Split Cylindrical Roller Bearings-Imperial

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

1 3/16~40inch

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Split Cylindrical Roller Bearings-Imperial

Filters

NO. Product Product Number Inner diameter (d) Outer diameter (D) Width (B) Width (B1) Width of inner ring (C) Shaft diameter and clamping ring clearance (Q)
101 01 01 B 800 8 inch 311.15 mm 60.3 mm 109.0 mm 285 mm
102 02 02 B 800 8 inch 368.30 mm 90.5 mm 156.0 mm 328 mm
103 03 03 B 800 8 inch 419.10 mm 118.3 mm 191.0 mm 366 mm
104 01 01 B 900 9 inch 342.90 mm 63.5 mm 115.0 mm 315 mm
105 02 02 B 900 9 inch 393.70 mm 90.5 mm 163.0 mm 354 mm
106 03 03 B 900 9 inch 469.90 mm 131.8 mm 212.0 mm 410 mm
107 01 01 B 1000 10 inch 374.65 mm 66.7 mm 122.0 mm 344 mm
108 02 02 B 1000 10 inch 431.80 mm 96.8 mm 170.0 mm 388 mm
109 03 03 B 1000 10 inch 482.60 mm 124.6 mm 211.0 mm 430 mm
110 01 01 B 1100 11 inch 406.40 mm 69.0 mm 128.0 mm 375 mm
111 02 02 B 1100 11 inch 463.55 mm 101.6 mm 186.0 mm 420 mm
112 03X 03X B 1100 11 inch 520.70 mm 131.8 mm 231.0 mm 462 mm
113 03E 03E B 1100 11 inch 495.30 mm 139.7 mm 244.0 mm 452 mm
114 01 01 B 1200 12 inch 438.15 mm 74.6 mm 143.0 mm 404 mm
115 02 02 B 1200 12 inch 495.30 mm 103.2 mm 193.0 mm 448 mm
116 03 03 B 1200 12 inch 558.80 mm 139.7 mm 244.0 mm 496 mm
117 01 01 B 1300 13 inch 463.55 mm 74.6 mm 136.0 mm 432 mm
118 02 02 B 1300 13 inch 527.05 mm 106.4 mm 192.0 mm 478 mm
119 03 03 B 1300 13 inch 622.30 mm 160.4 mm 272.0 mm 550 mm
120 01 01 B 1400 14 inch 488.95 mm 74.6 mm 136.0 mm 456 mm
121 02 02 B 1400 14 inch 565.15 mm 115.9 mm 200.0 mm 514 mm
122 03E 03E B 1400 14 inch 615.95 mm 158.0 mm 279.0 mm 556 mm
123 01 01 B 1500 15 inch 520.70 mm 76.2 mm 140.0 mm 486 mm
124 02 02 B 1500 15 inch 584.20 mm 111.1 mm 200.0 mm 536 mm
125 03 03 B 1500 15 inch 685.80 mm 166.7 mm 292.0 mm 610 mm
126 01 01 B 1600 16 inch 546.10 mm 76.2 mm 140.0 mm 512 mm
127 02 02 B 1600 16 inch 615.95 mm 115.9 mm 200.0 mm 566 mm
128 01 01 B 1700 17 inch 571.50 mm 76.2 mm 140.0 mm 538 mm
129 02 02 B 1700 17 inch 647.70 mm 119.1 mm 200.0 mm 596 mm
130 03E 03E B 1700 17 inch 700.00 mm 160.0 mm 284.0 mm 640 mm
131 01 01 B 1800 18 inch 596.90 mm 76.2 mm 140.0 mm 562 mm
132 02 02 B 1800 18 inch 666.75 mm 115.9 mm 200.0 mm 618 mm
133 03E 03E B 1800 18 inch 740.00 mm 170.0 mm 294.0 mm 680 mm
134 01 01 B 1900 19 inch 628.65 mm 81.0 mm 144.0 mm 594 mm
135 02 02 B 1900 19 inch 698.50 mm 119.1 mm 223.0 mm 648 mm
136 01 01 B 2000 20 inch 654.05 mm 80.2 mm 168.0 mm 618 mm
137 02 02 B 2000 20 inch 717.55 mm 115.9 mm 226.0 mm 670 mm
138 03 03 B 2000 20 inch 850.90 mm 187.4 mm 300.0 mm 765 mm
139 01 01 B 2100 21 inch 692.15 mm 81.0 mm 168.0 mm 650 mm
140 02 02 B 2100 21 inch 762.00 mm 119.1 mm 229.0 mm 710 mm
141 01 01 B 2200 22 inch 717.55 mm 81.0 mm 168.0 mm 675 mm
142 02 02 B 2200 22 inch 793.75 mm 122.2 mm 233.0 mm 738 mm
143 03E 03E B 2200 22 inch 863.60 mm 196.9 mm 310.0 mm 800 mm
144 01 01 B 2300 23 inch 749.30 mm 84.1 mm 172.0 mm 706 mm
145 02 02 B 2300 23 inch 812.80 mm 119.1 mm 232.0 mm 754 mm
146 03E 03E B 2300 23 inch 890.00 mm 184.0 mm 310.0 mm 826 mm
147 01 01 B 2400 24 inch 774.70 mm 84.1 mm 172.0 mm 732 mm
148 02 02 B 2400 24 inch 838.20 mm 119.1 mm 214.0 mm 786 mm
149 02 02 B 2500 25 inch 866.78 mm 219.08 mm
150 03E 03E B 2600 26 inch 980 mm 320 mm
151 01 01 B 2700 27 inch 864 mm 170 mm
152 01 01 B 2800 28 inch 892.18 mm 184.15 mm
153 01 01 B 4000 40 inch 1270 mm 260 mm
