Ceramic Balls
QIBR
Model Selection
| NO. | Product | Product Number | Nominal diameter Dw | Mass (approx.) 10 000 pieces | Material | Density | Hardness |
|---|---|---|---|---|---|---|---|
| 301 |
|
Ceramic Ball 1 7/16inch G10 | 36.512 50mm | 1526kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 302 |
|
Ceramic Ball 38mm G10 | 38.000 00mm | 1720kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 303 |
|
Ceramic Ball 1 1/2inch G10 | 38.100 00mm | 1733kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 304 |
|
Ceramic Ball 1 9/16inch G10 | 39.687 50mm | 1959kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 305 |
|
Ceramic Ball 40mm G10 | 40.000 00mm | 2006kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 306 |
|
Ceramic Ball 1 5/8inch G10 | 41.275 00mm | 2204kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 307 |
|
Ceramic Ball 1 11/16inch G10 | 42.862 50mm | 2467kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 308 |
|
Ceramic Ball 1 3/4inch G10 | 44.450 00mm | 2752kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 309 |
|
Ceramic Ball 45mm G10 | 45.000 00mm | 2856kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 310 |
|
Ceramic Ball 1 13/16inch G10 | 46.037 50mm | 3057kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 311 |
|
Ceramic Ball 1 7/8inch G10 | 47.625 00mm | 3385kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 312 |
|
Ceramic Ball 1 15/16inch G10 | 49.212 50mm | 3735kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 313 |
|
Ceramic Ball 50mm G10 | 50.000 00mm | 3917kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 314 |
|
Ceramic Ball 2inch G10 | 50.800 00mm | 4108kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 315 |
|
Ceramic Ball 2 1/8inch G10 | 53.975 00mm | 4928kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 316 |
|
Ceramic Ball 55mm G10 | 55.000 00mm | 5214kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 317 |
|
Ceramic Ball 2 1/4inch G10 | 57.150 00mm | 5849kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 318 |
|
Ceramic Ball 60mm G10 | 60.000 00mm | 6769kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 319 |
|
Ceramic Ball 2 3/8inch G10 | 60.325 00mm | 6879kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 320 |
|
Ceramic Ball 2 1/2inch G10 | 63.500 00mm | 8025kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 321 |
|
Ceramic Ball 65mm G10 | 65.000 00mm | 8606kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 322 |
|
Ceramic Ball 2 5/8inch G10 | 66.675 00mm | 9287kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 323 |
|
Ceramic Ball 2 3/4inch G10 | 69.850 00mm | 10678kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 324 |
|
Ceramic Ball 2 7/8inch G10 | 73.025 00mm | 12206kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 325 |
|
Ceramic Ball 3inch G10 | 76.200 00mm | 13865kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 326 |
|
Ceramic Ball 3 1/4inch G10 | 82.550 00mm | 17625kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 327 |
|
Ceramic Ball 3 1/2inch G10 | 88.900 00mm | 22013kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 328 |
|
Ceramic Ball 3 3/4inch G10 | 95.250 00mm | 27080kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 329 |
|
Ceramic Ball 4inch G10 | 101.600 00mm | 32866kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 330 |
|
Ceramic Ball 4 1/4inch G10 | 107.950 00mm | 39417kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 331 |
|
Ceramic Ball 4 1/2inch G10 | 114.300 00mm | 46792kg | Zirconia | 6.00 g/cm3 | 70 HRC |
| 332 |
|
Ceramic Ball 0.3mm G10 | 0.300 00mm | 0.0006kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 333 |
|
Ceramic Ball 0.4mm G10 | 0.400 00mm | 0.0013kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 334 |
|
Ceramic Ball 0.5mm G10 | 0.500 00mm | 0.0026kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 335 |
|
Ceramic Ball 0.6mm G10 | 0.600 00mm | 0.0045kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 336 |
|
Ceramic Ball 0.025inch G10 | 0.635 00mm | 0.0053kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 337 |
|
Ceramic Ball 0.7mm G10 | 0.700 00mm | 0.0071kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 338 |
|
Ceramic Ball 1/32inch G10 | 0.793 75mm | 0.0103kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 339 |
|
Ceramic Ball 0.8mm G10 | 0.800 00mm | 0.0106kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 340 |
|
Ceramic Ball 1mm G10 | 1.000 00mm | 0.0206kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 341 |
|
Ceramic Ball 3/64inch G10 | 1.190 62mm | 0.0348kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 342 |
|
Ceramic Ball 1.2mm G10 | 1.200 00mm | 0.0356kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 343 |
|
Ceramic Ball 1.5mm G10 | 1.500 00mm | 0.0696kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 344 |
|
Ceramic Ball 1/16inch G10 | 1.587 50mm | 0.0825kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 345 |
|
Ceramic Ball 5/64inch G10 | 1.984 38mm | 0.1612kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 346 |
|
Ceramic Ball 2mm G10 | 2.000 00mm | 0.1650kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 347 |
|
Ceramic Ball 3/32inch G10 | 2.381 25mm | 0.2786kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 348 |
|
Ceramic Ball 2.5mm G10 | 2.500 00mm | 0.3223kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 349 |
|
Ceramic Ball 7/64inch G10 | 2.778 12mm | 0.4423kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 350 |
|
Ceramic Ball 2.8mm G10 | 2.800 00mm | 0.4529kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 351 |
|
Ceramic Ball 3mm G10 | 3.000 00mm | 0.5570kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 352 |
|
Ceramic Ball 1/8inch G10 | 3.175 00mm | 0.6602kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 353 |
|
Ceramic Ball 3.5mm G10 | 3.500 00mm | 0.8846kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 354 |
|
Ceramic Ball 9/64inch G10 | 3.571 88mm | 0.9399kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 355 |
|
Ceramic Ball 5/32inch G10 | 3.968 75mm | 1.290kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 356 |
|
Ceramic Ball 4mm G10 | 4.000 00mm | 1.320kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 357 |
|
Ceramic Ball 4.5mm G10 | 4.500 00mm | 1.880kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 358 |
|
Ceramic Ball 3/16inch G10 | 4.762 50 mm | 2.229kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 359 |
|
Ceramic Ball 5mm G10 | 5.000 00mm | 2.579kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 360 |
|
Ceramic Ball 5.5mm G10 | 5.500 00mm | 3.432kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 361 |
|
Ceramic Ball 7/32inch G10 | 5.556 25mm | 3.538kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 362 |
|
Ceramic Ball 15/64inch G10 | 5.953 12mm | 4.353kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 363 |
|
Ceramic Ball 6mm G10 | 6.000 00mm | 4.456kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 364 |
|
Ceramic Ball 1/4inch G10 | 6.350 00mm | 5.283kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 365 |
|
Ceramic Ball 6.5mm G10 | 6.500 00mm | 5.666kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 366 |
|
Ceramic Ball 17/64inch G10 | 6.746 88mm | 6.335kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 367 |
|
Ceramic Ball 7mm G10 | 7.000 00mm | 7.075kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 368 |
|
Ceramic Ball 9/32inch G10 | 7.143 75mm | 7.523kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 369 |
|
Ceramic Ball 7.5mm G10 | 7.500 00mm | 8.705kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 370 |
|
Ceramic Ball 5/16inch G10 | 7.937 50mm | 10.32kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 371 |
|
Ceramic Ball 8mm G10 | 8.000 00mm | 10.56kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 372 |
|
Ceramic Ball 8.5mm G10 | 8.500 00mm | 12.67kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 373 |
|
Ceramic Ball 11/32inch G10 | 8.731 25mm | 20.86kg | Alumina | 6.00 g/cm3 | 70 HRC |
| 374 |
|
Ceramic Ball 9mm G10 | 9.000 00mm | 15.04kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 375 |
|
Ceramic Ball 3/8inch G10 | 9.525 00mm | 17.83kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 376 |
|
Ceramic Ball 10mm G10 | 10.000 00mm | 20.63kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 377 |
|
Ceramic Ball 13/32inch G10 | 10.318 75mm | 22.66kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 378 |
|
Ceramic Ball 11mm G10 | 11.000 00mm | 27.46kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 379 |
|
Ceramic Ball 7/16inch G10 | 11.112 50mm | 28.31kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 380 |
|
Ceramic Ball 11.5mm G10 | 11.500 00mm | 31.37kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 381 |
|
Ceramic Ball 15/32inch G10 | 11.906 25mm | 34.82kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 382 |
|
Ceramic Ball 12mm G10 | 12.000 00mm | 35.65kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 383 |
|
Ceramic Ball 1/2inch G10 | 12.700 00mm | 42.26kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 384 |
|
Ceramic Ball 13mm G10 | 13.000 00mm | 45.32kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 385 |
|
Ceramic Ball 17/32inch G10 | 13.493 75mm | 50.67kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 386 |
|
Ceramic Ball 14mm G10 | 14.000 00mm | 56.61kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 387 |
|
Ceramic Ball 9/16inch G10 | 14.287 50mm | 60.18kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 388 |
|
Ceramic Ball 15mm G10 | 15.000 00mm | 69.64kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 389 |
|
Ceramic Ball 19/32inch G10 | 15.081 25mm | 70.75kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 390 |
|
Ceramic Ball 5/8inch G10 | 15.875 00mm | 82.52kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 391 |
|
Ceramic Ball 16mm G10 | 16.000 00mm | 84.48kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 392 |
|
Ceramic Ball 21/32inch G10 | 16.668 75mm | 95.55kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 393 |
|
Ceramic Ball 17mm G10 | 17.000 00mm | 101.34kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 394 |
|
Ceramic Ball 11/16inch G10 | 17.462 50mm | 109.85kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 395 |
|
Ceramic Ball 18mm G10 | 18.000 00mm | 120.31kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 396 |
|
Ceramic Ball 23/32inch G10 | 18.256 25mm | 125.54kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 397 |
|
Ceramic Ball 19mm G10 | 19.000 00mm | 141.50kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 398 |
|
Ceramic Ball 3/4inch G10 | 19.050 00mm | 142.60kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 399 |
|
Ceramic Ball 25/32inch G10 | 19.843 75mm | 161.22kg | Alumina | 3.95 g/cm3 | 80 HRC |
| 400 |
|
Ceramic Ball 20mm G10 | 20.000 00mm | 165.04kg | Alumina | 3.95 g/cm3 | 80 HRC |
