Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
101 S512/ S512 12 2.800 inch 2.00 lbs 2.400 inch 5
102 S513/ S513 13 3.000 inch 2.60 lbs 2.600 inch 5
103 S514/ S514 14 3.200 inch 3.10 lbs 2.800 inch 5
104 S515/ S515 15 3.400 inch 3.70 lbs 3.000 inch 5
105 S516/ S516 16 3.600 inch 4.50 lbs 3.200 inch 5
106 S517/ S517 17 3.800 inch 5.20 lbs 3.400 inch 5
107 S518/ S518 18 4.000 inch 5.90 lbs 3.600 inch 5
108 S519/ S519 19 4.200 inch 6.70 lbs 3.800 inch 5
109 S520/ S520 20 4.400 inch 7.50 lbs 4.000 inch 5
110 S521/ S521 21 4.600 inch 8.10 lbs 4.200 inch 5
111 S522/ S522 22 4.800 inch 8.80 lbs 4.400 inch 5
112 S523/ S523 23 5.000 inch 9.50 lbs 4.600 inch 5
113 S524/ S524 24 5.200 inch 11.00 lbs 4.800 inch 5
114 S525/ S525 25 5.400 inch 11.80 lbs 5.000 inch 5
115 S526/ S526 26 5.600 inch 12.90 lbs 5.200 inch 5
116 S528/ S528 28 6.000 inch 14.30 lbs 5.600 inch 5
117 S530/ S530 30 6.400 inch 16.00 lbs 6.000 inch 5
118 S535/ S535 35 7.400 inch 22.80 lbs 7.000 inch 5
119 S540/ S540 40 8.400 inch 28.50 lbs 8.000 inch 5
120 S545/ S545 45 9.400 inch 35.00 lbs 9.000 inch 5
121 S550/ S550 50 10.400 inch 43.60 lbs 10.000 inch 5
122 S555/ S555 55 11.400 inch 52.00 lbs 11.000 inch 5
123 S560/ S560 60 12.400 inch 60.90 lbs 12.000 inch 5
124 S570/ S570 70 14.400 inch 48.40 lbs 14.000 inch 5
125 S580/ S580 80 16.400 inch 57.00 lbs 16.000 inch 5
126 S590/ S590 90 18.400 inch 67.00 lbs 18.000 inch 5
127 S5100/ S5100 100 20.400 inch 62.00 lbs 20.000 inch 5
128 S5110/ S5110 110 22.400 inch 87.60 lbs 22.000 inch 5
129 S5120/ S5120 120 24.400 inch 113.00 lbs 24.000 inch 5
130 C524/ C524 24 5.200 inch 9.90 lbs 4.800 inch 5
131 C525/ C525 25 5.400 inch 10.60 lbs 5.000 inch 5
132 C528/ C528 28 6.000 inch 12.10 lbs 5.600 inch 5
133 C530/ C530 30 6.400 inch 13.90 lbs 6.000 inch 5
134 C532/ C532 32 6.800 inch 13.50 lbs 6.400 inch 5
135 C535/ C535 35 7.400 inch 16.90 lbs 7.000 inch 5
136 C536/ C536 36 7.600 inch 15.50 lbs 7.200 inch 5
137 C540/ C540 40 8.400 inch 17.40 lbs 8.000 inch 5
138 C545/ C545 45 9.400 inch 20.30 lbs 9.000 inch 5
139 C548/ C548 48 10.000 inch 25.20 lbs 9.600 inch 5
140 C550/ C550 50 10.400 inch 23.70 lbs 10.000 inch 5
141 C554/ C554 54 11.200 inch 25.10 lbs 10.800 inch 5
142 C555/ C555 55 11.400 inch 26.00 lbs 11.000 inch 5
143 C560/ C560 60 12.400 inch 30.60 lbs 12.000 inch 5
144 C564/ C564 64 13.200 inch 31.20 lbs 12.800 inch 5
145 C566/ C566 66 13.600 inch 30.80 lbs 13.200 inch 5
146 C570/ C570 70 14.400 inch 34.50 lbs 14.000 inch 5
147 C572/ C572 72 14.800 inch 35.00 lbs 14.400 inch 5
148 C575/ C575 75 15.400 inch 36.70 lbs 15.000 inch 5
149 C580/ C580 80 16.400 inch 40.80 lbs 16.000 inch 5
150 C584/ C584 84 17.200 inch 40.00 lbs 16.800 inch 5
151 C590/ C590 90 18.400 inch 45.40 lbs 18.000 inch 5
152 C596/ C596 96 19.600 inch 48.60 lbs 19.200 inch 5
153 C5100/ C5100 100 20.400 inch 54.40 lbs 20.000 inch 5
154 C5120/ C5120 120 24.400 inch 56.10 lbs 24.000 inch 5
155 C5130/ C5130 130 26.400 inch 70.20 lbs 26.000 inch 5
156 S611/ S611 11 2.333 inch 1.10 lbs 2.000 inch 6
157 S612/ S612 12 2.333 inch 1.10 lbs 2.000 inch 6
158 S614/ S614 14 2.666 inch 1.80 lbs 2.333 inch 6
159 S615/ S615 15 2.833 inch 2.20 lbs 2.500 inch 6
160 S616/ S616 16 3.000 inch 2.60 lbs 2.666 inch 6
161 S618/ S618 18 3.333 inch 3.50 lbs 3.000 inch 6
162 S620/ S620 20 3.666 inch 4.60 lbs 3.333 inch 6
163 S621/ S621 21 3.833 inch 5.10 lbs 3.500 inch 6
164 S622/ S622 22 4.000 inch 5.50 lbs 3.666 inch 6
165 S624/ S624 24 4.333 inch 6.50 lbs 4.000 inch 6
166 S627/ S627 27 4.833 inch 6.60 lbs 4.500 inch 6
167 S628/ S628 28 5.000 inch 8.30 lbs 4.666 inch 6
168 S630/ S630 30 5.333 inch 9.50 lbs 5.000 inch 6
169 S632/ S632 32 5.666 inch 10.70 lbs 5.333 inch 6
170 S633/ S633 33 5.833 inch 11.30 lbs 5.500 inch 6
171 S636/ S636 36 6.333 inch 13.30 lbs 6.000 inch 6
172 S639/ S639 39 6.833 inch 16.60 lbs 6.500 inch 6
173 S640/ S640 40 7.000 inch 17.60 lbs 6.666 inch 6
174 S642/ S642 42 7.333 inch 18.90 lbs 7.000 inch 6
175 S645/ S645 45 7.833 inch 21.30 lbs 7.500 inch 6
176 S648/ S648 48 8.333 inch 24.30 lbs 8.000 inch 6
177 S652/ S652 52 9.000 inch 27.90 lbs 8.666 inch 6
178 S654/ S654 54 9.333 inch 30.40 lbs 9.000 inch 6
179 S658/ S658 58 10.000 inch 33.90 lbs 9.666 inch 6
180 S660/ S660 60 10.333 inch 34.30 lbs 10.000 inch 6
181 S664/ S664 64 11.000 inch 42.20 lbs 10.666 inch 6
182 S666/ S666 66 11.333 inch 50.00 lbs 11.000 inch 6
183 S672/ S672 72 12.333 inch 53.00 lbs 12.000 inch 6
184 S684/ S684 84 14.333 inch 40.00 lbs 14.000 inch 6
185 S696/ S696 96 16.333 inch 43.80 lbs 16.000 inch 6
186 S6108/ S6108 108 18.333 inch 53.00 lbs 18.000 inch 6
187 S6120/ S6120 120 20.333 inch 63.20 lbs 20.000 inch 6
188 S6132/ S6132 132 22.333 inch 68.30 lbs 22.000 inch 6
189 S6144/ S6144 144 24.333 inch 82.70 lbs 24.000 inch 6
190 C632/ C632 32 5.666 inch 7.20 lbs 5.333 inch 6
191 C640/ C640 40 7.000 inch 11.90 lbs 6.666 inch 6
192 C642/ C642 42 7.333 inch 13.00 lbs 7.000 inch 6
193 C648/ C648 48 8.333 inch 12.10 lbs 8.000 inch 6
194 C654/ C654 54 9.333 inch 14.40 lbs 9.000 inch 6
195 C660/ C660 60 10.333 inch 17.00 lbs 10.000 inch 6
196 C664/ C664 64 11.000 inch 18.50 lbs 10.666 inch 6
197 C666/ C666 66 11.333 inch 19.00 lbs 11.000 inch 6
198 C670/ C670 70 12.000 inch 20.60 lbs 11.666 inch 6
199 C672/ C672 72 12.333 inch 23.70 lbs 12.000 inch 6
200 C675/ C675 75 12.833 inch 25.40 lbs 12.500 inch 6
