Spindle bearings

Image may differ from product. See technical specification for details.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM,Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Package

DB, DF, DT, DBD, DBB, SU

Pairing method

DB, DF, DT, DBD, DBB, SU

Spindle bearings

Filters

NO. Product Product Number Basic dynamic load rating Basic static load rating Inner diameter (d) Mass Outer diameter (D) Width (B)
6801 HC71910-C-DLR-T-P4S/ HC71910-C-DLR-T-P4S 19.00 KN 16.60 KN 50 mm 0.13 kg 72 mm 12 mm
6802 HCB71910-E-P2-DB/ HCB71910-E-P2-DB 12.20 KN 11.00 KN 50 mm 0.11 kg 72 mm 12 mm
6803 HCB71910-C-P2-DT-L/ HCB71910-C-P2-DT-L 12.20 KN 11.00 KN 50 mm 0.11 kg 72 mm 12 mm
6804 HCB71910-C-T-P4S/ HCB71910-C-T-P4S 13.20 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6805 HCB71910-E-T-P4S/ HCB71910-E-T-P4S 13.20 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6806 HCB71910-C-DLR-T-P4S/ HCB71910-C-DLR-T-P4S 13.20 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6807 HCB71910-E-DLR-T-P4S/ HCB71910-E-DLR-T-P4S 13.20 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6808 XCB71910-C-P2-DB-M/ XCB71910-C-P2-DB-M 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6809 XC71910-C-P2-DB-M/ XC71910-C-P2-DB-M 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6810 XCB71910-C-P2-DT/ XCB71910-C-P2-DT 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6811 XCB71910-E-P2-DT-M/ XCB71910-E-P2-DT-M 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6812 XC71910-C-P2-DT/ XC71910-C-P2-DT 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6813 XC71910-E-P2-DT-M/ XC71910-E-P2-DT-M 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6814 XC71910-C-P2-H/ XC71910-C-P2-H 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6815 XCB71910-C-T-P4S/ XCB71910-C-T-P4S 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6816 XCB71910-E-T-P4S/ XCB71910-E-T-P4S 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6817 XCB71910-E-DLR-T-P4S/ XCB71910-E-DLR-T-P4S 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6818 XCB71910-C-DLR-T-P4S/ XCB71910-C-DLR-T-P4S 29.00 KN 11.60 KN 50 mm 0.11 kg 72 mm 12 mm
6819 XCB71910-E-P2-DB/ XCB71910-E-P2-DB 27.00 KN 11.00 KN 50 mm 0.11 kg 72 mm 12 mm
6820 HS71910-C-P2-DB-H/ HS71910-C-P2-DB-H 10.40 KN 10.20 KN 50 mm 0.15 kg 72 mm 12 mm
6821 HS71910-C-T-P4S/ HS71910-C-T-P4S 10.40 KN 10.20 KN 50 mm 0.15 kg 72 mm 12 mm
6822 HS71910-C-DLR-T-P4S/ HS71910-C-DLR-T-P4S 10.40 KN 10.20 KN 50 mm 0.15 kg 72 mm 12 mm
6823 B7010-E-P2-DB-L/ B7010-E-P2-DB-L 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6824 B7010-C-P2-DB/ B7010-C-P2-DB 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6825 B7010-E-P2-DT/ B7010-E-P2-DT 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6826 B7010-C-T-P4S/ B7010-C-T-P4S 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6827 B7010-E-T-P4S/ B7010-E-T-P4S 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6828 B7010-C-DLR-T-P4S/ B7010-C-DLR-T-P4S 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6829 B7010-E-DLR-T-P4S/ B7010-E-DLR-T-P4S 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6830 HC7010-C-DLR-T-P4S/ HC7010-C-DLR-T-P4S 28.50 KN 22.80 KN 50 mm 0.25 kg 80 mm 16 mm
6831 HCB7010-C-T-P4S/ HCB7010-C-T-P4S 19.60 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6832 HCB7010-E-T-P4S/ HCB7010-E-T-P4S 19.60 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6833 HCB7010-C-DLR-T-P4S/ HCB7010-C-DLR-T-P4S 19.60 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6834 HCB7010-E-DLR-T-P4S/ HCB7010-E-DLR-T-P4S 19.60 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6835 HCB7010-E-P2-DB/ HCB7010-E-P2-DB 18.60 KN 15.30 KN 50 mm 0.21 kg 80 mm 16 mm
6836 HCB7010-C-P2-DT-L/ HCB7010-C-P2-DT-L 18.60 KN 15.30 KN 50 mm 0.21 kg 80 mm 16 mm
6837 XCB7010-C-P2-DB-M/ XCB7010-C-P2-DB-M 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6838 XC7010-C-P2-DB-M/ XC7010-C-P2-DB-M 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6839 XCB7010-C-P2-DT/ XCB7010-C-P2-DT 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6840 XC7010-E-P2-DT-M/ XC7010-E-P2-DT-M 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6841 XC7010-C-P2-DT/ XC7010-C-P2-DT 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6842 XCB7010-E-P2-DT-M/ XCB7010-E-P2-DT-M 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6843 XC7010-C-P2-H/ XC7010-C-P2-H 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6844 XCB7010-C-T-P4S/ XCB7010-C-T-P4S 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6845 XCB7010-C-DLR-T-P4S/ XCB7010-C-DLR-T-P4S 44.00 KN 16.00 KN 50 mm 0.21 kg 80 mm 16 mm
6846 XCB7010-E-P2-DB/ XCB7010-E-P2-DB 41.50 KN 15.30 KN 50 mm 0.21 kg 80 mm 16 mm
6847 XCB7010-E-T-P4S/ XCB7010-E-T-P4S 41.50 KN 15.30 KN 50 mm 0.21 kg 80 mm 16 mm
6848 XCB7010-E-DLR-T-P4S/ XCB7010-E-DLR-T-P4S 41.50 KN 15.30 KN 50 mm 0.21 kg 80 mm 16 mm
6849 HS7010-C-P2-DB-H/ HS7010-C-P2-DB-H 13.40 KN 13.20 KN 50 mm 0.29 kg 80 mm 16 mm
6850 HS7010-C-T-P4S/ HS7010-C-T-P4S 13.40 KN 13.20 KN 50 mm 0.29 kg 80 mm 16 mm
6851 HS7010-C-DLR-T-P4S/ HS7010-C-DLR-T-P4S 13.40 KN 13.20 KN 50 mm 0.29 kg 80 mm 16 mm
6852 B7210-C-P2-DB/ B7210-C-P2-DB 43.00 KN 31.50 KN 50 mm 0.46 kg 90 mm 20 mm
6853 B7210-C-T-P4S/ B7210-C-T-P4S 43.00 KN 31.50 KN 50 mm 0.46 kg 90 mm 20 mm
6854 B7210-E-T-P4S/ B7210-E-T-P4S 43.00 KN 31.50 KN 50 mm 0.46 kg 90 mm 20 mm
6855 B7210-C-DLR-T-P4S/ B7210-C-DLR-T-P4S 43.00 KN 31.50 KN 50 mm 0.46 kg 90 mm 20 mm
6856 B7210-E-DLR-T-P4S/ B7210-E-DLR-T-P4S 43.00 KN 31.50 KN 50 mm 0.46 kg 90 mm 20 mm
6857 B7210-E-P2-DB-L/ B7210-E-P2-DB-L 40.50 KN 30.50 KN 50 mm 0.46 kg 90 mm 20 mm
6858 B7210-E-P2-DT/ B7210-E-P2-DT 40.50 KN 30.50 KN 50 mm 0.46 kg 90 mm 20 mm
6859 HCB7210-E-P2-DB/ HCB7210-E-P2-DB 30.00 KN 22.00 KN 50 mm 0.39 kg 90 mm 20 mm
6860 HCB7210-C-P2-DT-L/ HCB7210-C-P2-DT-L 30.00 KN 22.00 KN 50 mm 0.39 kg 90 mm 20 mm
6861 HCB7210-C-T-P4S/ HCB7210-C-T-P4S 30.00 KN 22.00 KN 50 mm 0.39 kg 90 mm 20 mm
6862 HCB7210-E-T-P4S/ HCB7210-E-T-P4S 30.00 KN 22.00 KN 50 mm 0.39 kg 90 mm 20 mm
6863 HCB7210-C-DLR-T-P4S/ HCB7210-C-DLR-T-P4S 30.00 KN 22.00 KN 50 mm 0.39 kg 90 mm 20 mm
6864 HCB7210-E-DLR-T-P4S/ HCB7210-E-DLR-T-P4S 30.00 KN 22.00 KN 50 mm 0.39 kg 90 mm 20 mm
6865 B71811-C-P2-DB/ B71811-C-P2-DB 10.20 KN 10.20 KN 55 mm 0.08 kg 72 mm 9 mm
6866 B71811-C-TPA-P4/ B71811-C-TPA-P4 10.20 KN 10.20 KN 55 mm 0.08 kg 72 mm 9 mm
6867 B71811-E-P2-DB-L/ B71811-E-P2-DB-L 9.65 KN 9.50 KN 55 mm 0.08 kg 72 mm 9 mm
6868 B71811-E-P2-DT/ B71811-E-P2-DT 9.65 KN 9.50 KN 55 mm 0.08 kg 72 mm 9 mm
6869 B71811-E-TPA-P4/ B71811-E-TPA-P4 9.65 KN 9.50 KN 55 mm 0.08 kg 72 mm 9 mm
6870 HCB71811-E-TPA-P4/ HCB71811-E-TPA-P4 6.70 KN 6.70 KN 55 mm 0.08 kg 72 mm 9 mm
6871 HCB71811-C-TPA-P4/ HCB71811-C-TPA-P4 7.10 KN 7.20 KN 55 mm 0.08 kg 72 mm 9 mm
6872 HCB71811-E-DLR-TPA-P4/ HCB71811-E-DLR-TPA-P4 6.70 KN 6.70 KN 55 mm 0.08 kg 72 mm 9 mm
6873 HCB71811-E-P2-DB/ HCB71811-E-P2-DB 6.70 KN 6.70 KN 55 mm 0.08 kg 72 mm 9 mm
6874 HCB71811-C-P2-DT-L/ HCB71811-C-P2-DT-L 6.70 KN 6.70 KN 55 mm 0.08 kg 72 mm 9 mm
6875 B71911-C-P2-DB/ B71911-C-P2-DB 22.80 KN 20.40 KN 55 mm 0.18 kg 80 mm 13 mm
6876 B71911-E-P2-DB-L/ B71911-E-P2-DB-L 22.80 KN 20.40 KN 55 mm 0.18 kg 80 mm 13 mm
6877 B71911-E-P2-DT/ B71911-E-P2-DT 22.80 KN 20.40 KN 55 mm 0.18 kg 80 mm 13 mm
6878 71911ACE/HCP2/ 71911ACE/HCP2 14.60 KN 10.20 KN 55 mm 0.17 kg 80 mm 13 mm
6879 71911ACE/P2H1DF/ 71911ACE/P2H1DF 14.60 KN 10.20 KN 55 mm 0.17 kg 80 mm 13 mm
6880 XCB71911-E-T-P4S/ XCB71911-E-T-P4S 35.50 KN 13.40 KN 55 mm 0.15 kg 80 mm 13 mm
6881 XCB71911-C-T-P4S/ XCB71911-C-T-P4S 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6882 B71911-C-T-P4S/ B71911-C-T-P4S 22.80 KN 20.40 KN 55 mm 0.18 kg 80 mm 13 mm
6883 B71911-E-T-P4S/ B71911-E-T-P4S 21.60 KN 19.30 KN 55 mm 0.18 kg 80 mm 13 mm
6884 HCB71911-E-T-P4S/ HCB71911-E-T-P4S 15.00 KN 13.40 KN 55 mm 0.15 kg 80 mm 13 mm
6885 HCB71911-E-DLR-T-P4S/ HCB71911-E-DLR-T-P4S 16.00 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6886 B71911-C-DLR-T-P4S/ B71911-C-DLR-T-P4S 22.80 KN 20.40 KN 55 mm 0.18 kg 80 mm 13 mm
6887 XCB71911-E-DLR-T-P4S/ XCB71911-E-DLR-T-P4S 35.50 KN 13.40 KN 55 mm 0.15 kg 80 mm 13 mm
6888 B71911-E-DLR-T-P4S/ B71911-E-DLR-T-P4S 21.60 KN 19.30 KN 55 mm 0.18 kg 80 mm 13 mm
6889 XCB71911-C-DLR-T-P4S/ XCB71911-C-DLR-T-P4S 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6890 HC71911-C-DLR-T-P4S/ HC71911-C-DLR-T-P4S 22.80 KN 20.40 KN 55 mm 0.18 kg 80 mm 13 mm
6891 HCB71911-C-T-P4S/ HCB71911-C-T-P4S 16.00 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6892 HCB71911-C-DLR-T-P4S/ HCB71911-C-DLR-T-P4S 16.00 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6893 HCB71911-E-P2-DB/ HCB71911-E-P2-DB 15.00 KN 13.40 KN 55 mm 0.15 kg 80 mm 13 mm
6894 HCB71911-C-P2-DT-L/ HCB71911-C-P2-DT-L 15.00 KN 13.40 KN 55 mm 0.15 kg 80 mm 13 mm
6895 XCB71911-C-P2-DB-M/ XCB71911-C-P2-DB-M 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6896 XC71911-C-P2-DB-M/ XC71911-C-P2-DB-M 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6897 XC71911-E-P2-DT-M/ XC71911-E-P2-DT-M 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6898 XC71911-C-P2-DT/ XC71911-C-P2-DT 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6899 XC71911-C-P2-H/ XC71911-C-P2-H 35.50 KN 14.30 KN 55 mm 0.15 kg 80 mm 13 mm
6900 XC71911-C-T-P4S/ XC71911-C-T-P4S 20.8 KN 9.5 KN 55 mm 0.19 kg 80 mm 13 mm
