Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
501 S2021/ S2021 21 1.150 inch 0.12 lbs 1.050 inch 20
502 S2022/ S2022 22 1.200 inch 0.14 lbs 1.100 inch 20
503 S2023/ S2023 23 1.250 inch 0.16 lbs 1.150 inch 20
504 S2024/ S2024 24 1.300 inch 0.19 lbs 1.200 inch 20
505 S2025/ S2025 25 1.350 inch 0.20 lbs 1.250 inch 20
506 S2028/ S2028 28 1.500 inch 0.26 lbs 1.400 inch 20
507 S2030/ S2030 30 1.600 inch 0.30 lbs 1.500 inch 20
508 S2032/ S2032 32 1.700 inch 0.40 lbs 1.600 inch 20
509 S2035/ S2035 35 1.850 inch 0.50 lbs 1.750 inch 20
510 S2036/ S2036 36 1.900 inch 0.52 lbs 1.800 inch 20
511 S2040/ S2040 40 2.100 inch 0.64 lbs 2.000 inch 20
512 S2045/ S2045 45 2.350 inch 0.82 lbs 2.250 inch 20
513 S2048/ S2048 48 2.500 inch 0.88 lbs 2.400 inch 20
514 S2050/ S2050 50 2.600 inch 0.90 lbs 2.500 inch 20
515 S2055/ S2055 55 2.850 inch 1.04 lbs 2.750 inch 20
516 S2060/ S2060 60 3.100 inch 1.16 lbs 3.000 inch 20
517 S2064/ S2064 64 3.300 inch 1.26 lbs 3.200 inch 20
518 S2070/ S2070 70 3.600 inch 1.40 lbs 3.500 inch 20
519 S2072/ S2072 72 3.700 inch 1.60 lbs 3.600 inch 20
520 S2075/ S2075 75 3.850 inch 1.70 lbs 3.750 inch 20
521 S2080/ S2080 80 4.100 inch 1.82 lbs 4.000 inch 20
522 S2084/ S2084 84 4.300 inch 1.96 lbs 4.200 inch 20
523 S2090/ S2090 90 4.600 inch 2.20 lbs 4.500 inch 20
524 S2096/ S2096 96 4.900 inch 2.42 lbs 4.800 inch 20
525 S20100/ S20100 100 5.100 inch 2.60 lbs 5.000 inch 20
526 S20112/ S20112 112 5.700 inch 2.86 lbs 5.600 inch 20
527 S20120/ S20120 120 6.100 inch 3.24 lbs 6.000 inch 20
528 S20132/ S20132 132 6.700 inch 3.80 lbs 6.600 inch 20
529 C2048/ C2048 48 2.500 inch 0.50 lbs 2.400 inch 20
530 C2064/ C2064 64 3.300 inch 0.68 lbs 3.200 inch 20
531 C20140/ C20140 140 7.100 inch 2.00 lbs 7.000 inch 20
532 C20160/ C20160 160 8.100 inch 2.34 lbs 8.000 inch 20
533 C20180/ C20180 180 9.100 inch 2.66 lbs 9.000 inch 20
534 C20200/ C20200 200 10.100 inch 2.84 lbs 10.000 inch 20
535 S2011BS S2011BS 5/16 11 0.700 inch 0.02 lbs 0.600 inch 20
536 S2012BS S2012BS 5/16 12 0.700 inch 0.02 lbs 0.600 inch 20
537 S2013BS S2013BS 5/16 13 0.750 inch 0.04 lbs 0.650 inch 20
538 S2014BS S2014BS 5/16 14 0.800 inch 0.04 lbs 0.700 inch 20
539 S2015BS S2015BS 3/8 15 0.850 inch 0.04 lbs 0.750 inch 20
540 S2016BS S2016BS 3/8 16 0.900 inch 0.04 lbs 1.800 inch 20
541 S2018BS S2018BS 3/8 18 1.000 inch 0.08 lbs 1.900 inch 20
542 S2020BS S2020BS 3/8 20 1.100 inch 0.12 lbs 1.000 inch 20
543 S2020BS S2020BS 1/2 20 1.100 inch 0.12 lbs 1.000 inch 20
544 S2022BS S2022BS 3/8 22 1.200 inch 0.14 lbs 1.100 inch 20
545 S2022BS S2022BS 1/2 22 1.200 inch 0.14 lbs 1.100 inch 20
546 S2024BS S2024BS 3/8 24 1.300 inch 0.19 lbs 1.200 inch 20
547 S2024BS S2024BS 1/2 24 1.300 inch 0.19 lbs 1.200 inch 20
548 S2025BS S2025BS 3/8 25 1.350 inch 0.20 lbs 1.250 inch 20
549 S2025BS S2025BS 1/2 25 1.350 inch 0.20 lbs 1.250 inch 20
550 S2028BS S2028BS 3/8 28 1.500 inch 0.26 lbs 1.400 inch 20
551 S2028BS S2028BS 1/2 28 1.500 inch 0.26 lbs 1.400 inch 20
552 S2030BS S2030BS 3/8 30 1.600 inch 0.30 lbs 1.500 inch 20
553 S2030BS S2030BS 1/2 30 1.600 inch 0.30 lbs 1.500 inch 20
554 S2032BS S2032BS 3/8 32 1.700 inch 0.40 lbs 1.600 inch 20
555 S2032BS S2032BS 1/2 32 1.700 inch 0.40 lbs 1.600 inch 20
556 S2035BS S2035BS 3/8 35 1.850 inch 0.50 lbs 1.750 inch 20
557 S2035BS S2035BS 1/2 35 1.850 inch 0.50 lbs 1.750 inch 20
558 S2036BS S2036BS 3/8 36 1.900 inch 0.52 lbs 1.800 inch 20
559 S2036BS S2036BS 1/2 36 1.900 inch 0.52 lbs 1.800 inch 20
560 S2040BS S2040BS 3/8 40 2.100 inch 0.64 lbs 2.000 inch 20
561 S2040BS S2040BS 1/2 40 2.100 inch 0.64 lbs 2.000 inch 20
562 S2040BS S2040BS 5/8 40 2.100 inch 0.64 lbs 2.000 inch 20
563 S2040BS S2040BS 3/4 40 2.100 inch 0.64 lbs 2.000 inch 20
564 S2411/ S2411 11 0.583 inch 0.02 lbs 0.500 inch 24
565 S2412/ S2412 12 0.583 inch 0.02 lbs 0.500 inch 24
566 S2414/ S2414 14 0.666 inch 0.04 lbs 0.583 inch 24
567 S2415/ S2415 15 0.708 inch 0.04 lbs 0.625 inch 24
568 S2416/ S2416 16 0.750 inch 0.04 lbs 0.666 inch 24
569 S2417/ S2417 17 0.791 inch 0.04 lbs 0.709 inch 24
570 S2418/ S2418 18 0.833 inch 0.04 lbs 0.750 inch 24
571 S2419/ S2419 19 0.875 inch 0.06 lbs 0.791 inch 24
572 S2420/ S2420 20 0.917 inch 0.06 lbs 0.833 inch 24
573 S2421/ S2421 21 0.959 inch 0.06 lbs 0.875 inch 24
574 S2422/ S2422 22 1.000 inch 0.06 lbs 0.917 inch 24
575 S2424/ S2424 24 1.083 inch 0.10 lbs 1.000 inch 24
576 S2426/ S2426 26 1.166 inch 0.10 lbs 1.083 inch 24
577 S2427/ S2427 27 1.208 inch 0.12 lbs 1.125 inch 24
578 S2430/ S2430 30 1.333 inch 0.16 lbs 1.250 inch 24
579 S2432/ S2432 32 1.416 inch 0.20 lbs 1.333 inch 24
580 S2433/ S2433 33 1.458 inch 0.20 lbs 1.375 inch 24
581 S2436/ S2436 36 1.583 inch 0.20 lbs 1.500 inch 24
582 S2440/ S2440 40 1.750 inch 0.24 lbs 1.666 inch 24
583 S2442/ S2442 42 1.833 inch 0.28 lbs 1.750 inch 24
584 S2444/ S2444 44 1.917 inch 0.30 lbs 1.833 inch 24
585 S2445/ S2445 45 1.959 inch 0.30 lbs 1.875 inch 24
586 S2448/ S2448 48 2.083 inch 0.32 lbs 2.000 inch 24
587 S2454/ S2454 54 2.333 inch 0.38 lbs 2.250 inch 24
588 S2456/ S2456 56 2.416 inch 0.40 lbs 2.333 inch 24
589 S2460/ S2460 60 2.583 inch 0.46 lbs 2.500 inch 24
590 S2466/ S2466 66 2.833 inch 0.52 lbs 2.750 inch 24
591 S2472/ S2472 72 3.083 inch 0.64 lbs 3.000 inch 24
592 S2484/ S2484 84 3.583 inch 0.88 lbs 3.500 inch 24
593 S2496/ S2496 96 4.083 inch 1.08 lbs 4.000 inch 24
594 S24120/ S24120 120 5.083 inch 2.60 lbs 5.000 inch 24
595 S24144/ S24144 144 6.083 inch 2.28 lbs 6.000 inch 24
596 TS412/ TS412 12 3.500 inch 6.80 lbs 3.000 inch 4
597 TS414/ TS414 14 4.000 inch 9.80 lbs 3.500 inch 4
598 TS415/ TS415 15 4.250 inch 11.50 lbs 3.750 inch 4
599 TS416/ TS416 16 4.500 inch 13.30 lbs 4.000 inch 4
600 TS418/ TS418 18 5.000 inch 17.30 lbs 4.500 inch 4
