70. 72. 718. 719 SERIES

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Pairing method

DB, DF, DT, DBD, DBB, SU

70. 72. 718. 719 SERIES

Filters

NO. Product Product Number Inner diameter (d) Outer diameter (D) Width (B) Basic dynamic load rating Basic static load rating Mass
501 709CE/HCP4A/ 709CE/HCP4A 9 mm 24 mm 7 mm 2.6 KN 0.93 KN 0.013 kg
502 719/8 719/8 ACE/P2 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
503 719/8ACE/HCP4A/ 719/8ACE/HCP4A 8 mm 19 mm 6 mm 1.68KN 0.6 KN 0.006 kg
504 719/8ACE/P2HU/ 719/8ACE/P2HU 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
505 719/8ACE/P4A/ 719/8ACE/P4A 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
506 719/8ACE/P4AHU/ 719/8ACE/P4AHU 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
507 719/8ACGB/P4AH/ 719/8ACGB/P4AH 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
508 719/8ACGB/P4AL/ 719/8ACGB/P4AL 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
509 719/8ACGB/P4AL1/ 719/8ACGB/P4AL1 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
510 719/8ACGC/P4AH/ 719/8ACGC/P4AH 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
511 719/8ACGC/P4AH1/ 719/8ACGC/P4AH1 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
512 719/8ACGC/P4AL/ 719/8ACGC/P4AL 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
513 719/8ACGC/P4AL1/ 719/8ACGC/P4AL1 8 mm 19 mm 6 mm 1.68 KN 0.6 KN 0.007 kg
514 719/8CE/HCP4A/ 719/8CE/HCP4A 8 mm 19 mm 6 mm 1.74 KN 0.63 KN 0.006 kg
515 719/9 719/9 ACE/P2 9 mm 20 mm 6 mm 1.95 KN 0.765 KN 0.008 kg
516 719/9ACE/HCP4A/ 719/9ACE/HCP4A 9 mm 20 mm 6 mm 1.95 KN 0.765 KN 0.007 kg
517 719/9ACE/P4AHU/ 719/9ACE/P4AHU 9 mm 20 mm 6 mm 1.95 KN 0.765 KN 0.008 kg
518 719/9CE/HCP4A/ 719/9CE/HCP4A 9 mm 20 mm 6 mm 2.03 KN 0.8 KN 0.007 kg
519 71900ACE/HCP4A/ 71900ACE/HCP4A 10 mm 22 mm 6 mm 1.95 KN 0.78 KN 0.008 kg
520 71900ACE/P4AHU/ 71900ACE/P4AHU 10 mm 22 mm 6 mm 1.95 KN 0.78 KN 0.009 kg
521 71900CD/HCP4A/ 71900CD/HCP4A 10 mm 22 mm 6 mm 2.51 KN 1.1 KN 0.009 kg
522 71900CE/HCP4A/ 71900CE/HCP4A 10 mm 22 mm 6 mm 2.03 KN 0.815 KN 0.008 kg
523 71901ACE/HCP4A/ 71901ACE/HCP4A 12 mm 24 mm 6 mm 2.03 KN 0.865 KN 0.009 kg
524 71901ACE/P4AHU/ 71901ACE/P4AHU 12 mm 24 mm 6 mm 2.03 KN 0.865 KN 0.01 kg
525 71901CD/HCP4A/ 71901CD/HCP4A 12 mm 24 mm 6 mm 2.65 KN 1.25 KN 0.01 kg
526 71901CE/HCP4A/ 71901CE/HCP4A 12 mm 24 mm 6 mm 2.12 KN 0.915 KN 0.009 kg
527 71902ACE/HCP4A/ 71902ACE/HCP4A 15 mm 28 mm 7 mm 3.02 KN 1.34 KN 0.013 kg
528 71902ACE/P4AHU/ 71902ACE/P4AHU 15 mm 28 mm 7 mm 3.02 KN 1.34 KN 0.015 kg
529 71902CD/HCP4A/ 71902CD/HCP4A 15 mm 28 mm 7 mm 3.97 KN 1.9 KN 0.014 kg
530 71902CE/HCP4A/ 71902CE/HCP4A 15 mm 28 mm 7 mm 3.19 KN 1.4 KN 0.013 kg
531 71903ACE/HCP4A/ 71903ACE/HCP4A 17 mm 30 mm 7 mm 3.19 KN 1.46 KN 0.014 kg
532 71903ACE/P4AHU/ 71903ACE/P4AHU 17 mm 30 mm 7 mm 3.19 KN 1.46 KN 0.016 kg
533 71903CD/HCP4A/ 71903CD/HCP4A 17 mm 30 mm 7 mm 4.16 KN 2.08 KN 0.015 kg
534 71903CE/HCP4A/ 71903CE/HCP4A 17 mm 30 mm 7 mm 3.32 KN 1.56 KN 0.014 kg
535 71904ACE/HCP4A/ 71904ACE/HCP4A 20 mm 37 mm 9 mm 4.68 KN 2.28 KN 0.032 kg
536 71904ACE/P4AHU/ 71904ACE/P4AHU 20 mm 37 mm 9 mm 4.68 KN 2.28 KN 0.036 kg
537 71904CD/HCP4A/ 71904CD/HCP4A 20 mm 37 mm 9 mm 6.05 KN 3.2 KN 0.033 kg
538 71904CE/HCP4A/ 71904CE/HCP4A 20 mm 37 mm 9 mm 4.88 KN 2.4 KN 0.032 kg
539 71905ACE/HCP4A/ 71905ACE/HCP4A 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.036 kg
540 71905ACE/P4AHU/ 71905ACE/P4AHU 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
541 71905ACGB/P4AH/ 71905ACGB/P4AH 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
542 71905ACGB/P4AL/ 71905ACGB/P4AL 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
543 71905ACGB/P4AL1/ 71905ACGB/P4AL1 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
544 71905ACGC/P4AH/ 71905ACGC/P4AH 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
545 71905ACGC/P4AH1/ 71905ACGC/P4AH1 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
546 71905ACGC/P4AL/ 71905ACGC/P4AL 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
547 71905ACGC/P4AL1/ 71905ACGC/P4AL1 25 mm 42 mm 9 mm 4.94 KN 2.7 KN 0.04 kg
548 71905AGA/P4AH/ 71905AGA/P4AH 25 mm 42 mm 9 mm 4.446 KN 2.43 KN 0.04 kg
549 71905AGA/P4AL/ 71905AGA/P4AL 25 mm 42 mm 9 mm 4.45 KN 2.43 KN 0.04 kg
550 71905AGA/P4AL1/ 71905AGA/P4AL1 25 mm 42 mm 9 mm 4.45 KN 2.43 KN 0.04 kg
551 71905AGB/P4AH/ 71905AGB/P4AH 25 mm 42 mm 9 mm 4.446 KN 2.43 KN 0.04 kg
552 71905AGB/P4AL/ 71905AGB/P4AL 25 mm 42 mm 9 mm 4.446 KN 2.43 KN 0.04 kg
553 71905AGB/P4AL1/ 71905AGB/P4AL1 25 mm 42 mm 9 mm 4.446 KN 2.43 KN 0.04 kg
554 71905CD/HCP4A/ 71905CD/HCP4A 25 mm 42 mm 9 mm 6.67 KN 4 KN 0.039 kg
555 71905CE/HCP4A/ 71905CE/HCP4A 25 mm 42 mm 9 mm 5.27 KN 2.85 KN 0.036 kg
556 71906 71906 ACD/P4AH1QBC 30 mm 47 mm 9 mm 5.59 KN 3.25 KN 0.048 kg
557 71906ACD/P4AHDB/ 71906ACD/P4AHDB 30 mm 47 mm 9 mm 5.59 KN 3.25 KN 0.048 kg
558 71906ACE/HCP4A/ 71906ACE/HCP4A 30 mm 47 mm 9 mm 5.27 KN 3.1 KN 0.045 kg
559 71906ACE/P4AHU/ 71906ACE/P4AHU 30 mm 47 mm 9 mm 5.27 KN 3.1 KN 0.05 kg
560 71906CD/HCP4A/ 71906CD/HCP4A 30 mm 47 mm 9 mm 7.15 KN 4.55 KN 0.045 kg
561 71906CE/HCP4A/ 71906CE/HCP4A 30 mm 47 mm 9 mm 5.59 KN 3.25 KN 0.045 kg
562 71907ACE/HCP4A/ 71907ACE/HCP4A 35 mm 55 mm 10 mm 7.28 KN 4.5 KN 0.067 kg
563 71907ACE/P4AHU/ 71907ACE/P4AHU 35 mm 55 mm 10 mm 7.28 KN 4.5 KN 0.075 kg
564 71907CB/HCP4A/ 71907CB/HCP4A 35 mm 55 mm 10 mm 7.28 KN 4.5 KN 0.075 kg
565 71907CB/P4A/ 71907CB/P4A 35 mm 55 mm 10 mm 7.28 KN 4.5 KN 0.075 kg
566 71907CD/HCP4A/ 71907CD/HCP4A 35 mm 55 mm 10 mm 9.75 KN 6.55 KN 0.068 kg
567 71907CE/HCP4A/ 71907CE/HCP4A 35 mm 55 mm 10 mm 7.61 KN 4.75 KN 0.067 kg
568 71907CE/P4AHDU/ 71907CE/P4AHDU 35 mm 55 mm 10 mm 7.61KN 4.57 KN 0.068 kg
569 71908ACB/HCP4A/ 71908ACB/HCP4A 40 mm 62 mm 12 mm 9.23 KN 5.85 KN 0.1 kg
570 71908ACB/P4A/ 71908ACB/P4A 40 mm 62 mm 12 mm 9.23 KN 5.85 KN 0.1 kg
571 71908ACE/HCP4A/ 71908ACE/HCP4A 40 mm 62 mm 12 mm 9.23 KN 5.58 KN 0.088 kg
572 71908ACE/P4AHU/ 71908ACE/P4AHU 40 mm 62 mm 12 mm 9.23 KN 5.85 KN 0.1 kg
573 71908CD/HCP4A/ 71908CD/HCP4A 40 mm 62 mm 12 mm 12.4 KN 8.5 KN 0.1 kg
574 71908CE/HCP4A/ 71908CE/HCP4A 40 mm 62 mm 12 mm 9.75 KN 6.1 KN 0.088 kg
575 71909ACB/HCP4A/ 71909ACB/HCP4A 45 mm 68 mm 12 mm 9.75 KN 6.55 KN 0.12 kg
576 71909ACB/P4A/ 71909ACB/P4A 45 mm 68 mm 12 mm 9.75 KN 6.55 KN 0.12 kg
577 71909ACE/HCP4A/ 71909ACE/HCP4A 45 mm 68 mm 12 mm 9.75 KN 6.4 KN 0.13 kg
578 71909ACE/P4AHU/ 71909ACE/P4AHU 45 mm 68 mm 12 mm 9.75 KN 6.55 KN 0.13 kg
579 71909CD/HCP4A/ 71909CD/HCP4A 45 mm 68 mm 12 mm 13 KN 9.5 KN 0.12 kg
580 71909CE/HCP4A/ 71909CE/HCP4A 45 mm 68 mm 12 mm 10.1 KN 6.95 KN 0.120 kg
581 71910ACB/HCP4A/ 71910ACB/HCP4A 50 mm 72 mm 12 mm 12.1 KN 8.15 KN 0.11 kg
582 71910ACB/P4A/ 71910ACB/P4A 50 mm 72 mm 12 mm 12.1 KN 8.15 KN 0.11 kg
583 71910ACE/HCP4A/ 71910ACE/HCP4A 50 mm 72 mm 12 mm 12.1 KN 8.15 KN 0.11 kg
584 71910ACE/P4AHU/ 71910ACE/P4AHU 50 mm 72 mm 12 mm 12.1 KN 8.15 KN 0.13 kg
585 71910CD/HCP4A/ 71910CD/HCP4A 50 mm 72 mm 12 mm 13.5 KN 10.4 KN 0.12 kg
586 71910CE/HCP4A/ 71910CE/HCP4A 50 mm 72 mm 12 mm 12.7 KN 8.65 KN 0.110 kg
587 71911ACE/HCP4A/ 71911ACE/HCP4A 55 mm 80 mm 13 mm 14.6 KN 10.2 KN 0.14 kg
588 71911ACE/P4AHU/ 71911ACE/P4AHU 55 mm 80 mm 13 mm 14.6 KN 10.2 KN 0.17 kg
589 71911CD/HCP4A/ 71911CD/HCP4A 55 mm 80 mm 13 mm 19.5 KN 14.6 KN 0.15 kg
590 71911CE/HCP4A/ 71911CE/HCP4A 55 mm 80 mm 13 mm 15.3 KN 10.6 KN 0.140 kg
591 71912ACB/HCP4A/ 71912ACB/HCP4A 60 mm 85 mm 13 mm 15.3 KN 11.2 KN 0.16 kg
592 71912ACB/P4A/ 71912ACB/P4A 60 mm 85 mm 13 mm 15.3 KN 11.2 KN 0.16 kg
593 71912ACE/HCP4A/ 71912ACE/HCP4A 60 mm 85 mm 13 mm 15.3 KN 11.2 KN 0.16 kg
594 71912ACE/P4AHU/ 71912ACE/P4AHU 60 mm 85 mm 13 mm 15.3 KN 11.2 KN 0.19 kg
595 71912CD/HCP4A/ 71912CD/HCP4A 60 mm 85 mm 13 mm 19.9 KN 15.3 KN 0.16 kg
596 71912CE/HCP4A/ 71912CE/HCP4A 60 mm 85 mm 13 mm 16.3 KN 11.8 KN 0.16 kg
597 71913ACB/HCP4A/ 71913ACB/HCP4A 65 mm 90 mm 13 mm 15.6 KN 11.8 KN 0.17 kg
598 71913ACB/P4A/ 71913ACB/P4A 65 mm 90 mm 13 mm 15.6 KN 11.8 KN 0.17 kg
599 71913ACE/HCP4A/ 71913ACE/HCP4A 65 mm 90 mm 13 mm 15.6 KN 11.8 KN 0.17 kg
600 71913ACE/P4AHU/ 71913ACE/P4AHU 65 mm 90 mm 13 mm 15.6 KN 11.8 KN 0.2 kg
