Plummer Bearing Units-Imperial

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

1 3/16~24inch

Applications

Agricultural Machinery, Mining & Construction Equipment, Conveying Systems, Paper & Printing Machinery,etc

Filters

NO. Product Product Number Bolt size Inner diameter (d) Length total (a) Distance shaft axis (H) MAX distance fixing bore (E) MIN distance fixing bore (E)
1 P01+01 P01+01 B 103 M12 1 3/16 inch 228 mm 60 mm 192 mm 172 mm
2 P01+01 P01+01 B 104 M12 1 1/4 inch 228 mm 60 mm 192 mm 172 mm
3 P01+01 P01+01 B 107 M12 1 7/16 inch 228 mm 60 mm 192 mm 172 mm
4 P01+01 P01+01 B 108 M12 1 1/2 inch 228 mm 60 mm 192 mm 172 mm
5 P02+01E P02+01E B 111 M16 1 11/16 inch 270 mm 70 mm 227 mm 203 mm
6 P02+01E P02+01E B 112 M16 1 3/4 inch 270 mm 70 mm 227 mm 203 mm
7 P02+01E P02+01E B 115 M16 1 15/16 inch 270 mm 70 mm 227 mm 203 mm
8 P03+02 P03+02 B 115 M16 1 15/16 inch 280 mm 80 mm 242 mm 226 mm
9 P02+01E P02+01E B 200 M16 2 inch 270 mm 70 mm 227 mm 203 mm
10 P03+02 P03+02 B 200 M16 2 inch 280 mm 80 mm 242 mm 226 mm
11 P03+01E P03+01E B 203 M16 2 3/16 inch 280 mm 80 mm 242 mm 226 mm
12 P04+02 P04+02 B 203 M20 2 3/16 inch 330 mm 95 mm 280 mm 260 mm
13 P03+01E P03+01E B 204 M16 2 1/4 inch 280 mm 80 mm 242 mm 226 mm
14 P04+02 P04+02 B 204 M20 2 1/4 inch 330 mm 95 mm 280 mm 260 mm
15 P03+01E P03+01E B 207 M16 2 7/16 inch 280 mm 80 mm 242 mm 226 mm
16 P04+02 P04+02 B 207 M20 2 7/16 inch 330 mm 95 mm 280 mm 260 mm
17 P03+01E P03+01E B 208 M16 2 1/2 inch 280 mm 80 mm 242 mm 226 mm
18 P04+02 P04+02 B 208 M20 2 1/2 inch 330 mm 95 mm 280 mm 260 mm
19 P04+01E P04+01E B 211 M20 2 11/16 inch 330 mm 95 mm 280 mm 260 mm
20 P05+02 P05+02 B 211 M24 2 11/16 inch 380 mm 112 mm 328 mm 312 mm
21 P04+01E P04+01E B 212 M20 2 3/4 inch 330 mm 95 mm 280 mm 260 mm
22 P05+02 P05+02 B 212 M24 2 3/4 inch 380 mm 112 mm 328 mm 312 mm
23 P03+100 P03+100 B 215 M16 2 15/16 inch 280 mm 80 mm 242 mm 226 mm
24 P04+01E P04+01E B 215 M20 2 15/16 inch 330 mm 95 mm 280 mm 260 mm
25 P05+02 P05+02 B 215 M24 2 15/16 inch 380 mm 112 mm 328 mm 312 mm
26 P03+100 P03+100 B 300 M16 3 inch 280 mm 80 mm 242 mm 226 mm
27 P04+01E P04+01E B 300 M20 3 inch 330 mm 95 mm 280 mm 260 mm
28 P05+02 P05+02 B 300 M24 3 inch 380 mm 112 mm 328 mm 312 mm
29 P05+01E P05+01E B 303 M24 3 3/16 inch 380 mm 112 mm 328 mm 312 mm
30 P06+02 P06+02 B 303 M24 3 3/16 inch 420 mm 125 mm 366 mm 342 mm
31 P05+01E P05+01E B 304 M24 3 1/4 inch 380 mm 112 mm 328 mm 312 mm
32 P06+02 P06+02 B 304 M24 3 1/4 inch 420 mm 125 mm 366 mm 342 mm
33 P04+100 P04+100 B 307 M20 3 7/16 inch 330 mm 95 mm 280 mm 260 mm
34 P05+01E P05+01E B 307 M24 3 7/16 inch 380 mm 112 mm 328 mm 312 mm
35 P06+02 P06+02 B 307 M24 3 7/16 inch 420 mm 125 mm 366 mm 342 mm
36 P05+01E P05+01E B 308 M24 3 1/2 inch 380 mm 112 mm 328 mm 312 mm
37 P06+02 P06+02 B 308 M24 3 1/2 inch 420 mm 125 mm 366 mm 342 mm
38 P06+01E P06+01E B 311 M24 3 11/16 inch 420 mm 125 mm 366 mm 342 mm
39 P07+02 P07+02 B 311 M24 3 11/16 inch 466 mm 143 mm 410 mm 374 mm
40 P06+01E P06+01E B 312 M24 3 3/4 inch 420 mm 125 mm 366 mm 342 mm
41 P07+02 P07+02 B 312 M24 3 3/4 inch 466 mm 143 mm 410 mm 374 mm
42 P05+100 P05+100 B 315 M24 3 15/16 inch 380 mm 112 mm 328 mm 312 mm
43 P06+01E P06+01E B 315 M24 3 15/16 inch 420 mm 125 mm 366 mm 342 mm
44 P07+02 P07+02 B 315 M24 3 15/16 inch 466 mm 143 mm 410 mm 374 mm
45 P54+03 P54+03 B 315 M24 3 15/16 inch 514 mm 191 mm 450 mm 426 mm
46 P05+100 P05+100 B 400 M24 4 inch 380 mm 112 mm 328 mm 312 mm
47 P06+01E P06+01E B 400 M24 4 inch 420 mm 125 mm 366 mm 342 mm
48 P07+02 P07+02 B 400 M24 4 inch 466 mm 143 mm 410 mm 374 mm
49 P54+03 P54+03 B 400 M24 4 inch 514 mm 191 mm 450 mm 426 mm
50 P07+01 P07+01 B 403 M24 4 3/16 inch 466 mm 143 mm 410 mm 374 mm
51 P08+02 P08+02 B 403 M24 4 3/16 inch 508 mm 162 mm 462 mm 438 mm
52 P06+100 P06+100 B 407 M24 4 7/16 inch 420 mm 125 mm 366 mm 342 mm
53 P07+01 P07+01 B 407 M24 4 7/16 inch 466 mm 143 mm 410 mm 374 mm
54 P08+02 P08+02 B 407 M24 4 7/16 inch 508 mm 162 mm 462 mm 438 mm
55 P55+03 P55+03 B 407 M24 4 7/16 inch 534 mm 197 mm 470 mm 446 mm
56 P06+100 P06+100 B 408 M24 4 1/2 inch 420 mm 125 mm 366 mm 342 mm
57 P07+01 P07+01 B 408 M24 4 1/2 inch 466 mm 143 mm 410 mm 374 mm
58 P08+02 P08+02 B 408 M24 4 1/2 inch 508 mm 162 mm 462 mm 438 mm
59 P55+03 P55+03 B 408 M24 4 1/2 inch 534 mm 197 mm 470 mm 446 mm
60 P07+100 P07+100 B 415 M24 4 15/16 inch 466 mm 143 mm 410 mm 374 mm
61 P08+01 P08+01 B 415 M24 4 15/16 inch 508 mm 162 mm 462 mm 438 mm
62 P10+02 P10+02 B 415 M24 4 15/16 inch 558 mm 181 mm 508 mm 484 mm
63 P56+03 P56+03 B 415 M24 4 15/16 inch 546 mm 203 mm 482 mm 458 mm
64 P07+100 P07+100 B 500 M24 5 inch 466 mm 143 mm 410 mm 374 mm
65 P08+01 P08+01 B 500 M24 5 inch 508 mm 162 mm 462 mm 438 mm
66 P10+02 P10+02 B 500 M24 5 inch 558 mm 181 mm 508 mm 484 mm
67 P56+03 P56+03 B 500 M24 5 inch 546 mm 203 mm 482 mm 458 mm
68 P09+01 P09+01 B 503 M24 5 3/16 inch 558 mm 181 mm 494 mm 470 mm
69 P30+02 P30+02 B 503 M24 5 3/16 inch 610 mm 203 mm 558 mm 534 mm
70 P08+100 P08+100 B 507 M24 5 7/16 inch 508 mm 162 mm 462 mm 438 mm
71 P09+01 P09+01 B 507 M24 5 7/16 inch 558 mm 181 mm 494 mm 470 mm
72 P30+02 P30+02 B 507 M24 5 7/16 inch 610 mm 203 mm 558 mm 534 mm
73 P57+03 P57+03 B 507 M30 5 7/16 inch 622 mm 229 mm 534 mm 494 mm
74 P08+100 P08+100 B 508 M24 5 1/2 inch 508 mm 162 mm 462 mm 438 mm
75 P09+01 P09+01 B 508 M24 5 1/2 inch 558 mm 181 mm 494 mm 470 mm
76 P30+02 P30+02 B 508 M24 5 1/2 inch 610 mm 203 mm 558 mm 534 mm
77 P57+03 P57+03 B 508 M30 5 1/2 inch 622 mm 229 mm 534 mm 494 mm
78 P09+100 P09+100 B 515 M24 5 15/16 inch 558 mm 181 mm 494 mm 470 mm
79 P10+01 P10+01 B 515 M24 5 15/16 inch 558 mm 181 mm 508 mm 484 mm
80 P31+02 P31+02 B 515 M24 5 15/16 inch 636 mm 210 mm 570 mm 546 mm
81 P58+03 P58+03 B 515 M30 5 15/16 inch 666 mm 254 mm 578 mm 538 mm
82 P09+100 P09+100 B 600 M24 6 inch 558 mm 181 mm 494 mm 470 mm
83 P10+01 P10+01 B 600 M24 6 inch 558 mm 181 mm 508 mm 484 mm
84 P31+02 P31+02 B 600 M24 6 inch 636 mm 210 mm 570 mm 546 mm
85 P58+03 P58+03 B 600 M30 6 inch 666 mm 254 mm 578 mm 538 mm
86 P11+01 P11+01 B 607 M24 6 7/16 inch 508 mm 213 mm 380 mm 356 mm
87 P32+02 P32+02 B 607 M30 6 7/16 inch 596 mm 267 mm 468 mm 428 mm
88 P59+03 P59+03 B 607 M30 6 7/16 inch 736 mm 267 mm 648 mm 608 mm
89 P11+01 P11+01 B 608 M24 6 1/2 inch 508 mm 213 mm 380 mm 356 mm
90 P32+02 P32+02 B 608 M30 6 1/2 inch 596 mm 267 mm 468 mm 428 mm
91 P59+03 P59+03 B 608 M30 6 1/2 inch 736 mm 267 mm 648 mm 608 mm
92 P12+01 P12+01 B 615 M24 6 15/16 inch 534 mm 235 mm 400 mm 376 mm
93 P33+02 P33+02 B 615 M30 6 15/16 inch 636 mm 273 mm 478 mm 438 mm
94 P60+03 P60+03 B 615 M30 6 15/16 inch 762 mm 279 mm 656 mm 616 mm
95 P12+01 P12+01 B 700 M24 7 inch 534 mm 235 mm 400 mm 376 mm
96 P33+02 P33+02 B 700 M30 7 inch 636 mm 273 mm 478 mm 438 mm
97 P60+03 P60+03 B 700 M30 7 inch 762 mm 279 mm 656 mm 616 mm
98 P13+01 P13+01 B 715 M24 7 15/16 inch 572 mm 248 mm 434 mm 410 mm
99 P34+02 P34+02 B 715 M30 7 15/16 inch 686 mm 305 mm 528 mm 488 mm
100 P61+03 P61+03 B 715 M36 7 15/16 inch 838 mm 311 mm 656 mm 616 mm
