Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
401 S1214BS S1214BS 1/2 14 1.333 inch 0.24 lbs 1.167 inch 12
402 S1215BS S1215BS 5/8 15 1.417 inch 0.27 lbs 1.250 inch 12
403 S1216BS S1216BS 5/8 16 1.500 inch 0.34 lbs 1.333 inch 12
404 S1218BS S1218BS 5/8 18 1.667 inch 0.42 lbs 1.500 inch 12
405 S1220BS S1220BS 5/8 20 1.833 inch 0.56 lbs 1.667 inch 12
406 S1220BS S1220BS 3/4 20 1.833 inch 0.56 lbs 1.667 inch 12
407 S1221BS S1221BS 5/8 21 1.917 inch 0.56 lbs 1.750 inch 12
408 S1221BS S1221BS 3/4 21 1.917 inch 0.56 lbs 1.750 inch 12
409 S1221BS S1221BS 7/8 21 1.917 inch 0.56 lbs 1.750 inch 12
410 S1222BS S1222BS 5/8 22 2.000 inch 0.70 lbs 1.833 inch 12
411 S1222BS S1222BS 3/4 22 2.000 inch 0.70 lbs 1.833 inch 12
412 S1222BS S1222BS 7/8 22 2.000 inch 0.70 lbs 1.833 inch 12
413 S1222BS S1222BS 1 22 2.000 inch 0.70 lbs 1.833 inch 12
414 S1224BS S1224BS 5/8 24 2.167 inch 0.88 lbs 2.000 inch 12
415 S1224BS S1224BS 3/4 24 2.167 inch 0.88 lbs 2.000 inch 12
416 S1224BS S1224BS 7/8 24 2.167 inch 0.88 lbs 2.000 inch 12
417 S1224BS S1224BS 1 24 2.167 inch 0.88 lbs 2.000 inch 12
418 S1611/ S1611 11 0.875 inch 0.06 lbs 0.750 inch 16
419 S1612/ S1612 12 0.875 inch 0.06 lbs 0.750 inch 16
420 S1613/ S1613 13 0.937 inch 0.08 lbs 0.812 inch 16
421 S1614/ S1614 14 1.000 inch 0.08 lbs 0.875 inch 16
422 S1615/ S1615 15 1.062 inch 0.10 lbs 0.937 inch 16
423 S1616/ S1616 16 1.125 inch 0.12 lbs 1.000 inch 16
424 S1617/ S1617 17 1.187 inch 0.14 lbs 1.062 inch 16
425 S1618/ S1618 18 1.250 inch 0.16 lbs 1.125 inch 16
426 S1619/ S1619 19 1.312 inch 0.20 lbs 1.187 inch 16
427 S1620/ S1620 20 1.375 inch 0.22 lbs 1.250 inch 16
428 S1621/ S1621 21 1.438 inch 0.24 lbs 1.312 inch 16
429 S1622/ S1622 22 1.500 inch 0.28 lbs 1.375 inch 16
430 S1623/ S1623 23 1.562 inch 0.32 lbs 1.437 inch 16
431 S1624/ S1624 24 1.625 inch 0.34 lbs 1.500 inch 16
432 S1626/ S1626 26 1.750 inch 0.42 lbs 1.625 inch 16
433 S1628/ S1628 28 1.875 inch 0.52 lbs 1.725 inch 16
434 S1630/ S1630 30 2.000 inch 0.60 lbs 1.875 inch 16
435 S1632/ S1632 32 2.125 inch 0.70 lbs 2.000 inch 16
436 S1634/ S1634 34 2.250 inch 0.80 lbs 2.125 inch 16
437 S1636/ S1636 36 2.375 inch 0.92 lbs 2.250 inch 16
438 S1638/ S1638 38 2.500 inch 0.98 lbs 2.375 inch 16
439 S1640/ S1640 40 2.626 inch 1.10 lbs 2.500 inch 16
440 S1644/ S1644 44 2.875 inch 1.20 lbs 2.750 inch 16
441 S1648/ S1648 48 3.125 inch 1.40 lbs 3.000 inch 16
442 S1652/ S1652 52 3.375 inch 1.50 lbs 3.250 inch 16
443 S1654/ S1654 54 3.500 inch 1.60 lbs 3.375 inch 16
444 S1656/ S1656 56 3.625 inch 1.70 lbs 3.500 inch 16
445 S1660/ S1660 60 3.875 inch 1.30 lbs 3.750 inch 16
446 S1664/ S1664 64 4.125 inch 2.20 lbs 4.000 inch 16
447 S1668/ S1668 68 4.375 inch 2.50 lbs 4.250 inch 16
448 S1672/ S1672 72 4.625 inch 2.80 lbs 4.500 inch 16
449 S1680/ S1680 80 5.125 inch 3.40 lbs 5.000 inch 16
450 S1684/ S1684 84 5.375 inch 3.60 lbs 5.250 inch 16
451 S1688/ S1688 88 5.625 inch 3.90 lbs 5.500 inch 16
452 S1696/ S1696 96 6.125 inch 4.60 lbs 6.000 inch 16
453 S16104/ S16104 104 6.625 inch 5.20 lbs 6.500 inch 16
454 C16112/ C16112 112 7.125 inch 3.40 lbs 7.000 inch 16
455 C16120/ C16120 120 7.625 inch 3.50 lbs 7.500 inch 16
456 C16128/ C16128 128 8.125 inch 3.70 lbs 8.000 inch 16
457 C16144/ C16144 144 9.125 inch 5.00 lbs 9.000 inch 16
458 C16160/ C16160 160 10.125 inch 5.20 lbs 10.000 inch 16
459 C16192/ C16192 192 12.125 inch 8.10 lbs 12.000 inch 16
460 S1611BS S1611BS 3/8 11 0.875 inch 0.06 lbs 0.750 inch 16
461 S1612BS S1612BS 3/8 12 0.875 inch 0.06 lbs 0.752 inch 16
462 S1613BS S1613BS 3/8 13 0.973 inch 0.08 lbs 0.812 inch 16
463 S1614BS S1614BS 3/8 14 1.000 inch 0.08 lbs 0.875 inch 16
464 S1615BS S1615BS 1/2 15 1.062 inch 0.10 lbs 0.937 inch 16
465 S1616BS S1616BS 1/2 16 1.125 inch 0.12 lbs 1.000 inch 16
466 S1618BS S1618BS 1/2 18 1.250 inch 0.16 lbs 1.125 inch 16
467 S1620BS S1620BS 1/2 20 1.375 inch 0.22 lbs 1.250 inch 16
468 S1620BS S1620BS 5/8 20 1.375 inch 0.22 lbs 1.250 inch 16
469 S1622BS S1622BS 1/2 22 1.500 inch 0.28 lbs 1.375 inch 16
470 S1622BS S1622BS 5/8 22 1.500 inch 0.28 lbs 1.375 inch 16
471 S1624BS S1624BS 1/2 24 1.625 inch 0.34 lbs 1.500 inch 16
472 S1624BS S1624BS 5/8 24 1.625 inch 0.34 lbs 1.500 inch 16
473 S1624BS S1624BS 3/4 24 1.625 inch 0.34 lbs 1.500 inch 16
474 S1626BS S1626BS 1/2 26 1.750 inch 0.42 lbs 1.625 inch 16
475 S1626BS S1626BS 5/8 26 1.750 inch 0.42 lbs 1.625 inch 16
476 S1626BS S1626BS 3/4 26 1.750 inch 0.42 lbs 1.625 inch 16
477 S1628BS S1628BS 1/2 28 1.875 inch 0.52 lbs 1.750 inch 16
478 S1628BS S1628BS 5/8 28 1.875 inch 0.52 lbs 1.750 inch 16
479 S1628BS S1628BS 3/4 28 1.875 inch 0.52 lbs 1.750 inch 16
480 S1628BS S1628BS 7/8 28 1.875 inch 0.52 lbs 1.750 inch 16
481 S1630BS S1630BS 1/2 30 2.000 inch 0.60 lbs 1.875 inch 16
482 S1630BS S1630BS 5/8 30 2.000 inch 0.60 lbs 1.875 inch 16
483 S1630BS S1630BS 3/4 30 2.000 inch 0.60 lbs 1.875 inch 16
484 S1630BS S1630BS 7/8 30 2.000 inch 0.60 lbs 1.875 inch 16
485 S1630BS S1630BS 1 30 2.000 inch 0.60 lbs 1.875 inch 16
486 S1632BS S1632BS 1/2 32 2.125 inch 0.70 lbs 2.000 inch 16
487 S1632BS S1632BS 5/8 32 2.125 inch 0.70 lbs 2.000 inch 16
488 S1632BS S1632BS 3/4 32 2.125 inch 0.70 lbs 2.000 inch 16
489 S1632BS S1632BS 7/8 32 2.125 inch 0.70 lbs 2.000 inch 16
490 S1632BS S1632BS 1 32 2.125 inch 0.70 lbs 2.000 inch 16
491 S2011/ S2011 11 0.700 inch 0.02 lbs 0.600 inch 20
492 S2012/ S2012 12 0.700 inch 0.02 lbs 0.600 inch 20
493 S2013/ S2013 13 0.750 inch 0.04 lbs 0.650 inch 20
494 S2014/ S2014 14 0.800 inch 0.04 lbs 0.700 inch 20
495 S2015/ S2015 15 0.850 inch 0.04 lbs 0.750 inch 20
496 S2016/ S2016 16 0.900 inch 0.04 lbs 0.800 inch 20
497 S2017/ S2017 17 0.950 inch 0.08 lbs 0.850 inch 20
498 S2018/ S2018 18 1.000 inch 0.08 lbs 0.900 inch 20
499 S2019/ S2019 19 1.050 inch 0.10 lbs 0.950 inch 20
500 S2020/ S2020 20 1.100 inch 0.12 lbs 1.000 inch 20
