Plummer Bearing Units-Metric

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

35~6000mm

Applications

Agricultural Machinery, Mining & Construction Equipment, Conveying Systems, Paper & Printing Machinery,etc

Filters

NO. Product Product Number Inner diameter (d) Distance shaft axis (H) MIN distance fixing bore (E) MAX distance fixing bore (E) Bolt size Number of mounting holes (n)
101 P17+01 P17+01 B 300M 300 mm 343 mm 564 mm 604 mm M30 4
102 P38+02 P38+02 B 300M 300 mm 394 mm 546 mm 586 mm M30 8
103 P65+03 P65+03 B 300M 300 mm 457 mm 654 mm 694 mm M36 8
104 P18+01 P18+01 B 320M 320 mm 368 mm 602 mm 642 mm M36 4
105 P39+02 P39+02 B 320M 320 mm 419 mm 590 mm 630 mm M30 8
106 P66+03 P66+03 B 320M 320 mm 518 mm 742 mm 782 mm M36 8
107 P18+01 P18+01 B 330M 330 mm 368 mm 602 mm 642 mm M36 4
108 P39+02 P39+02 B 330M 330 mm 419 mm 590 mm 630 mm M30 8
109 P18+01 P18+01 B 1300-340M 340 mm 368 mm 602 mm 642 mm M36 4
110 P19+01 P19+01 B 340M 340 mm 387 mm 634 mm 674 mm M36 4
111 P40+02 P40+02 B 340M 340 mm 451 mm 640 mm 680 mm M36 8
112 P86+03E P86+03E B 340M 340 mm 470 mm 634 mm 686 mm M42 8
113 P19+01 P19+01 B 350M 350 mm 387 mm 634 mm 674 mm M36 4
114 P40+02 P40+02 B 350M 350 mm 451 mm 640 mm 680 mm M36 8
115 P19+01 P19+01 B 1400-360M 360 mm 387 mm 634 mm 674 mm M36 4
116 P20+01 P20+01 B 360M 360 mm 397 mm 656 mm 696 mm M36 4
117 P40+02 P40+02 B 360M 360 mm 451 mm 640 mm 680 mm M36 8
118 P86+03E P86+03E B 360M 360 mm 470 mm 634 mm 686 mm M42 8
119 P67+03X P67+03X B 360M 360 mm 533 mm 758 mm 810 mm M42 8
120 P20+01 P20+01 B 380M 380 mm 397 mm 656 mm 696 mm M36 4
121 P41+02 P41+02 B 380M 380 mm 464 mm 662 mm 702 mm M36 8
122 P68+03 P68+03 B 380M 380 mm 559 mm 780 mm 832 mm M42 8
123 P21+01 P21+01 B 390M 390 mm 432 mm 704 mm 744 mm M36 4
124 P21+01 P21+01 B 400M 400 mm 432 mm 704 mm 744 mm M36 4
125 P42+02 P42+02 B 400M 400 mm 495 mm 710 mm 750 mm M36 8
126 P68+03 P68+03 B 400M 400 mm 559 mm 780 mm 832 mm M42 8
127 P22+01 P22+01 B 420M 420 mm 445 mm 736 mm 776 mm M36 4
128 P43+02 P43+02 B 420M 420 mm 514 mm 748 mm 788 mm M36 8
129 P89+03E P89+03E B 420M 420 mm 508 mm 664 mm 716 mm M48 8
130 P23+01 P23+01 B 440M 440 mm 464 mm 768 mm 808 mm M42 4
131 P44+02 P44+02 B 440M 440 mm 533 mm 768 mm 808 mm M36 8
132 P89+03E P89+03E B 440M 440 mm 508 mm 664 mm 716 mm M48 8
133 P23+01 P23+01 B 460M 460 mm 464 mm 768 mm 808 mm M42 4
134 P44+02 P44+02 B 460M 460 mm 533 mm 768 mm 808 mm M36 8
135 P90+03E P90+03E B 460M 460 mm 550 mm 754 mm 806 mm M48 8
136 P71+03X P71+03X B 460M 460 mm 660 mm 908 mm 960 mm M48 8
137 P24+01 P24+01 B 480M 480 mm 483 mm 796 mm 836 mm M42 4
138 P45+02 P45+02 B 480M 480 mm 552 mm 792 mm 832 mm M36 8
139 P71+03X P71+03X B 480M 480 mm 660 mm 908 mm 960 mm M48 8
140 P25+01 P25+01 B 500M 500 mm 489 mm 824 mm 864 mm M42 4
141 P46+02 P46+02 B 500M 500 mm 572 mm 824 mm 864 mm M36 8
142 P94+03 P94+03 B 500M 500 mm 622 mm 914 mm 966 mm M56 8
143 P26+01 P26+01 B 530M 530 mm 533 mm 884 mm 924 mm M42 4
144 P47+02 P47+02 B 530M 530 mm 591 mm 870 mm 910 mm M36 8
145 P94+03 P94+03 B 530M 530 mm 622 mm 914 mm 966 mm M56 8
146 P27+01 P27+01 B 560M 560 mm 552 mm 916 mm 956 mm M42 4
147 P48+02 P48+02 B 560M 560 mm 616 mm 904 mm 956 mm M42 8
148 P94+03E P94+03E B 560M 560 mm 622 mm 914 mm 966 mm M56 8
149 P28+01 P28+01 B 580M 580 mm 578 mm 857 mm 896 mm M36 8
150 P49+02 P49+02 B 580M 580 mm 635 mm 932 mm 984 mm M42 8
151 P29+01 P29+01 B 600M 600 mm 597 mm 888 mm 928 mm M36 8
152 P50+02 P50+02 B 600M 600 mm 673 mm 984 mm 1036 mm M42 8
153 P95+03E P95+03E B 600M 600 mm 622 mm 914 mm 966 mm M56 8
