Plummer Bearing Units-Metric

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

High Carbon Chromium Bearing Steel/Grey Iron or Ductile Iron/Bearing steel GCr15

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Bore

35~6000mm

Applications

Agricultural Machinery, Mining & Construction Equipment, Conveying Systems, Paper & Printing Machinery,etc

Filters

NO. Product Product Number Bore Distance fixing bore (e) Housing model Distance shaft axis (H) Distance fixing bore (S)
1 P01+01 P01+01 B 35M P01 60 mm -
2 P01+01 P01+01 B 40M P01 60 mm -
3 P02+01E P02+01E B 45M P02 70 mm -
4 P02+01E P02+01E B 50M P02 70 mm -
5 P03+02 P03+02 B 50M P03 80 mm -
6 P03+01E P03+01E B 55M P03 80 mm -
7 P03+01E P03+01E B 60M P03 80 mm -
8 P04+02 P04+02 B 60M P04 95 mm -
9 P03+01 P03+01 E B 65M P03 80 mm -
10 P04+02 P04+02 B 65M P04 95 mm -
11 P04+01E P04+01E B 70M P04 95 mm -
12 P05+02 P05+02 B 70M P05 112 mm -
13 P03+100 P03+100 B 75M P03 80 mm -
14 P04+01E P04+01E B 75M P04 95 mm -
15 P05+02 P05+02 B 75M P05 112 mm -
16 P05+01E P05+01E B 80M P05 112 mm -
17 P06+02 P06+02 B 80M P06 125 mm -
18 P04+100 P04+100 B 85M P04 95 mm -
19 P05+01E P05+01E B 85M P05 112 mm -
20 P06+02 P06+02 B 85M P06 125 mm -
21 P05+01E P05+01E B 90M P05 112 mm -
22 P06+02 P06+02 B 90M P06 125 mm -
23 P06+01E P06+01E B 95M P06 125 mm -
24 P05+100 P05+100 B 100M P05 112 mm -
25 P06+01E P06+01E B 100M P06 125 mm -
26 P07+02 P07+02 B 100M P07 143 mm -
27 P54+03 P54+03 B 100M P54 191 mm 82 mm
28 P06+01E P06+01E B 105M P06 125 mm -
29 P07+02 P07+02 B 105M P07 143 mm -
30 P06+100 P06+100 B 110M P06 125 mm -
31 P07+01 P07+01 B 110M P07 143 mm -
32 P08+02 P08+02 B 110M P08 162 mm 120 mm
33 P55+03 P55+03 B 110M P55 197 mm 88 mm
34 P07+01B P07+01B 115M P07 143 mm -
35 P08+02 P08+02 B 115M P08 162 mm 120 mm
36 P07+100 P07+100 B 120M P07 143 mm -
37 P08+01 P08+01 B 120M P08 162 mm 120 mm
38 P10+02 P10+02 B 120M P10 181 mm 120 mm
39 P55+03 P55+03 B 120M P55 197 mm 88 mm
40 P08+01 P08+01 B 125M P08 162 mm 120 mm
41 P10+02 P10+02 B 125M P10 181 mm 120 mm
42 P07+100 P07+100 B 130M P07 143 mm -
43 P08+01 P08+01 B 130M P08 162 mm 120 mm
44 P10+02 P10+02 B 130M P10 181 mm 120 mm
45 P56+03 P56+03 B 130M P56 203 mm 96 mm
46 P09+01 P09+01 B 135M P09 181 mm 120 mm
47 P08+100 P08+100 B 140M P08 162 mm 120 mm
48 P09+01 P09+01 B 140M P09 181 mm 120 mm
49 P30+02 P30+02 B 140M P30 203 mm 120 mm
50 P57+03 P57+03 B 140M P57 229 mm 102 mm
51 P30+02 P30+02 B 145M P30 203 mm 120 mm
52 P09+100 P09+100 B 150M P09 181 mm 120 mm
53 P10+01 P10+01 B 150M P10 181 mm 120 mm
54 P31+02 P31+02 B 150M P31 210 mm 128 mm
55 P58+03 P58+03 B 150M P58 254 mm 120 mm
56 P10+01 P10+01 B 155M P10 181 mm 120 mm
57 P31+02 P31+02 B 155M P31 210 mm 128 mm
58 P10+01 P10+01 B 600-160M P10 181 mm 120 mm
59 P11+01 P11+01 B 160M P11 213 mm 114 mm
60 P31+02 P31+02 B 600-160M P31 210 mm 128 mm
61 P32+02 P32+02 B 160M P32 267 mm 172 mm
62 P59+03 P59+03 B 160M P59 267 mm 140 mm
63 P11+01 P11+01 B 608-170M P11 213 mm 114 mm
64 P12+01 P12+01 B 170M P12 235 mm 128 mm
65 P32+02 P32+02 B 170M P32 267 mm 172 mm
66 P59+03 P59+03 B 170M P59 267 mm 140 mm
67 P12+01 P12+01 B 175M P12 235 mm 128 mm
68 P33+02 P33+02 B 175M P33 273 mm 166 mm
69 P12+01 P12+01 B 180M P12 235 mm 128 mm
70 P33+02 P33+02 B 180M P33 273 mm 166 mm
71 P60+03 P60+03 B 180M P60 279 mm 152 mm
72 P13+01 P13+01 B 190M P13 248 mm 140 mm
73 P34+02 P34+02 B 190M P34 305 mm 190 mm
74 P61+03 P61+03 B 190M P61 311 mm 172 mm
75 P13+01 P13+01 B 200M P13 248 mm 140 mm
76 P34+02 P34+02 B 200M P34 305 mm 190 mm
77 P61+03 P61+03 B 200M P61 311 mm 172 mm
78 P14+01 P14+01 B 220M P14 270 mm 140 mm
79 P35+02 P35+02 B 220M P35 324 mm 190 mm
80 P62+03 P62+03 B 220M P62 349 mm 178 mm
81 P14+01 P14+01 B 230M P14 270 mm 140 mm
82 P35+02 P35+02 B 230M P35 324 mm 190 mm
83 P15+01 P15+01 B 240M P15 292 mm 140 mm
84 P36+02 P36+02 B 240M P36 356 mm 204 mm
85 P63+03 P63+03 B 240M P63 394 mm 304 mm
86 P15+01 P15+01 B 250M P15 292 mm 140 mm
87 P36+02 P36+02 B 250M P36 356 mm 204 mm
88 P63+03 P63+03 B 250M P63 394 mm 304 mm
89 P15+01 P15+01 B 1000-260M P15 292 mm 140 mm
90 P16+01 P16+01 B 260M P16 311 mm 140 mm
91 P36+02 P36+02 B 260M P36 356 mm 204 mm
92 P63+03 P63+03 B 260M P63 394 mm 304 mm
93 P16+01 P16+01 B 270M P16 311 mm 140 mm
94 P16+01 P16+01 B 275M P16 311 mm 140 mm
95 P16+01 P16+01 B 280M P16 311 mm 140 mm
96 P37+02 P37+02 B 280M 101 mm P37 378 mm 254 mm
97 P64+03X P64+03X B 280M 101 mm P64 425 mm 318 mm
98 P83+03E P83+03E B 280M 120 mm P83 368 mm 178 mm
99 P17+01 P17+01 B 290M P17 343 mm 178 mm
100 P65+03 P65+03 B 290M 101 mm P65 457 mm 330 mm
