Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
801 TS1220BS TS1220BS 3/4 20 1.833 inch 0.65 lbs 1.667 inch 12
802 TS1221BS TS1221BS 3/4 21 1.917 inch 0.75 lbs 1.750 inch 12
803 TS1221BS TS1221BS 7/8 21 1.917 inch 0.75 lbs 1.750 inch 12
804 TS1224BS TS1224BS 3/4 24 2.167 inch 1.06 lbs 2.000 inch 12
805 TS1224BS TS1224BS 7/8 24 2.167 inch 1.06 lbs 2.000 inch 12
806 TS1224BS TS1224BS 1 24 2.167 inch 1.06 lbs 2.000 inch 12
807 TS1228BS TS1228BS 3/4 28 2.500 inch 1.60 lbs 2.333 inch 12
808 TS1228BS TS1228BS 7/8 28 2.500 inch 1.60 lbs 2.333 inch 12
809 TS1228BS TS1228BS 1 28 2.500 inch 1.60 lbs 2.333 inch 12
810 TS1612/ TS1612 12 0.875 inch 0.09 lbs 0.750 inch 16
811 TS1613/ TS1613 13 0.938 inch 0.11 lbs 0.812 inch 16
812 TS1614/ TS1614 14 1.000 inch 0.14 lbs 0.875 inch 16
813 TS1615/ TS1615 15 1.063 inch 0.17 lbs 0.937 inch 16
814 TS1616/ TS1616 16 1.125 inch 0.17 lbs 1.000 inch 16
815 TS1617/ TS1617 17 1.188 inch 0.20 lbs 1.062 inch 16
816 TS1618/ TS1618 18 1.250 inch 0.24 lbs 1.125 inch 16
817 TS1620/ TS1620 20 1.375 inch 0.28 lbs 1.250 inch 16
818 TS1621/ TS1621 21 1.438 inch 0.32 lbs 1.312 inch 16
819 TS1622/ TS1622 22 1.500 inch 0.36 lbs 1.375 inch 16
820 TS1624/ TS1624 24 1.625 inch 0.46 lbs 1.500 inch 16
821 TS1626/ TS1626 26 1.750 inch 0.56 lbs 1.625 inch 16
822 TS1628/ TS1628 28 1.875 inch 0.65 lbs 1.750 inch 16
823 TS1630/ TS1630 30 2.000 inch 0.77 lbs 1.875 inch 16
824 TS1632/ TS1632 32 2.125 inch 0.90 lbs 2.000 inch 16
825 TS1636/ TS1636 36 2.375 inch 1.18 lbs 2.250 inch 16
826 TS1640/ TS1640 40 2.625 inch 1.48 lbs 2.500 inch 16
827 TS1648/ TS1648 48 3.125 inch 1.94 lbs 3.000 inch 16
828 TS1656/ TS1656 56 3.625 inch 2.79 lbs 3.500 inch 16
829 TS1660/ TS1660 60 3.875 inch 3.28 lbs 3.750 inch 16
830 TS1664/ TS1664 64 4.125 inch 3.74 lbs 4.000 inch 16
831 TS1672/ TS1672 72 4.625 inch 4.69 lbs 4.500 inch 16
832 TS1680/ TS1680 80 5.125 inch 6.03 lbs 5.000 inch 16
833 TS1684/ TS1684 84 5.375 inch 6.46 lbs 5.250 inch 16
834 TS1696/ TS1696 96 6.125 inch 7.86 lbs 6.000 inch 16
835 TC16112/ TC16112 112 7.125 inch 4.40 lbs 7.000 inch 16
836 TC16128/ TC16128 128 8.125 inch 5.50 lbs 8.000 inch 16
837 TC16144/ TC16144 144 9.125 inch 6.40 lbs 9.000 inch 16
838 TC16160/ TC16160 160 10.125 inch 8.10 lbs 10.000 inch 16
839 TC16192/ TC16192 192 12.125 inch 10.10 lbs 12.000 inch 16
840 TS1612BS TS1612BS 3/8 12 0.875 inch 0.09 lbs 0.750 inch 16
841 TS1614BS TS1614BS 3/8 14 1.000 inch 0.14 lbs 0.875 inch 16
842 TS1615BS TS1615BS 3/8 15 1.063 inch 0.17 lbs 0.937 inch 16
843 TS1615BS TS1615BS 1/2 15 1.063 inch 0.17 lbs 0.937 inch 16
844 TS1616BS TS1616BS 1/2 16 1.125 inch 0.17 lbs 1.000 inch 16
845 TS1618BS TS1618BS 1/2 18 1.250 inch 0.24 lbs 1.125 inch 16
846 TS1620BS TS1620BS 5/8 20 1.375 inch 0.28 lbs 1.250 inch 16
847 TS1624BS TS1624BS 5/8 24 1.625 inch 0.46 lbs 1.500 inch 16
848 TS1624BS TS1624BS 3/4 24 1.625 inch 0.46 lbs 1.500 inch 16
849 TS1628BS TS1628BS 5/8 28 1.875 inch 0.65 lbs 1.750 inch 16
850 TS1628BS TS1628BS 3/4 28 1.875 inch 0.65 lbs 1.750 inch 16
851 TS1630BS TS1630BS 5/8 30 2.000 inch 0.77 lbs 1.875 inch 16
852 TS1630BS TS1630BS 3/4 30 2.000 inch 0.77 lbs 1.875 inch 16
853 TS1630BS TS1630BS 7/8 30 2.000 inch 0.77 lbs 1.875 inch 16
854 TS1632BS TS1632BS 5/8 32 2.125 inch 0.90 lbs 2.000 inch 16
855 TS1632BS TS1632BS 3/4 32 2.125 inch 0.90 lbs 2.000 inch 16
856 TS1632BS TS1632BS 7/8 32 2.125 inch 0.90 lbs 2.000 inch 16
857 TS1632BS TS1632BS 1 32 2.125 inch 0.90 lbs 2.000 inch 16
858 TS2012/ TS2012 12 0.700 inch 0.04 lbs 0.600 inch 20
859 TS2014/ TS2014 14 0.800 inch 0.06 lbs 0.700 inch 20
860 TS2015/ TS2015 15 0.850 inch 0.07 lbs 0.750 inch 20
861 TS2016/ TS2016 16 0.900 inch 0.08 lbs 0.800 inch 20
862 TS2018/ TS2018 18 1.000 inch 0.12 lbs 0.900 inch 20
863 TS2020/ TS2020 20 1.100 inch 0.13 lbs 1.000 inch 20
864 TS2021/ TS2021 21 1.150 inch 0.15 lbs 1.050 inch 20
865 TS2022/ TS2022 22 1.200 inch 0.17 lbs 1.100 inch 20
866 TS2024/ TS2024 24 1.300 inch 0.22 lbs 1.200 inch 20
867 TS2025/ TS2025 25 1.350 inch 0.24 lbs 1.250 inch 20
868 TS2028/ TS2028 28 1.500 inch 0.32 lbs 1.400 inch 20
869 TS2030/ TS2030 30 1.600 inch 0.38 lbs 1.500 inch 20
870 TS2032/ TS2032 32 1.700 inch 0.46 lbs 1.600 inch 20
871 TS2035/ TS2035 35 1.850 inch 0.56 lbs 1.750 inch 20
872 TS2036/ TS2036 36 1.900 inch 0.60 lbs 1.800 inch 20
873 TS2040/ TS2040 40 2.100 inch 0.76 lbs 2.000 inch 20
874 TS2045/ TS2045 45 2.350 inch 0.95 lbs 2.250 inch 20
875 TS2050/ TS2050 50 2.600 inch 1.08 lbs 2.500 inch 20
876 TS2060/ TS2060 60 3.100 inch 1.45 lbs 3.000 inch 20
877 TS2070/ TS2070 70 3.600 inch 1.93 lbs 3.500 inch 20
878 TS2072/ TS2072 72 3.700 inch 2.01 lbs 3.600 inch 20
879 TS2080/ TS2080 80 4.100 inch 2.35 lbs 4.000 inch 20
880 TS2084/ TS2084 84 4.300 inch 2.53 lbs 4.200 inch 20
881 TS2090/ TS2090 90 4.600 inch 2.82 lbs 4.500 inch 20
882 TS2096/ TS2096 96 4.900 inch 3.14 lbs 4.800 inch 20
883 TS20100/ TS20100 100 5.100 inch 3.35 lbs 5.000 inch 20
884 TS20120/ TS20120 120 6.100 inch 4.58 lbs 6.000 inch 20
885 TS2012BS TS2012BS 5/16 12 0.700 inch 0.04 lbs 0.600 inch 20
886 TS2014BS TS2014BS 5/16 14 0.800 inch 0.06 lbs 0.700 inch 20
887 TS2015BS TS2015BS 3/8 15 0.850 inch 0.07 lbs 0.750 inch 20
888 TS2016BS TS2016BS 3/8 16 0.900 inch 0.08 lbs 0.800 inch 20
889 TS2018BS TS2018BS 3/8 18 1.000 inch 0.12 lbs 0.900 inch 20
890 TS2020BS TS2020BS 1/2 20 1.100 inch 0.13 lbs 1.000 inch 20
891 TS2024BS TS2024BS 1/2 24 1.300 inch 0.22 lbs 1.200 inch 20
892 TS2025BS TS2025BS 1/2 25 1.350 inch 0.24 lbs 1.250 inch 20
893 TS2030BS TS2030BS 1/2 30 1.600 inch 0.38 lbs 1.500 inch 20
894 TS2035BS TS2035BS 1/2 35 1.850 inch 0.56 lbs 1.750 inch 20
895 TS2040BS TS2040BS 1/2 40 2.100 inch 0.76 lbs 2.000 inch 20
896 TS2040BS TS2040BS 5/8 40 2.100 inch 0.76 lbs 2.000 inch 20
897 TS2040BS TS2040BS 3/4 40 2.100 inch 0.76 lbs 2.000 inch 20
