Spindle bearings

Image may differ from product. See technical specification for details.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Inner ring diameter

10mm-280mm

Outer ring diameter

20mm-400mm

Weight

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Stainless Steel, German High Nitrogen Stainless Steel CRONIDUR30, Ceramic

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM,Machine tool spindle, centrifuge, booster pump, oil pump, blower, various gearboxes, laboratory equipment

Package

DB, DF, DT, DBD, DBB, SU

Pairing method

DB, DF, DT, DBD, DBB, SU

Spindle bearings

Filters

NO. Product Product Number Basic dynamic load rating Basic static load rating Inner diameter (d) Mass Outer diameter (D) Width (B)
7001 HC7012-C-DLR-T-P4S/ HC7012-C-DLR-T-P4S 39.00 KN 33.50 KN 60 mm 0.4 kg 95 mm 18 mm
7002 HCB7012-C-T-P4S/ HCB7012-C-T-P4S 27.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7003 HCB7012-C-DLR-T-P4S/ HCB7012-C-DLR-T-P4S 27.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7004 HCB7012-E-P2-DB/ HCB7012-E-P2-DB 25.50 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7005 HCB7012-C-P2-DT-L/ HCB7012-C-P2-DT-L 25.50 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7006 HCB7012-E-T-P4S/ HCB7012-E-T-P4S 25.50 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7007 HCB7012-E-DLR-T-P4S/ HCB7012-E-DLR-T-P4S 25.50 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7008 XCB7012-C-P2-DB-M/ XCB7012-C-P2-DB-M 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7009 XC7012-C-P2-DB-M/ XC7012-C-P2-DB-M 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7010 XCB7012-C-P2-DT/ XCB7012-C-P2-DT 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7011 XC7012-E-P2-DT-M/ XC7012-E-P2-DT-M 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7012 XC7012-C-P2-DT/ XC7012-C-P2-DT 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7013 XC7012-C-P2-H/ XC7012-C-P2-H 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7014 XCB7012-E-P2-DT-M/ XCB7012-E-P2-DT-M 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7015 XCB7012-C-T-P4S/ XCB7012-C-T-P4S 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7016 XC7012-C-T-P4S/ XC7012-C-T-P4S 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7017 XCB7012-C-DLR-T-P4S/ XCB7012-C-DLR-T-P4S 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7018 XC7012-C-DLR-T-P4S/ XC7012-C-DLR-T-P4S 60.00 KN 23.20 KN 60 mm 0.34 kg 95 mm 18 mm
7019 XCB7012-E-P2-DB/ XCB7012-E-P2-DB 57.00 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7020 XCB7012-E-T-P4S/ XCB7012-E-T-P4S 57.00 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7021 XCB7012-E-DLR-T-P4S/ XCB7012-E-DLR-T-P4S 57.00 KN 22.00 KN 60 mm 0.34 kg 95 mm 18 mm
7022 HS7012-C-P2-DB-H/ HS7012-C-P2-DB-H 19.30 KN 20.00 KN 60 mm 0.46kg 95 mm 18 mm
7023 HS7012-C-T-P4S/ HS7012-C-T-P4S 19.30 KN 20.00 KN 60 mm 0.46kg 95 mm 18 mm
7024 HS7012-C-DLR-T-P4S/ HS7012-C-DLR-T-P4S 19.30 KN 20.00 KN 60 mm 0.46kg 95 mm 18 mm
7025 B7212-C-P2-DB/ B7212-C-P2-DB 55.00 KN 44.00 KN 60 mm 0.80 kg 110 mm 22 mm
7026 B7212-C-T-P4S/ B7212-C-T-P4S 55.00 KN 44.00 KN 60 mm 0.80 kg 110 mm 22 mm
7027 B7212-C-DLR-T-P4S/ B7212-C-DLR-T-P4S 55.00 KN 44.00 KN 60 mm 0.80 kg 110 mm 22 mm
7028 B7212-E-P2-DB-L/ B7212-E-P2-DB-L 52.00 KN 42.50 KN 60 mm 0.80 kg 110 mm 22 mm
7029 B7212-E-P2-DT/ B7212-E-P2-DT 52.00 KN 42.50 KN 60 mm 0.80 kg 110 mm 22 mm
7030 B7212-E-P2-DT/ B7212-E-P2-DT 52.00 KN 42.50 KN 60 mm 0.80 kg 110 mm 22 mm
7031 HCB7212-C-T-P4S/ HCB7212-C-T-P4S 38.00 KN 30.50 KN 60 mm 0.70 kg 110 mm 22 mm
7032 HCB7212-C-DLR-T-P4S/ HCB7212-C-DLR-T-P4S 38.00 KN 30.50 KN 60 mm 0.70 kg 110 mm 22 mm
7033 HCB7212-E-P2-DB/ HCB7212-E-P2-DB 36.00 KN 29.00 KN 60 mm 0.70 kg 110 mm 22 mm
7034 HCB7212-C-P2-DT-L/ HCB7212-C-P2-DT-L 36.00 KN 29.00 KN 60 mm 0.70 kg 110 mm 22 mm
7035 HCB7212-E-T-P4S/ HCB7212-E-T-P4S 36.00 KN 29.00 KN 60 mm 0.70 kg 110 mm 22 mm
7036 HCB7212-E-DLR-T-P4S/ HCB7212-E-DLR-T-P4S 36.00 KN 29.00 KN 60 mm 0.70 kg 110 mm 22 mm
7037 B71813-C-P2-DB/ B71813-C-P2-DB 13.40 KN 14.00 KN 65 mm 0.13 kg 85 mm 10 mm
7038 B71813-C-TPA-P4/ B71813-C-TPA-P4 13.40 KN 14.00 KN 65 mm 0.13 kg 85 mm 10 mm
7039 B71813-E-P2-DB-L/ B71813-E-P2-DB-L 12.70 KN 12.90 KN 65 mm 0.13 kg 85 mm 10 mm
7040 B71813-E-P2-DT/ B71813-E-P2-DT 12.70 KN 12.90 KN 65 mm 0.13 kg 85 mm 10 mm
7041 B71813-E-TPA-P4/ B71813-E-TPA-P4 12.70 KN 12.90 KN 65 mm 0.13 kg 85 mm 10 mm
7042 HCB71813-C-TPA-P4/ HCB71813-C-TPA-P4 9.30 KN 9.80 KN 65 mm 0.13 kg 85 mm 10 mm
7043 HCB71813-E-P2-DB/ HCB71813-E-P2-DB 8.80 KN 9.15 KN 65 mm 0.13 kg 85 mm 10 mm
7044 HCB71813-C-P2-DT-L/ HCB71813-C-P2-DT-L 8.80 KN 9.15 KN 65 mm 0.13 kg 85 mm 10 mm
7045 HCB71813-E-TPA-P4/ HCB71813-E-TPA-P4 8.80 KN 9.15 KN 65 mm 0.13 kg 85 mm 10 mm
7046 HCB71813-E-DLR-TPA-P4/ HCB71813-E-DLR-TPA-P4 8.80 KN 9.15 KN 65 mm 0.13 kg 85 mm 10 mm
7047 B71913-C-P2-DB/ B71913-C-P2-DB 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7048 B71913-E-P2-DB-L/ B71913-E-P2-DB-L 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7049 B71913-E-P2-DT/ B71913-E-P2-DT 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7050 B71913-C-T-P4S/ B71913-C-T-P4S 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7051 B71913-E-T-P4S/ B71913-E-T-P4S 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7052 B71913-C-DLR-T-P4S/ B71913-C-DLR-T-P4S 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7053 B71913-E-DLR-T-P4S/ B71913-E-DLR-T-P4S 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7054 HC71913-C-DLR-T-P4S/ HC71913-C-DLR-T-P4S 24.50 KN 24.00 KN 65 mm 0.20 kg 90 mm 13 mm
7055 71913 71913 ACE/HCP2 15.6 KN 11.8 KN 65 mm 0.20 kg 90 mm 13 mm
7056 HCB71913-C-T-P4S/ HCB71913-C-T-P4S 17.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7057 HCB71913-C-DLR-T-P4S/ HCB71913-C-DLR-T-P4S 17.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7058 HCB71913-E-P2-DB/ HCB71913-E-P2-DB 16.00 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7059 HCB71913-C-P2-DT-L/ HCB71913-C-P2-DT-L 16.00 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7060 HCB71913-E-T-P4S/ HCB71913-E-T-P4S 16.00 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7061 HCB71913-E-DLR-T-P4S/ HCB71913-E-DLR-T-P4S 16.00 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7062 XCB71913-C-P2-DB-M/ XCB71913-C-P2-DB-M 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7063 XC71913-C-P2-DB-M/ XC71913-C-P2-DB-M 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7064 XCB71913-C-P2-DT/ XCB71913-C-P2-DT 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7065 XCB71913-E-P2-DT-M/ XCB71913-E-P2-DT-M 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7066 XC71913-E-P2-DT-M/ XC71913-E-P2-DT-M 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7067 XC71913-C-P2-DT/ XC71913-C-P2-DT 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7068 XC71913-C-P2-H/ XC71913-C-P2-H 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7069 XCB71913-C-T-P4S/ XCB71913-C-T-P4S 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7070 XC71913-C-T-P4S/ XC71913-C-T-P4S 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7071 XCB71913-C-DLR-T-P4S/ XCB71913-C-DLR-T-P4S 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7072 XC71913-C-DLR-T-P4S/ XC71913-C-DLR-T-P4S 38.00 KN 16.60 KN 65 mm 0.17 kg 90 mm 13 mm
7073 XCB71913-E-P2-DB/ XCB71913-E-P2-DB 35.50 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7074 XCB71913-E-T-P4S/ XCB71913-E-T-P4S 35.50 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7075 XCB71913-E-DLR-T-P4S/ XCB71913-E-DLR-T-P4S 35.50 KN 16.00 KN 65 mm 0.17 kg 90 mm 13 mm
7076 HS71913-C-P2-DB-H/ HS71913-C-P2-DB-H 14.30 KN 15.30 KN 65 mm 0.23 kg 90 mm 13 mm
7077 HS71913-C-T-P4S/ HS71913-C-T-P4S 14.30 KN 15.30 KN 65 mm 0.23 kg 90 mm 13 mm
7078 HS71913-C-DLR-T-P4S/ HS71913-C-DLR-T-P4S 14.30 KN 15.30 KN 65 mm 0.23 kg 90 mm 13 mm
7079 B7013-E-P2-DB-L/ B7013-E-P2-DB-L 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7080 B7013-C-P2-DB/ B7013-C-P2-DB 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7081 B7013-E-P2-DT/ B7013-E-P2-DT 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7082 B7013-C-T-P4S/ B7013-C-T-P4S 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7083 B7013-E-T-P4S/ B7013-E-T-P4S 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7084 B7013-C-DLR-T-P4S/ B7013-C-DLR-T-P4S 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7085 B7013-E-DLR-T-P4S/ B7013-E-DLR-T-P4S 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7086 HC7013-C-DLR-T-P4S/ HC7013-C-DLR-T-P4S 40.00 KN 35.50 KN 65 mm 0.42 kg 100 mm 18 mm
7087 7013 7013 ACE/HCP2 19.50 KN 14.60 KN 65 mm 0.43kg 100 mm 18 mm
7088 HCB7013-C-T-P4S/ HCB7013-C-T-P4S 27.50 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7089 HCB7013-C-DLR-T-P4S/ HCB7013-C-DLR-T-P4S 27.50 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7090 HCB7013-E-P2-DB/ HCB7013-E-P2-DB 26.00 KN 23.60 KN 65 mm 0.36 kg 100 mm 18 mm
7091 HCB7013-C-P2-DT-L/ HCB7013-C-P2-DT-L 26.00 KN 23.60 KN 65 mm 0.36 kg 100 mm 18 mm
7092 HCB7013-E-T-P4S/ HCB7013-E-T-P4S 26.00 KN 23.60 KN 65 mm 0.36 kg 100 mm 18 mm
7093 HCB7013-E-DLR-T-P4S/ HCB7013-E-DLR-T-P4S 26.00 KN 23.60 KN 65 mm 0.36 kg 100 mm 18 mm
7094 XCB7013-C-P2-DB-M/ XCB7013-C-P2-DB-M 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7095 XC7013-C-P2-DB-M/ XC7013-C-P2-DB-M 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7096 XCB7013-C-P2-DT/ XCB7013-C-P2-DT 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7097 XC7013-E-P2-DT-M/ XC7013-E-P2-DT-M 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7098 XC7013-C-P2-DT/ XC7013-C-P2-DT 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7099 XC7013-C-P2-H/ XC7013-C-P2-H 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
7100 XCB7013-E-P2-DT-M/ XCB7013-E-P2-DT-M 61.00 KN 24.50 KN 65 mm 0.36 kg 100 mm 18 mm
