm 190 mm
53 02 02 BCRES 60M 60 mm 138 mm 108 mm 248 mm
54 01E 01E BCRES 65M 65 mm 113 mm 79 mm 190 mm
55 02 02 BCRES 65M 65 mm 138 mm 108 mm 248 mm
56 01E 01E BCRES 70M 70 mm 126 mm 108 mm 248 mm
57 02 02 BCRES 70M 70 mm 152 mm 130 mm 248 mm
58 100 100 BCRES 75M 75 mm 113 mm 79 mm 190 mm
59 01E 01E BCRES 75M 75 mm 126 mm 108 mm 248 mm
60 02 02 BCRES 75M 75 mm 152 mm 130 mm 248 mm
61 01E 01E BCRES 80M 80 mm 148 mm 133 mm 264 mm
62 02 02 BCRES 80M 80 mm 173 mm 149 mm 334 mm
63 100 100 BCRES 85M 85 mm 126 mm 108 mm 248 mm
64 01E 01E BCRES 85M 85 mm 148 mm 133 mm 264 mm
65 02 02 BCRES 85M 85 mm 173 mm 149 mm 334 mm
66 01E 01E BCRES 90M 90 mm 148 mm 133 mm 264 mm
67 02 02 BCRES 90M 90 mm 173 mm 149 mm 334 mm
68 100 100 BCRES 100M 100 mm 148 mm 130 mm 248 mm
69 01E 01E BCRES 100M 100 mm 146 mm 125 mm 308 mm
70 02 02 BCRES 100M 100 mm 171 mm 149 mm 354 mm
71 01E 01E BCRES 105M 105 mm 146 mm 125 mm 308 mm
72 02 02 BCRES 105M 105 mm 171 mm 149 mm 354 mm
73 100 100 BCRES 110M 110 mm 146 mm 125 mm 308 mm
74 01 01 BCRES 110M 110 mm 154 mm 149 mm 354 mm
75 02 02 BCRES 110M 110 mm 187 mm 162 mm 400 mm
76 01 01 BCRES 115M 115 mm 154 mm 149 mm 354 mm
77 02 02 BCRES 115M 115 mm 187 mm 162 mm 400 mm
78 100 100 BCRES 120M 120 mm 154 mm 149 mm 354 mm
79 01 01 BCRES 120M 120 mm 168 mm 158 mm 400 mm
80 02 02 BCRES 120M 120 mm 209 mm 177 mm 442 mm
81 01 01 BCRES 125M 125 mm 168 mm 158 mm 400 mm
82 02 02 BCRES 125M 125 mm 209 mm 177 mm 442 mm
83 100 100 BCRES 130M 130 mm 154 mm 149 mm 354 mm
84 01 01 BCRES 130M 130 mm 168 mm 158 mm 400 mm
85 02 02 BCRES 130M 130 mm 209 mm 177 mm 442 mm
86 01 01 BCRES 135M 135 mm 187 mm 177 mm 442 mm
87 100 100 BCRES 140M 140 mm 168 mm 158 mm 400 mm
88 01 01 BCRES 140M 140 mm 187 mm 177 mm 442 mm
89 02 02 BCRES 140M 140 mm 213 mm 177 mm 442 mm
90 100 100 BCRES 150M 150 mm 187 mm 177 mm 442 mm
91 01 01 BCRES 150M 150 mm 193 mm 177 mm 442 mm
92 02 02 BCRES 150M 150 mm 229 mm 203 mm 444 mm
93 01 01 BCRES 155M 155 mm 193 mm 177 mm 442 mm
94 02 02 BCRES 155M 155 mm 229 mm 203 mm 444 mm
