Spindle bearings

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM,Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Package

DB, DF, DT, DBD, DBB, SU

Pairing method

DB, DF, DT, DBD, DBB, SU

Spindle bearings

Filters

NO. Product Product Number Inner diameter (d) Outer diameter (D) Width (B) Basic dynamic load rating Basic static load rating Mass
9401 HCB7014-C-T-P4S/ HCB7014-C-T-P4S 70 mm 110 mm 20 mm 34.00 KN 30.00 KN 0.50 kg
9402 HCB7014-E-P4S-U/ HCB7014-E-P4S-U 70 mm 110 mm 20 mm 32.50 KN 29.00 KN 0.50 kg
9403 HCB7014-E-T-P4S/ HCB7014-E-T-P4S 70 mm 110 mm 20 mm 32.50 KN 29.00 KN 0.50 kg
9404 HCB7014-EDLR-T-P4S/ HCB7014-EDLR-T-P4S 70 mm 110 mm 20 mm 32.50 KN 29.00 KN 0.50 kg
9405 XC7014-C-P2-DB-M/ XC7014-C-P2-DB-M 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9406 XC7014-C-P2-DT/ XC7014-C-P2-DT 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9407 XC7014-C-P2-H/ XC7014-C-P2-H 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9408 XC7014-C-P4S-DB/ XC7014-C-P4S-DB 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9409 XC7014-C-P4S-DF/ XC7014-C-P4S-DF 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9410 XC7014-C-P4S-U/ XC7014-C-P4S-U 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9411 XC7014-C-T-P4S/ XC7014-C-T-P4S 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9412 XC7014-CDLR-T-P4S/ XC7014-CDLR-T-P4S 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9413 XC7014-CDLR-TX-P2/ XC7014-CDLR-TX-P2 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9414 XC7014-E-P2-DT-M/ XC7014-E-P2-DT-M 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9415 XC7014-E-P4S-DB/ XC7014-E-P4S-DB 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9416 XC7014-E-P4S-DF/ XC7014-E-P4S-DF 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9417 XCB7014-C-P2-DB-M/ XCB7014-C-P2-DB-M 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9418 XCB7014-C-P2-DT/ XCB7014-C-P2-DT 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9419 XCB7014-C-P4S-DB/ XCB7014-C-P4S-DB 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9420 XCB7014-C-P4S-DF/ XCB7014-C-P4S-DF 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9421 XCB7014-C-P4S-U/ XCB7014-C-P4S-U 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9422 XCB7014-C-T-P4S/ XCB7014-C-T-P4S 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9423 XCB7014-CDLR-T-P4S/ XCB7014-CDLR-T-P4S 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9424 XCB7014-E-P2-DT-M/ XCB7014-E-P2-DT-M 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9425 XCB7014-E-P4S-DF/ XCB7014-E-P4S-DF 70 mm 110 mm 20 mm 76.50 KN 30.00 KN 0.50 kg
9426 B7014-E-P4S-DF/ B7014-E-P4S-DF 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9427 B7014-E-P4S-U/ B7014-E-P4S-U 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9428 B7014-E-T-P4S/ B7014-E-T-P4S 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9429 B7014-EDLR-T-P4S/ B7014-EDLR-T-P4S 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9430 XCB7014-CDLR-TX-P2/ XCB7014-CDLR-TX-P2 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9431 XCB7014-E-P2-DB/ XCB7014-E-P2-DB 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9432 XCB7014-E-P4S-DB/ XCB7014-E-P4S-DB 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9433 XCB7014-E-P4S-U/ XCB7014-E-P4S-U 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9434 XCB7014-E-T-P4S/ XCB7014-E-T-P4S 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9435 XCB7014-EDLR-T-P4S/ XCB7014-EDLR-T-P4S 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9436 XCB7014-EDLR-TX-P2/ XCB7014-EDLR-TX-P2 70 mm 110 mm 20 mm 72.00 KN 29.00 KN 0.50 kg
9437 HS7014-C-DLR-T-P4S/ HS7014-C-DLR-T-P4S 70 mm 110 mm 20 mm 26.00 KN 28.00 KN 0.67 kg
9438 HS7014-C-P2-DB-H/ HS7014-C-P2-DB-H 70 mm 110 mm 20 mm 26.00 KN 28.00 KN 0.67 kg
9439 HS7014-C-T-P4S/ HS7014-C-T-P4S 70 mm 110 mm 20 mm 26.00 KN 28.00 KN 0.67 kg
9440 HS7014-C-T-P4S-DF/ HS7014-C-T-P4S-DF 70 mm 110 mm 20 mm 26.00 KN 28.00 KN 0.67 kg
9441 HS7014-E-T-P4S-DF/ HS7014-E-T-P4S-DF 70 mm 110 mm 20 mm 26.00 KN 28.00 KN 0.67 kg
9442 B7214-E-P2-DB-L/ B7214-E-P2-DB-L 70 mm 125 mm 24 mm 65.50 KN 56.00 KN 1.12 kg
9443 B7214-E-P2-DT/ B7214-E-P2-DT 70 mm 125 mm 24 mm 65.50 KN 56.00 KN 1.12 kg
9444 B7214-E-P4S-DF/ B7214-E-P4S-DF 70 mm 125 mm 24 mm 65.50 KN 56.00 KN 1.12 kg
9445 B7214-E-P4S-U/ B7214-E-P4S-U 70 mm 125 mm 24 mm 65.50 KN 56.00 KN 1.12 kg
9446 B7214-E-T-P4S/ B7214-E-T-P4S 70 mm 125 mm 24 mm 65.50 KN 56.00 KN 1.12 kg
9447 B7214-EDLR-T-P4S/ B7214-EDLR-T-P4S 70 mm 125 mm 24 mm 65.50 KN 56.00 KN 1.12 kg
9448 HC7214-C-P2-DB-L/ HC7214-C-P2-DB-L 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9449 HCB7214-C-DLR-T-P4S/ HCB7214-C-DLR-T-P4S 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9450 HCB7214-C-P2-DT-L/ HCB7214-C-P2-DT-L 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9451 HCB7214-C-P4S-U/ HCB7214-C-P4S-U 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9452 HCB7214-C-T-P4S/ HCB7214-C-T-P4S 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9453 HCB7214-E-P2-DB/ HCB7214-E-P2-DB 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9454 HCB7214-E-P4S-U/ HCB7214-E-P4S-U 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9455 HCB7214-E-T-P4S/ HCB7214-E-T-P4S 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9456 HCB7214-EDLR-T-P4S/ HCB7214-EDLR-T-P4S 70 mm 125 mm 24 mm 45.50 KN 39.00 KN 0.96 kg
9457 B71815-C-P2-DB/ B71815-C-P2-DB 75 mm 95 mm 10 mm 14.30 KN 15.60 KN 0.14 kg
9458 B71815-C-TPA-P4/ B71815-C-TPA-P4 75 mm 95 mm 10 mm 14.30 KN 15.60 KN 0.14 kg
9459 B71815-CDLR-TX-P2/ B71815-CDLR-TX-P2 75 mm 95 mm 10 mm 14.30 KN 15.60 KN 0.14 kg
9460 B71815-EDLR-TX-P2/ B71815-EDLR-TX-P2 75 mm 95 mm 10 mm 14.30 KN 15.60 KN 0.14 kg
9461 B71815-E-P2-DB-L/ B71815-E-P2-DB-L 75 mm 95 mm 10 mm 13.40 KN 14.60 KN 0.14 kg
9462 B71815-E-P2-DT/ B71815-E-P2-DT 75 mm 95 mm 10 mm 13.40 KN 14.60 KN 0.14 kg
9463 B71815-E-P4S-U/ B71815-E-P4S-U 75 mm 95 mm 10 mm 13.40 KN 14.60 KN 0.14 kg
9464 B71815-E-TPA-P4/ B71815-E-TPA-P4 75 mm 95 mm 10 mm 13.40 KN 14.60 KN 0.14 kg
9465 HC71815-C-P2-DB-L/ HC71815-C-P2-DB-L 75 mm 95 mm 10 mm 9.30 KN 10.20 KN 0.14 kg
9466 HCB71815-C-P2-DT-L/ HCB71815-C-P2-DT-L 75 mm 95 mm 10 mm 9.30 KN 10.20 KN 0.14 kg
9467 HCB71815-C-TPA-P4/ HCB71815-C-TPA-P4 75 mm 95 mm 10 mm 9.80 KN 11.00 KN 0.14 kg
9468 HCB71815-E-P2-DB/ HCB71815-E-P2-DB 75 mm 95 mm 10 mm 9.30 KN 10.20 KN 0.14 kg
9469 HCB71815-E-P4-U/ HCB71815-E-P4-U 75 mm 95 mm 10 mm 9.30 KN 10.20 KN 0.14 kg
9470 HCB71815-E-TPA-P4/ HCB71815-E-TPA-P4 75 mm 95 mm 10 mm 9.30 KN 10.20 KN 0.14 kg
9471 HCB71815-EDLR-TPA-P4/ HCB71815-EDLR-TPA-P4 75 mm 95 mm 10 mm 9.30 KN 10.20 KN 0.14 kg
9472 B71915-C-P2-DB/ B71915-C-P2-DB 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9473 B71915-C-P4S-DB/ B71915-C-P4S-DB 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9474 B71915-C-P4S-DF/ B71915-C-P4S-DF 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9475 B71915-C-P4S-U/ B71915-C-P4S-U 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9476 B71915-C-T-P4S/ B71915-C-T-P4S 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9477 B71915-CDLR-T-P4S/ B71915-CDLR-T-P4S 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9478 B71915-CDLR-TX-P2/ B71915-CDLR-TX-P2 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9479 B71915-E-P2-DB-L/ B71915-E-P2-DB-L 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9480 B71915-E-P2-DT/ B71915-E-P2-DT 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9481 B71915-E-P4S-DF/ B71915-E-P4S-DF 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9482 B71915-E-P4S-U/ B71915-E-P4S-U 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9483 B71915-E-T-P4S/ B71915-E-T-P4S 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9484 B71915-EDLR-T-P4S/ B71915-EDLR-T-P4S 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9485 B71915-EDLR-TX-P2/ B71915-EDLR-TX-P2 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9486 HC71915-CDLR-T-P4S/ HC71915-CDLR-T-P4S 75 mm 105 mm 16 mm 34.00 KN 34.50 KN 0.35 kg
9487 71915 71915 ACE/HCP2 75 mm 105 mm 16 mm 21.20 KN 16.30 KN 0.34 kg
9488 HCB71915-C-DLR-T-P4S/ HCB71915-C-DLR-T-P4S 75 mm 105 mm 16 mm 23.60 KN 24.00 KN 0.30 kg
9489 HCB71915-C-P4S-U/ HCB71915-C-P4S-U 75 mm 105 mm 16 mm 23.60 KN 24.00 KN 0.30 kg
9490 HCB71915-C-T-P4S/ HCB71915-C-T-P4S 75 mm 105 mm 16 mm 23.60 KN 24.00 KN 0.30 kg
9491 HCB71915-C-P2-DT-L/ HCB71915-C-P2-DT-L 75 mm 105 mm 16 mm 22.00 KN 22.80 KN 0.30 kg
9492 HCB71915-E-P2-DB/ HCB71915-E-P2-DB 75 mm 105 mm 16 mm 22.00 KN 22.80 KN 0.30 kg
9493 XC71915-C-P2-DB-M/ XC71915-C-P2-DB-M 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9494 XC71915-C-P2-DT/ XC71915-C-P2-DT 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9495 XC71915-C-P2-H/ XC71915-C-P2-H 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9496 XC71915-C-P4S-DB/ XC71915-C-P4S-DB 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9497 XC71915-C-P4S-DF/ XC71915-C-P4S-DF 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9498 XC71915-C-T-P4S/ XC71915-C-T-P4S 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9499 XC71915-CDLR-T-P4S/ XC71915-CDLR-T-P4S 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
9500 XC71915-CDLR-TX-P2/ XC71915-CDLR-TX-P2 75 mm 105 mm 16 mm 53.00 KN 24.00 KN 0.30 kg
