Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
201 C680/ C680 80 13.666 inch 25.80 lbs 13.333 inch 6
202 C684/ C684 84 14.333 inch 25.00 lbs 14.000 inch 6
203 C690/ C690 90 15.333 inch 25.80 lbs 15.000 inch 6
204 C696/ C696 96 16.333 inch 28.00 lbs 16.000 inch 6
205 C6108/ C6108 108 18.333 inch 32.00 lbs 18.000 inch 6
206 C6120/ C6120 120 20.333 inch 34.80 lbs 20.000 inch 6
207 C6132/ C6132 132 22.333 inch 43.40 lbs 22.000 inch 6
208 C6144/ C6144 144 24.333 inch 45.20 lbs 24.000 inch 6
209 C6180/ C6180 180 30.333 inch 58.30 lbs 30.000 inch 6
210 S611BS S611BS 1 11 2.333 inch 1.10 lbs 2.000 inch 6
211 S612BS S612BS 1 12 2.333 inch 1.10 lbs 2.000 inch 6
212 S614BS S614BS 1 14 2.667 inch 1.80 lbs 2.333 inch 6
213 S614BS S614BS 1 1/8 14 2.667 inch 1.80 lbs 2.333 inch 6
214 S615BS S615BS 1 15 2.833 inch 2.20 lbs 2.500 inch 6
215 S615BS S615BS 1 1/8 15 2.833 inch 2.20 lbs 2.500 inch 6
216 S615BS S615BS 1 3/16 15 2.833 inch 2.20 lbs 2.500 inch 6
217 S615BS S615BS 1 1/4 15 2.833 inch 2.20 lbs 2.500 inch 6
218 S616BS S616BS 1 16 3.000 inch 2.60 lbs 2.677 inch 6
219 S616BS S616BS 1 1/8 16 3.000 inch 2.60 lbs 2.677 inch 6
220 S616BS S616BS 1 3/16 16 3.000 inch 2.60 lbs 2.677 inch 6
221 S616BS S616BS 1 1/4 16 3.000 inch 2.60 lbs 2.677 inch 6
222 S618BS S618BS 1 18 3.333 inch 3.50 lbs 3.000 inch 6
223 S618BS S618BS 1 1/8 18 3.333 inch 3.50 lbs 3.000 inch 6
224 S618BS S618BS 1 3/16 18 3.333 inch 3.50 lbs 3.000 inch 6
225 S618BS S618BS 1 1/4 18 3.333 inch 3.50 lbs 3.000 inch 6
226 S620BS S620BS 1 20 3.667 inch 4.60 lbs 3.333 inch 6
227 S620BS S620BS 1 1/8 20 3.667 inch 4.60 lbs 3.333 inch 6
228 S620BS S620BS 1 3/16 20 3.667 inch 4.60 lbs 3.333 inch 6
229 S620BS S620BS 1 1/4 20 3.667 inch 4.60 lbs 3.333 inch 6
230 S811/ S811 11 1.750 inch 0.50 lbs 1.500 inch 8
231 S812/ S812 12 1.750 inch 0.50 lbs 1.500 inch 8
232 S813/ S813 13 1.875 inch 0.70 lbs 1.625 inch 8
233 S814/ S814 14 2.000 inch 0.90 lbs 1.750inch 8
234 S815/ S815 15 2.125 inch 0.90 lbs 1.875 inch 8
235 S816/ S816 16 2.250 inch 1.10 lbs 2.000 inch 8
236 S817/ S817 17 2.375 inch 1.30 lbs 2.125 inch 8
237 S818/ S818 18 2.500 inch 1.60 lbs 2.250 inch 8
238 S819/ S819 19 2.625 inch 1.80 lbs 2.375 inch 8
239 S820/ S820 20 2.750 inch 2.00 lbs 2.500 inch 8
240 S821/ S821 21 2.875 inch 2.30 lbs 2.625 inch 8
241 S822/ S822 22 3.000 inch 2.60 lbs 2.750 inch 8
242 S824/ S824 24 3.250 inch 3.60 lbs 3.000 inch 8
243 S826/ S826 26 3.500 inch 3.90 lbs 3.250 inch 8
244 S828/ S828 28 3.750 inch 4.40 lbs 3.500 inch 8
245 S830/ S830 30 4.000 inch 5.10 lbs 3.750 inch 8
246 S832/ S832 32 4.250 inch 5.60 lbs 4.000 inch 8
247 S840/ S840 40 5.250 inch 8.30 lbs 5.000 inch 8
248 S842/ S842 42 5.500 inch 9.00 lbs 5.250 inch 8
249 S844/ S844 44 5.750 inch 9.70 lbs 5.500 inch 8
250 S848/ S848 48 6.250 inch 11.30 lbs 6.000 inch 8
251 C836/ C836 36 4.750 inch 4.50 lbs 4.500 inch 8
252 C840/ C840 40 5.250 inch 5.10 lbs 5.000 inch 8
253 C842/ C842 42 5.500 inch 5.50 lbs 5.250 inch 8
254 C844/ C844 44 5.750 inch 6.00 lbs 5.500 inch 8
255 C852/ C852 52 6.750 inch 10.30 lbs 6.500 inch 8
256 C854/ C854 54 7.000 inch 8.10 lbs 6.750 inch 8
257 C856/ C856 56 7.250 inch 8.20 lbs 7.000 inch 8
258 C860/ C860 60 7.750 inch 8.80 lbs 7.500 inch 8
259 C864/ C864 64 8.250 inch 11.20 lbs 8.000 inch 8
260 C868/ C868 68 8.750 inch 11.50 lbs 8.500 inch 8
261 C872/ C872 72 9.250 inch 11.70 lbs 9.000 inch 8
262 C876/ C876 76 9.750 inch 12.00 lbs 9.500 inch 8
263 C880/ C880 80 10.250 inch 12.20 lbs 10.000 inch 8
264 C884/ C884 84 10.750 inch 13.20 lbs 10.500 inch 8
265 C888/ C888 88 11.250 inch 13.50 lbs 11.000 inch 8
266 C892/ C892 92 11.750 inch 15.00 lbs 11.500 inch 8
267 C896/ C896 96 12.250 inch 15.80 lbs 12.000 inch 8
268 C8100/ C8100 100 12.750 inch 16.50 lbs 12.500 inch 8
269 C8112/ C8112 112 14.250 inch 17.70 lbs 14.000 inch 8
270 C8120/ C8120 120 15.250 inch 18.40 lbs 15.000 inch 8
271 C8128/ C8128 128 16.250 inch 21.30 lbs 16.000 inch 8
272 C8144/ C8144 144 18.250 inch 24.20 lbs 18.000 inch 8
273 C8160/ C8160 160 20.250 inch 26.60 lbs 20.000 inch 8
274 C8168/ C8168 168 21.250 inch 28.90 lbs 21.000 inch 8
275 S811BS S811BS 3/4 11 1.750 inch 0.50 lbs 1.500 inch 8
276 S812BS S812BS 3/4 12 1.750 inch 0.50 lbs 1.500 inch 8
277 S814BS S814BS 3/4 14 2.000 inch 0.90 lbs 1.750 inch 8
278 S815BS S815BS 7/8 15 2.125 inch 1.00 lbs 1.875 inch 8
279 S816BS S816BS 7/8 16 2.250 inch 1.10 lbs 2.000 inch 8
280 S816BS S816BS 1 16 2.250 inch 1.10 lbs 2.000 inch 8
281 S818BS S818BS 7/8 18 2.500 inch 1.60 lbs 2.250 inch 8
282 S818BS S818BS 1 18 2.500 inch 1.60 lbs 2.250 inch 8
283 S818BS S818BS 1-1/8 18 2.500 inch 1.60 lbs 2.250 inch 8
284 S820BS S820BS 7/8 20 2.750 inch 2.00 lbs 2.500 inch 8
285 S820BS S820BS 1 20 2.750 inch 2.00 lbs 2.500 inch 8
286 S820BS S820BS 1-1/8 20 2.750 inch 2.00 lbs 2.500 inch 8
287 S822BS S822BS 7/8 22 3.000 inch 2.60 lbs 2.750 inch 8
288 S822BS S822BS 1 22 3.000 inch 2.60 lbs 2.750 inch 8
289 S822BS S822BS 1-1/8 22 3.000 inch 2.60 lbs 2.750 inch 8
290 S1011/ S1011 11 1.400 inch 0.30 lbs 1.200 inch 10
291 S1012/ S1012 12 1.400 inch 0.30 lbs 1.200 inch 10
292 S1013/ S1013 13 1.500 inch 0.30 lbs 1.300 inch 10
293 S1014/ S1014 14 1.600 inch 0.40 lbs 1.400 inch 10
294 S1015/ S1015 15 1.700 inch 0.50 lbs 1.500 inch 10
295 S1016/ S1016 16 1.800 inch 0.60 lbs 1.600 inch 10
296 S1017/ S1017 17 1.900 inch 0.60 lbs 1.700 inch 10
297 S1018/ S1018 18 2.000 inch 0.80 lbs 1.800 inch 10
298 S1019/ S1019 19 2.100 inch 0.90 lbs 1.900 inch 10
299 S1020/ S1020 20 2.200 inch 1.00 lbs 2.000 inch 10
300 S1021/ S1021 21 2.300 inch 1.20 lbs 2.100 inch 10
