Split Cylindrical Roller Bearings-Metric

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

35~600mm

Applications

Automotive Industry, Material Handling Equipment, Construction Machinery, Agricultural Equipment, etc

Split Cylindrical Roller Bearings-Metric

Filters

NO. Product Product Number Inner diameter (d) Outer diameter (D) Width of inner ring (C) Width (B1) Basic dynamic load rating,radial Basic static load rating,radial
101 01 01 B 300M 300 mm 438.15 mm 143.0 mm 74.6 mm 806 KN 1452 KN
102 02 02 B 300M 300 mm 495.30 mm 193.0 mm 103.2 mm 1467 KN 2409 KN
103 03 03 B 300M 300 mm 558.80 mm 244.0 mm 139.7 mm 2156 KN 3312 KN
104 01 01 B 320M 320 mm 463.55 mm 136.0 mm 74.6 mm 894 KN 1638 KN
105 02 02 B 320M 320 mm 527.05 mm 192.0 mm 106.4 mm 1570 KN 2622 KN
106 03 03 B 320M 320 mm 622.30 mm 272.0 mm 106.4 mm 2529 KN 3795 KN
107 01 01 B 330M 330 mm 463.55 mm 136.0 mm 74.6 mm 894 KN 1638 KN
108 02 02 B 330M 330 mm 527.05 mm 192.0 mm 106.4 mm 1570 KN 2622 KN
109 01 01 B 1300-340M 340 mm 463.55 mm 136.0 mm 74.6 mm 894 KN 1638 KN
110 01 01 B 340M 340 mm 488.95 mm 136.0 mm 74.6 mm 935 KN 1774 KN
111 02 02 B 340M 340 mm 565.15 mm 200.0 mm 115.9 mm 1744 KN 2940 KN
112 03E 03E B 340M 340 mm 615.95 mm 279.0 mm 158.0 mm 2750 KN 4392 KN
113 01 01 B 350M 350 mm 488.95 mm 136.0 mm 74.6 mm 935 KN 1774 KN
114 02 02 B 350M 350 mm 565.15 mm 200.0 mm 115.9 mm 1744 KN 2940 KN
115 01 01 B 1400-360M 360 mm 488.95 mm 136.0 mm 74.6 mm 935 KN 1774 KN
116 01 01 B 360M 360 mm 520.70 mm 140.0 mm 76.2 mm 1005 KN 1925 KN
117 02 02 B 360M 360 mm 565.15 mm 200.0 mm 115.9 mm 1744 KN 2940 KN
118 03E 03E B 360M 360 mm 615.95 mm 279.0 mm 158.0 mm 2750 KN 4392 KN
119 03X 03X B 360M 360 mm 647.70 mm 279.0 mm 160.4 mm 2785 KN 4377 KN
120 01 01 B 380M 380 mm 520.70 mm 140.0 mm 76.2 mm 1005 KN 1925 KN
121 02 02 B 380M 380 mm 584.20 mm 200.0 mm 111.1 mm 1862 KN 3254 KN
122 03 03 B 380M 380 mm 685.80 mm 292.0 mm 166.7 mm 3019 KN 4800 KN
123 01 01 B 390M 390 mm 546.10 mm 140.0 mm 76.2 mm 1048 KN 2071 KN
124 01 01 B 400M 400 mm 546.10 mm 140.0 mm 76.2 mm 1048 KN 2071 KN
125 02 02 B 400M 400 mm 615.95 mm 200.0 mm 115.9 mm 1948 KN 3438 KN
126 03 03 B 400M 400 mm 685.80 mm 292.0 mm 166.7 mm 3019 KN 4800 KN
127 01 01 B 420M 420 mm 571.50 mm 140.0 mm 76.2 mm 1089 KN 2218 KN
128 02 02 B 420M 420 mm 647.70 mm 200.0 mm 119.1 mm 2069 KN 3702 KN
129 03E 03E B 420M 420 mm 700.00 mm 284.0 mm 160.0 mm 3474 KN 6006 KN
130 01 01 B 440M 440 mm 596.90 mm 140.0 mm 76.2 mm 1129 KN 2366 KN
131 02 02 B 440M 440 mm 666.75 mm 200.0 mm 115.9 mm 2195 KN 4057 KN
132 03E 03E B 440M 440 mm 700.00 mm 284.0 mm 160.0 mm 3474 KN 6006 KN
133 01 01 B 460M 460 mm 596.90 mm 140.0 mm 76.2 mm 1129 KN 2366 KN
134 02 02 B 460M 460 mm 666.75 mm 200.0 mm 115.9 mm 2195 KN 4057 KN
135 03E 03E B 460M 460 mm 740.00 mm 294.0 mm 170.0 mm 3650 KN 6156 KN
136 03X 03X B 460M 460 mm 800.10 mm 300.0 mm 187.4 mm 3771 KN 6186 KN
137 01 01 B 480M 480 mm 628.65 mm 144.0 mm 81.0 mm 1169 KN 2433 KN
138 02 02 B 480M 480 mm 698.50 mm 223.0 mm 119.1 mm 2313 KN 4419 KN
139 03X 03X B 480M 480 mm 800.10 mm 300.0 mm 187.4 mm 3771 KN 6186 KN
140 01 01 B 500M 500 mm 654.05 mm 168.0 mm 80.2 mm 1213 KN 2593 KN
141 02 02 B 500M 500 mm 717.55 mm 226.0 mm 115.9 mm 2430 KN 4776 KN
142 03 03 B 500M 500 mm 850.90 mm 300.0 mm 187.4 mm 4087 KN 7042 KN
143 01 01 B 530M 530 mm 692.15 mm 168.0 mm 81.0 mm 1253 KN 2755 KN
144 02 02 B 530M 530 mm 762.00 mm 229.0 mm 119.1 mm 2658 KN 5137 KN
145 03 03 B 530M 530 mm 850.90 mm 300.0 mm 187.4 mm 4087 KN 7042 KN
146 01 01 B 560M 560 mm 717.55 mm 168.0 mm 81.0 mm 1294 KN 2916 KN
147 02 02 B 560M 560 mm 793.75 mm 233.0 mm 122.2 mm 2790 KN 5556 KN
148 03E 03E B 560M 560 mm 863.60 mm 310.0 mm 196.9 mm 4669 KN 8511 KN
149 01 01 B 580M 580 mm 749.30 mm 172.0 mm 84.1 mm 1387 KN 3138 KN
150 02 02 B 580M 580 mm 812.80 mm 232.0 mm 119.1 mm 2336 KN 4836 KN
151 01 01 B 600M 600 mm 774.70 mm 172.0 mm 84.1 mm 1431 KN 3311 KN
152 02 02 B 600M 600 mm 838.20 mm 214.0 mm 119.1 mm 2905 KN 5992 KN
153 03E 03E B 600M 600 mm 890.00 mm 310.0 mm 184.0 mm 4887 KN 9130 KN
154 03E 03E B 613.2M 613 mm 980 mm 370 mm 200 mm 5593 KN 9863 KN
155 01 01 B 630M 630 mm 794 mm 190 mm 88 mm 1780 KN 4181 KN
156 02 02 B 650M 650 mm 860 mm 220 mm 120 mm 2724 KN 5833 KN
157 03E 03E B 650M 650 mm 980 mm 320 mm 200 mm 5738 KN 11253 KN
158 01 01 B 690M 690 mm 864 mm 170 mm 94 mm 1761 KN 4014 KN
159 01 01 B 710M 710 mm 890 mm 185 mm 95 mm 1817 KN 4234 KN
160 01 01 B 750M 750 mm 971.55 mm 206 mm 101.6 mm 2321 KN 5685 KN
161 02 02 B 710M 710 mm 980 mm 290 mm 155 mm 3530 KN 7019 KN
162 02 02 B 750M 750 mm 990 mm 240 mm 140 mm 3554 KN 7582 KN
163 03 03 B 750M 750 mm 1060 mm 310 mm 185 mm 5173 KN 10544 KN
164 01 01 B 775M 775 mm 945 mm 165 mm 80 mm 1762 KN 3974 KN
165 01 01 B 850M 850 mm 1046 mm 200 mm 106 mm 2555 KN 6401 KN
166 01 01 B 950M 950 mm 1172 mm 220 mm 120 mm 3238 KN 8209 KN
167 4DS 4DS B 1150M 1150 mm 1490 mm 305 mm 175 mm 5737 KN 13445 KN
