Spindle bearings

Image may differ from product. See technical specification for details.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM,Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Package

DB, DF, DT, DBD, DBB, SU

Pairing method

DB, DF, DT, DBD, DBB, SU

Spindle bearings

Filters

NO. Product Product Number Basic dynamic load rating Basic static load rating Inner diameter (d) Mass Outer diameter (D) Width (B)
6701 HCB71809-C-TPA-P4/ HCB71809-C-TPA-P4 5.00 KN 4.80 KN 45 mm 0.04kg 58 mm 7 mm
6702 HCB71809-E-TPA-P4/ HCB71809-E-TPA-P4 5.00 KN 4.80 KN 45 mm 0.04kg 58 mm 7 mm
6703 HCB71809-E-DLR-TPA-P4/ HCB71809-E-DLR-TPA-P4 5.00 KN 4.80 KN 45 mm 0.04kg 58 mm 7 mm
6704 HCB71809-E-P2-DB/ HCB71809-E-P2-DB 4.75 KN 4.50 KN 45 mm 0.04kg 58 mm 7 mm
6705 HCB71809-C-P2-DT-L/ HCB71809-C-P2-DT-L 4.75 KN 4.50 KN 45 mm 0.04kg 58 mm 7 mm
6706 B71909-C-P2-DB/ B71909-C-P2-DB 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6707 B71909-E-P2-DB-L/ B71909-E-P2-DB-L 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6708 B71909-E-P2-DT/ B71909-E-P2-DT 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6709 71909 71909 ACE/HCP2 9.75 KN 6.55 KN 45 mm 0.13 kg 68 mm 12 mm
6710 B71909-C-T-P4S/ B71909-C-T-P4S 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6711 B71909-E-T-P4S/ B71909-E-T-P4S 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6712 B71909-C-DLR-T-P4S/ B71909-C-DLR-T-P4S 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6713 B71909-E-DLR-T-P4S/ B71909-E-DLR-T-P4S 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6714 HC71909-C-DLR-T-P4S/ HC71909-C-DLR-T-P4S 18.60 KN 15.60 KN 45 mm 0.13 kg 68 mm 12 mm
6715 HCB71909-C-T-P4S/ HCB71909-C-T-P4S 12.90 KN 10.80 KN 45 mm 0.13 kg 68 mm 12 mm
6716 HCB71909-E-T-P4S/ HCB71909-E-T-P4S 12.90 KN 10.80 KN 45 mm 0.13 kg 68 mm 12 mm
6717 HCB71909-C-DLR-T-P4S/ HCB71909-C-DLR-T-P4S 12.90 KN 10.80 KN 45 mm 0.13 kg 68 mm 12 mm
6718 HCB71909-E-DLR-T-P4S/ HCB71909-E-DLR-T-P4S 12.90 KN 10.80 KN 45 mm 0.13 kg 68 mm 12 mm
6719 HCB71909-E-P2-DB/ HCB71909-E-P2-DB 12.20 KN 10.40 KN 45 mm 0.11 kg 68 mm 12 mm
6720 HCB71909-C-P2-DT-L/ HCB71909-C-P2-DT-L 12.20 KN 10.40 KN 45 mm 0.11 kg 68 mm 12 mm
6721 XCB71909-E-P2-DB/ XCB71909-E-P2-DB 27.00 KN 10.40 KN 45 mm 0.11 kg 68 mm 12 mm
6722 XCB71909-E-T-P4S/ XCB71909-E-T-P4S 27.00 KN 10.40 KN 45 mm 0.11 kg 68 mm 12 mm
6723 XCB71909-E-DLR-T-P4S/ XCB71909-E-DLR-T-P4S 27.00 KN 10.40 KN 45 mm 0.11 kg 68 mm 12 mm
6724 XCB71909-C-P2-DB-M/ XCB71909-C-P2-DB-M 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6725 XC71909-C-P2-DB-M/ XC71909-C-P2-DB-M 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6726 XCB71909-C-P2-DT/ XCB71909-C-P2-DT 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6727 XCB71909-E-P2-DT-M/ XCB71909-E-P2-DT-M 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6728 XC71909-C-P2-DT/ XC71909-C-P2-DT 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6729 XC71909-C-P2-H/ XC71909-C-P2-H 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6730 XC71909-E-P2-DT-M/ XC71909-E-P2-DT-M 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6731 XC71909-C-T-P4S/ XC71909-C-T-P4S 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6732 XCB71909-C-T-P4S/ XCB71909-C-T-P4S 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6733 XCB71909-C-DLR-T-P4S/ XCB71909-C-DLR-T-P4S 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6734 XC71909-C-DLR-T-P4S/ XC71909-C-DLR-T-P4S 29.00 KN 10.80 KN 45 mm 0.11 kg 68 mm 12 mm
6735 HS71909-C-P2-DB-H/ HS71909-C-P2-DB-H 10.00 KN 9.65 KN 45 mm 0.14 kg 68 mm 12 mm
6736 HS71909-C-T-P4S/ HS71909-C-T-P4S 10.00 KN 9.65 KN 45 mm 0.14 kg 68 mm 12 mm
6737 HS71909-C-DLR-T-P4S/ HS71909-C-DLR-T-P4S 10.00 KN 9.65 KN 45 mm 0.14 kg 68 mm 12 mm
6738 B7009-E-P2-DB-L/ B7009-E-P2-DB-L 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6739 B7009-C-P2-DB/ B7009-C-P2-DB 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6740 B7009-E-P2-DT/ B7009-E-P2-DT 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6741 7009ACE/HCP2/ 7009ACE/HCP2 12.10 KN 8.15 KN 45 mm 0.24 kg 75 mm 16 mm
6742 7009ACE/P2H1DF/ 7009ACE/P2H1DF 12.10 KN 8.15 KN 45 mm 0.24 kg 75 mm 16 mm
6743 B7009-C-T-P4S/ B7009-C-T-P4S 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6744 B7009-E-T-P4S/ B7009-E-T-P4S 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6745 B7009-C-DLR-T-P4S/ B7009-C-DLR-T-P4S 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6746 B7009-E-DLR-T-P4S/ B7009-E-DLR-T-P4S 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6747 HC7009-C-DLR-T-P4S/ HC7009-C-DLR-T-P4S 27.50 KN 21.20 KN 45 mm 0.23 kg 75 mm 16 mm
6748 HCB7009-C-T-P4S/ HCB7009-C-T-P4S 19.00 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6749 HCB7009-E-T-P4S/ HCB7009-E-T-P4S 19.00 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6750 HCB7009-C-DLR-T-P4S/ HCB7009-C-DLR-T-P4S 19.00 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6751 HCB7009-E-DLR-T-P4S/ HCB7009-E-DLR-T-P4S 19.00 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6752 HCB7009-E-DLR-T-P4S/ HCB7009-E-DLR-T-P4S 19.00 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6753 HCB7009-E-P2-DB/ HCB7009-E-P2-DB 18.00 KN 14.00 KN 45 mm 0.20 kg 75 mm 16 mm
6754 HCB7009-C-P2-DT-L/ HCB7009-C-P2-DT-L 18.00 KN 14.00 KN 45 mm 0.20 kg 75 mm 16 mm
6755 XCB7009-E-P2-DB/ XCB7009-E-P2-DB 40.00 KN 14.00 KN 45 mm 0.20 kg 75 mm 16 mm
6756 XCB7009-E-T-P4S/ XCB7009-E-T-P4S 40.00 KN 14.00 KN 45 mm 0.20 kg 75 mm 16 mm
6757 XCB7009-E-DLR-T-P4S/ XCB7009-E-DLR-T-P4S 40.00 KN 14.00 KN 45 mm 0.20 kg 75 mm 16 mm
6758 XCB7009-C-P2-DB-M/ XCB7009-C-P2-DB-M 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6759 XC7009-C-P2-DB-M/ XC7009-C-P2-DB-M 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6760 XCB7009-C-P2-DT/ XCB7009-C-P2-DT 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6761 XC7009-C-P2-DT/ XC7009-C-P2-DT 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6762 XC7009-E-P2-DT-M/ XC7009-E-P2-DT-M 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6763 XCB7009-E-P2-DT-M/ XCB7009-E-P2-DT-M 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6764 XC7009-C-P2-H/ XC7009-C-P2-H 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6765 XCB7009-C-T-P4S/ XCB7009-C-T-P4S 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6766 XCB7009-C-DLR-T-P4S/ XCB7009-C-DLR-T-P4S 42.50 KN 14.60 KN 45 mm 0.20 kg 75 mm 16 mm
6767 HS7009-C-P2-DB-H/ HS7009-C-P2-DB-H 12.90 KN 12.20 KN 45 mm 0.27 kg 75 mm 16 mm
6768 HS7009-C-T-P4S/ HS7009-C-T-P4S 12.90 KN 12.20 KN 45 mm 0.27 kg 75 mm 16 mm
6769 HS7009-C-DLR-T-P4S/ HS7009-C-DLR-T-P4S 12.90 KN 12.20 KN 45 mm 0.27 kg 75 mm 16 mm
6770 B7209-C-P2-DB/ B7209-C-P2-DB 33.50 KN 24.50 KN 45 mm 0.41 kg 85 mm 19 mm
6771 B7209-C-T-P4S/ B7209-C-T-P4S 33.50 KN 24.50 KN 45 mm 0.41 kg 85 mm 19 mm
6772 B7209-E-T-P4S/ B7209-E-T-P4S 33.50 KN 24.50 KN 45 mm 0.41 kg 85 mm 19 mm
6773 B7209-C-DLR-T-P4S/ B7209-C-DLR-T-P4S 33.50 KN 24.50 KN 45 mm 0.41 kg 85 mm 19 mm
6774 B7209-E-DLR-T-P4S/ B7209-E-DLR-T-P4S 33.50 KN 24.50 KN 45 mm 0.41 kg 85 mm 19 mm
6775 B7209-E-P2-DB-L/ B7209-E-P2-DB-L 32.00 KN 23.60 KN 45 mm 0.41 kg 85 mm 19 mm
6776 B7209-E-P2-DT/ B7209-E-P2-DT 32.00 KN 23.60 KN 45 mm 0.41 kg 85 mm 19 mm
6777 HCB7209-E-T-P4S/ HCB7209-E-T-P4S 23.20 KN 12.20 KN 45 mm 0.34 kg 85 mm 19 mm
6778 HCB7209-C-T-P4S/ HCB7209-C-T-P4S 23.20 KN 12.20 KN 45 mm 0.34 kg 85 mm 19 mm
6779 HCB7209-C-DLR-T-P4S/ HCB7209-C-DLR-T-P4S 23.20 KN 12.20 KN 45 mm 0.34 kg 85 mm 19 mm
6780 HCB7209-E-DLR-T-P4S/ HCB7209-E-DLR-T-P4S 23.20 KN 12.20 KN 45 mm 0.34 kg 85 mm 19 mm
6781 HCB7209-E-P2-DB/ HCB7209-E-P2-DB 22.00 KN 11.60 KN 45 mm 0.34 kg 85 mm 19 mm
6782 HCB7209-C-P2-DT-L/ HCB7209-C-P2-DT-L 22.00 KN 11.60 KN 45 mm 0.34 kg 85 mm 19 mm
6783 B71810-C-P2-DB/ B71810-C-P2-DB 7.35 KN 7.35 KN 50 mm 0.05 kg 65 mm 7 mm
6784 B71810-C-TPA-P4/ B71810-C-TPA-P4 7.35 KN 7.35 KN 50 mm 0.05 kg 65 mm 7 mm
6785 B71810-E-TPA-P4/ B71810-E-TPA-P4 7.35 KN 7.35 KN 50 mm 0.05 kg 65 mm 7 mm
6786 B71810-E-P2-DB-L/ B71810-E-P2-DB-L 6.95 KN 6.80 KN 50 mm 0.05 kg 65 mm 7 mm
6787 B71810-E-P2-DT/ B71810-E-P2-DT 6.95 KN 6.80 KN 50 mm 0.05 kg 65 mm 7 mm
6788 HCB71810-C-TPA-P4/ HCB71810-C-TPA-P4 5.10 KN 5.10 KN 50 mm 0.05 kg 65 mm 7 mm
6789 HCB71810-E-TPA-P4/ HCB71810-E-TPA-P4 5.10 KN 5.10 KN 50 mm 0.05 kg 65 mm 7 mm
6790 HCB71810-E-DLR-TPA-P4/ HCB71810-E-DLR-TPA-P4 5.10 KN 5.10 KN 50 mm 0.05 kg 65 mm 7 mm
6791 HCB71810-E-P2-DB/ HCB71810-E-P2-DB 4.80 KN 4.75 KN 50 mm 0.05 kg 65 mm 7 mm
6792 HCB71810-C-P2-DT-L/ HCB71810-C-P2-DT-L 4.80 KN 4.75 KN 50 mm 0.05 kg 65 mm 7 mm
6793 B71910-C-P2-DB/ B71910-C-P2-DB 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6794 B71910-E-P2-DB-L/ B71910-E-P2-DB-L 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6795 B71910-E-P2-DT/ B71910-E-P2-DT 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6796 71910 71910 ACE/HCP2 12.10 KN 8.15KN 50 mm 0.13 kg 72 mm 12 mm
6797 B71910-C-T-P4S/ B71910-C-T-P4S 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6798 B71910-E-T-P4S/ B71910-E-T-P4S 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6799 B71910-C-DLR-T-P4S/ B71910-C-DLR-T-P4S 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6800 B71910-E-DLR-T-P4S/ B71910-E-DLR-T-P4S 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
