Ceramic Balls

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Material

Alumina, Silicon Nitride, Silicon Carbide, Zirconia, Boron Nitride

Nominal diameter (Dw)

0.3mm-114.3mm

Hardness

70-90HRC

Density

3.1-6g/cm3

Ceramic Balls

Filters

NO. Product Product Number Nominal diameter (Dw) Mass Material Density Hardness
201 Silicon Silicon Nitride Ceramic Ball 31/32inch 0.96875 inch 24.96232 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
202 Silicon Silicon Nitride Ceramic Ball 32mm 32 mm 54.90331 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
203 Silicon Silicon Nitride Ceramic Ball 34mm 34 mm 65.85448 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
204 Silicon Silicon Nitride Ceramic Ball 35mm 35 mm 71.83775 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
205 Silicon Silicon Nitride Ceramic Ball 36mm 36 mm 78.17288 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
206 Silicon Silicon Nitride Ceramic Ball 38mm 38 mm 91.93892 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
207 Silicon Silicon Nitride Ceramic Ball 3inch 3.00000 inch 741.33330 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
208 Silicon Silicon Nitride Ceramic Ball 3mm 3 mm 0.04524 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
209 Silicon Silicon Nitride Ceramic Ball 4 1/4inch 4.25000 inch 2107.73755 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
210 Silicon Silicon Nitride Ceramic Ball 4.5mm 4.5 mm 0.15268 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
211 Silicon Silicon Nitride Ceramic Ball 40mm 40 mm 107.23303 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
212 Silicon Silicon Nitride Ceramic Ball 45mm 45 mm 152.68140 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
213 Silicon Silicon Nitride Ceramic Ball 4inch 4.00000 inch 1757.23448 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
214 Silicon Silicon Nitride Ceramic Ball 4mm 4 mm 0.10723 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
215 Silicon Silicon Nitride Ceramic Ball 5.5mm 5.5 mm 0.27876 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
216 Silicon Silicon Nitride Ceramic Ball 5/16inch 0.31250 inch 0.83791 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
217 Silicon Silicon Nitride Ceramic Ball 5/32inch 0.15625 inch 0.10474 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
218 Silicon Silicon Nitride Ceramic Ball 5/64inch 0.07812 inch 0.01309 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
219 Silicon Silicon Nitride Ceramic Ball 5/8inch 0.62500 inch 6.70332 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
220 Silicon Silicon Nitride Ceramic Ball 50mm 50 mm 209.43951 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
221 Silicon Silicon Nitride Ceramic Ball 55mm 55 mm 278.76398 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
222 Silicon Silicon Nitride Ceramic Ball 5mm 5 mm 0.20944 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
223 Silicon Silicon Nitride Ceramic Ball 6.5mm 6.5 mm 0.46014 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
224 Silicon Silicon Nitride Ceramic Ball 60mm 60 mm 361.91147 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
225 Silicon Silicon Nitride Ceramic Ball 65mm 65 mm 460.13860 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
226 Silicon Silicon Nitride Ceramic Ball 6mm 6 mm 0.36191 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
227 Silicon Silicon Nitride Ceramic Ball 7.5mm 7.5 mm 0.70686 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
228 Silicon Silicon Nitride Ceramic Ball 7/16inch 0.43750 inch 2.29924 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
229 Silicon Silicon Nitride Ceramic Ball 7/32inch 0.21875 inch 0.28740 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
230 Silicon Silicon Nitride Ceramic Ball 7/64inch 0.10938 inch 0.03593 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
231 Silicon Silicon Nitride Ceramic Ball 7/8inch 0.87500 inch 18.39390 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
232 Silicon Silicon Nitride Ceramic Ball 7mm 7 mm 0.57470 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
233 Silicon Silicon Nitride Ceramic Ball 8.5mm 8.5 mm 1.02898 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
234 Silicon Silicon Nitride Ceramic Ball 8mm 8 mm 0.85786 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
235 Silicon Silicon Nitride Ceramic Ball 9/16inch 0.56250 inch 4.88672 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
236 Silicon Silicon Nitride Ceramic Ball 9/32inch 0.28125 inch 0.61084 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
237 Silicon Silicon Nitride Ceramic Ball 9/64inch 0.14062 inch 0.07635 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
238 Silicon Silicon Nitride Ceramic Ball 9mm 9 mm 1.22145 g Silicon Nitride 3.20-3.30 g/cm3 75-80 HRC
239 Silicon Silicon Carbide Ceramic Ball 1 1/16inch 1.06250 inch 31.90423 g Silicon Carbide 3.10 g/cm3 85-90 HRC
240 Silicon Silicon Carbide Ceramic Ball 1 1/2inch 1.50000 inch 89.77083 g Silicon Carbide 3.10 g/cm3 85-90 HRC
241 Silicon Silicon Carbide Ceramic Ball 1 1/4inch 1.25000 inch 51.95071 g Silicon Carbide 3.10 g/cm3 85-90 HRC
242 Silicon Silicon Carbide Ceramic Ball 1 1/8inch 1.12500 inch 37.87207 g Silicon Carbide 3.10 g/cm3 85-90 HRC
243 Silicon Silicon Carbide Ceramic Ball 1 11/16inch 1.68750 inch 127.81823 g Silicon Carbide 3.10 g/cm3 85-90 HRC
244 Silicon Silicon Carbide Ceramic Ball 1 13/16inch 1.81250 inch 158.37824 g Silicon Carbide 3.10 g/cm3 85-90 HRC
245 Silicon Silicon Carbide Ceramic Ball 1 15/16inch 1.93750 inch 193.45795 g Silicon Carbide 3.10 g/cm3 85-90 HRC
246 Silicon Silicon Carbide Ceramic Ball 1 3/16inch 1.18750 inch 44.54124 g Silicon Carbide 3.10 g/cm3 85-90 HRC
247 Silicon Silicon Carbide Ceramic Ball 1 3/4inch 1.75000 inch 142.55275 g Silicon Carbide 3.10 g/cm3 85-90 HRC
248 Silicon Silicon Carbide Ceramic Ball 1 3/8inch 1.37500 inch 69.14640 g Silicon Carbide 3.10 g/cm3 85-90 HRC
249 Silicon Silicon Carbide Ceramic Ball 1 5/16inch 1.31250 inch 60.13944 g Silicon Carbide 3.10 g/cm3 85-90 HRC
250 Silicon Silicon Carbide Ceramic Ball 1 5/8inch 1.62500 inch 114.13571 g Silicon Carbide 3.10 g/cm3 85-90 HRC
251 Silicon Silicon Carbide Ceramic Ball 1 7/16inch 1.43750 inch 79.01054 g Silicon Carbide 3.10 g/cm3 85-90 HRC
252 Silicon Silicon Carbide Ceramic Ball 1 7/8inch 1.87500 inch 175.33365 g Silicon Carbide 3.10 g/cm3 85-90 HRC
253 Silicon Silicon Carbide Ceramic Ball 1 9/16inch 1.56250 inch 101.46623 g Silicon Carbide 3.10 g/cm3 85-90 HRC
254 Silicon Silicon Carbide Ceramic Ball 1/16inch 0.06250 inch 0.00649 g Silicon Carbide 3.10 g/cm3 85-90 HRC
255 Silicon Silicon Carbide Ceramic Ball 1/2inch 0.50000 inch 3.32485 g Silicon Carbide 3.10 g/cm3 85-90 HRC
256 Silicon Silicon Carbide Ceramic Ball 1/32inch 0.03125 inch 0.00081 g Silicon Carbide 3.10 g/cm3 85-90 HRC
257 Silicon Silicon Carbide Ceramic Ball 1/40inch 0.02500 inch 0.00042 g Silicon Carbide 3.10 g/cm3 85-90 HRC
258 Silicon Silicon Carbide Ceramic Ball 1/4inch 0.25000 inch 0.41561 g Silicon Carbide 3.10 g/cm3 85-90 HRC
259 Silicon Silicon Carbide Ceramic Ball 1/8inch 0.12500 inch 0.05195 g Silicon Carbide 3.10 g/cm3 85-90 HRC
260 Silicon Silicon Carbide Ceramic Ball 11/16inch 0.68750 inch 8.64330 g Silicon Carbide 3.10 g/cm3 85-90 HRC
261 Silicon Silicon Carbide Ceramic Ball 11/32inch 0.34375 inch 1.08041 g Silicon Carbide 3.10 g/cm3 85-90 HRC
262 Silicon Silicon Carbide Ceramic Ball 13/16inch 0.81250 inch 14.26696 g Silicon Carbide 3.10 g/cm3 85-90 HRC
263 Silicon Silicon Carbide Ceramic Ball 13/32inch 0.40625 inch 1.78337 g Silicon Carbide 3.10 g/cm3 85-90 HRC
264 Silicon Silicon Carbide Ceramic Ball 15/16inch 0.93750 inch 21.91671 g Silicon Carbide 3.10 g/cm3 85-90 HRC
265 Silicon Silicon Carbide Ceramic Ball 15/32inch 0.46875 inch 2.73959 g Silicon Carbide 3.10 g/cm3 85-90 HRC
266 Silicon Silicon Carbide Ceramic Ball 15/64inch 0.23438 inch 0.34245 g Silicon Carbide 3.10 g/cm3 85-90 HRC
267 Silicon Silicon Carbide Ceramic Ball 17/32inch 0.53125 inch 3.98803 g Silicon Carbide 3.10 g/cm3 85-90 HRC
268 Silicon Silicon Carbide Ceramic Ball 17/64inch 0.26563 inch 0.49850 g Silicon Carbide 3.10 g/cm3 85-90 HRC
269 Silicon Silicon Carbide Ceramic Ball 19/32inch 0.59375 inch 5.56766 g Silicon Carbide 3.10 g/cm3 85-90 HRC
270 Silicon Silicon Carbide Ceramic Ball 1inch 1.00000 inch 26.59876 g Silicon Carbide 3.10 g/cm3 85-90 HRC
271 Silicon Silicon Carbide Ceramic Ball 2 1/2inch 2.50000 inch 415.60569 g Silicon Carbide 3.10 g/cm3 85-90 HRC
272 Silicon Silicon Carbide Ceramic Ball 2 1/4inch 2.25000 inch 302.97655 g Silicon Carbide 3.10 g/cm3 85-90 HRC
273 Silicon Silicon Carbide Ceramic Ball 2 1/8inch 2.12500 inch 255.23384 g Silicon Carbide 3.10 g/cm3 85-90 HRC
274 Silicon Silicon Carbide Ceramic Ball 2 3/4inch 2.75000 inch 553.17117 g Silicon Carbide 3.10 g/cm3 85-90 HRC
275 Silicon Silicon Carbide Ceramic Ball 2 3/8inch 2.37500 inch 356.32993 g Silicon Carbide 3.10 g/cm3 85-90 HRC
276 Silicon Silicon Carbide Ceramic Ball 2 5/8inch 2.62500 inch 481.11554 g Silicon Carbide 3.10 g/cm3 85-90 HRC
277 Silicon Silicon Carbide Ceramic Ball 2 7/8inch 2.87500 inch 632.08430 g Silicon Carbide 3.10 g/cm3 85-90 HRC
278 Silicon Silicon Carbide Ceramic Ball 21/32inch 0.65625 inch 7.51743 g Silicon Carbide 3.10 g/cm3 85-90 HRC
279 Silicon Silicon Carbide Ceramic Ball 23/32inch 0.71875 inch 9.87632 g Silicon Carbide 3.10 g/cm3 85-90 HRC
280 Silicon Silicon Carbide Ceramic Ball 25/32inch 0.78125 inch 12.68328 g Silicon Carbide 3.10 g/cm3 85-90 HRC
281 Silicon Silicon Carbide Ceramic Ball 27/32inch 0.84375 inch 15.97728 g Silicon Carbide 3.10 g/cm3 85-90 HRC
282 Silicon Silicon Carbide Ceramic Ball 29/32inch 0.90625 inch 19.79728 g Silicon Carbide 3.10 g/cm3 85-90 HRC
283 Silicon Silicon Carbide Ceramic Ball 2inch 2.00000 inch 212.79011 g Silicon Carbide 3.10 g/cm3 85-90 HRC
284 Silicon Silicon Carbide Ceramic Ball 3 1/2inch 3.50000 inch 1140.42201 g Silicon Carbide 3.10 g/cm3 85-90 HRC
285 Silicon Silicon Carbide Ceramic Ball 3 1/4inch 3.25000 inch 913.08570 g Silicon Carbide 3.10 g/cm3 85-90 HRC
286 Silicon Silicon Carbide Ceramic Ball 3 3/4inch 3.75000 inch 1402.66920 g Silicon Carbide 3.10 g/cm3 85-90 HRC
287 Silicon Silicon Carbide Ceramic Ball 3/16inch 0.18750 inch 0.17533 g Silicon Carbide 3.10 g/cm3 85-90 HRC
288 Silicon Silicon Carbide Ceramic Ball 3/32inch 0.09375 inch 0.02192 g Silicon Carbide 3.10 g/cm3 85-90 HRC
289 Silicon Silicon Carbide Ceramic Ball 3/4inch 0.75000 inch 11.22135 g Silicon Carbide 3.10 g/cm3 85-90 HRC
290 Silicon Silicon Carbide Ceramic Ball 3/64inch 0.04688 inch 0.00274 g Silicon Carbide 3.10 g/cm3 85-90 HRC
291 Silicon Silicon Carbide Ceramic Ball 3/8inch 0.37500 inch 1.40267 g Silicon Carbide 3.10 g/cm3 85-90 HRC
292 Silicon Silicon Carbide Ceramic Ball 31/32inch 0.96875 inch 24.18224 g Silicon Carbide 3.10 g/cm3 85-90 HRC
293 Silicon Silicon Carbide Ceramic Ball 3inch 3.00000 inch 718.16663 g Silicon Carbide 3.10 g/cm3 85-90 HRC
294 Silicon Silicon Carbide Ceramic Ball 4 1/4inch 4.25000 inch 2041.87075 g Silicon Carbide 3.10 g/cm3 85-90 HRC
295 Silicon Silicon Carbide Ceramic Ball 4inch 4.00000 inch 1702.32091 g Silicon Carbide 3.10 g/cm3 85-90 HRC
296 Silicon Silicon Carbide Ceramic Ball 5/16inch 0.31250 inch 0.81173 g Silicon Carbide 3.10 g/cm3 85-90 HRC
297 Silicon Silicon Carbide Ceramic Ball 5/32inch 0.15625 inch 0.10147 g Silicon Carbide 3.10 g/cm3 85-90 HRC
298 Silicon Silicon Carbide Ceramic Ball 5/64inch 0.07813 inch 0.01268 g Silicon Carbide 3.10 g/cm3 85-90 HRC
299 Silicon Silicon Carbide Ceramic Ball 5/8inch 0.62500 inch 6.49384 g Silicon Carbide 3.10 g/cm3 85-90 HRC
300 Silicon Silicon Carbide Ceramic Ball 7/16inch 0.43750 inch 2.22739 g Silicon Carbide 3.10 g/cm3 85-90 HRC

1. Application of Ceramic Balls


Ceramic balls have a wide range of applications in industry and daily life, mainly including:


Bearings: Ceramic balls are often used to manufacture various precision bearings, especially high-speed and high-load applications. Ceramic bearings have a lower coefficient of friction, higher corrosion resistance and high temperature resistance than steel ball bearings.

Grinding media: Ceramic balls can be used as grinding media during crushing and grinding. They are widely used in industries such as chemistry, pharmaceuticals, and mining, especially when high hardness and high wear resistance are required.

Seals: Ceramic balls are also widely used in the field of liquid and gas sealing, especially when resistance to high temperature or high corrosion environments is required.

Filtration: Some ceramic balls are used in filtration systems, especially in water treatment and waste gas treatment processes, where they can effectively remove impurities and particles.

Electronic components: In some high-tech fields, ceramic balls are used in the manufacture of high-precision electronic components such as sensors and capacitors.


2. Characteristics of ceramic balls

Strong wear resistance: Ceramic balls have very high hardness, which can effectively reduce wear and increase the service life of equipment.

Good corrosion resistance: Ceramic balls have strong corrosion resistance to chemicals such as acids, alkalis, and salts, and are suitable for extreme environments.

Good high temperature resistance: Ceramic materials can withstand higher temperatures than metals and are suitable for high temperature working environments.

Lightweight: Ceramic balls are usually lighter than metal balls, and can sometimes effectively reduce the weight of the overall structure, making them suitable for some applications that require lightweight.

Reduce friction: Ceramic balls usually have a lower coefficient of friction than metal balls, which is particularly important for some high-speed equipment.
