Image may differ from product. See technical specification for details.
Search for the bearing model you need
Standard
GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh
Material
42CrMo, 50Mn
Pitch diameter
4-36 inch
Outer diameter (D)
4.666-36.5 inch
Weight
12-140 lbs
Brand
QIBR/OEM/Neutral
Package
QIBR/Standard Industrial Package/OEM
Applications
suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.
| NO. | Product | Product Number | Number of teeth (z) | Outer diameter (D) | Weight | Pitch diameter | Pitch (DP) |
|---|---|---|---|---|---|---|---|
| 601 |
|
TS420 | 20 | 5.500 inch | 21.80 lbs | 5.000 inch | 4 |
| 602 |
|
TS422 | 22 | 6.000 inch | 26.70 lbs | 5.500 inch | 4 |
| 603 |
|
TS424 | 24 | 6.500 inch | 33.70 lbs | 6.000 inch | 4 |
| 604 |
|
TS428 | 28 | 7.500 inch | 43.80 lbs | 7.000 inch | 4 |
| 605 |
|
TS430 | 30 | 8.000 inch | 49.40 lbs | 7.500 inch | 4 |
| 606 |
|
TS432 | 32 | 8.500 inch | 56.80 lbs | 8.000 inch | 4 |
| 607 |
|
TS436 | 36 | 9.500 inch | 70.00 lbs | 9.000 inch | 4 |
| 608 |
|
TS440 | 40 | 10.500 inch | 85.20 lbs | 10.000 inch | 4 |
| 609 |
|
TS444 | 44 | 11.500 inch | 101.60 lbs | 11.000 inch | 4 |
| 610 |
|
TS448 | 48 | 12.500 inch | 119.50 lbs | 12.000 inch | 4 |
| 611 |
|
TS456 | 56 | 14.500 inch | 96.90 lbs | 14.000 inch | 4 |
| 612 |
|
TS460 | 60 | 15.500 inch | 88.10 lbs | 15.000 inch | 4 |
| 613 |
|
TS464 | 64 | 16.500 inch | 86.90 lbs | 16.000 inch | 4 |
| 614 |
|
TS472 | 72 | 18.500 inch | 86.50 lbs | 18.000 inch | 4 |
| 615 |
|
TS480 | 80 | 20.500 inch | 90.90 lbs | 20.000 inch | 4 |
| 616 |
|
TS512 | 12 | 2.800 inch | 2.90 lbs | 2.400 inch | 5 |
| 617 |
|
TS514 | 14 | 3.200 inch | 4.30 lbs | 2.800 inch | 5 |
| 618 |
|
TS515 | 15 | 3.400 inch | 5.20 lbs | 3.000 inch | 5 |
| 619 |
|
TS516 | 16 | 3.600 inch | 6.10 lbs | 3.200 inch | 5 |
| 620 |
|
TS518 | 18 | 4.000 inch | 8.00 lbs | 3.600 inch | 5 |
| 621 |
|
TS520 | 20 | 4.400 inch | 10.20 lbs | 4.000 inch | 5 |
| 622 |
|
TS524 | 24 | 5.200 inch | 15.70 lbs | 4.800 inch | 5 |
| 623 |
|
TS525 | 25 | 5.400 inch | 20.30 lbs | 5.000 inch | 5 |
| 624 |
|
TS528 | 28 | 6.000 inch | 22.90 lbs | 5.600 inch | 5 |
| 625 |
|
TS530 | 30 | 6.400 inch | 23.90 lbs | 6.000 inch | 5 |
| 626 |
|
TS535 | 35 | 7.400 inch | 29.90 lbs | 7.000 inch | 5 |
| 627 |
|
TS540 | 40 | 8.400 inch | 38.20 lbs | 8.000 inch | 5 |
| 628 |
|
TS545 | 45 | 9.400 inch | 47.70 lbs | 9.000 inch | 5 |
| 629 |
|
TS550 | 50 | 10.400 inch | 60.30 lbs | 10.000 inch | 5 |
| 630 |
|
TS560 | 60 | 12.400 inch | 84.70 lbs | 12.000 inch | 5 |
| 631 |
|
TS570 | 70 | 14.400 inch | 51.60 lbs | 14.000 inch | 5 |
| 632 |
|
TS580 | 80 | 16.400 inch | 55.80 lbs | 16.000 inch | 5 |
| 633 |
|
TS590 | 90 | 18.400 inch | 59.70 lbs | 18.000 inch | 5 |
| 634 |
|
TS5100 | 100 | 20.400 inch | 69.20 lbs | 20.000 inch | 5 |
| 635 |
|
TS5110 | 110 | 22.400 inch | 72.30 lbs | 22.000 inch | 5 |
| 636 |
|
TS5120 | 120 | 24.400 inch | 80.20 lbs | 24.000 inch | 5 |
| 637 |
|
TS611 | 11 | 2.333 inch | 1.60 lbs | 2.000 inch | 6 |
| 638 |
|
TS612 | 12 | 2.333 inch | 1.60 lbs | 2.000 inch | 6 |
| 639 |
|
TS614 | 14 | 2.666 inch | 2.40 lbs | 2.333 inch | 6 |
| 640 |
|
TS615 | 15 | 2.833 inch | 2.90 lbs | 2.500 inch | 6 |
| 641 |
|
TS616 | 16 | 3.000 inch | 3.40 lbs | 2.666 inch | 6 |
| 642 |
|
TS618 | 18 | 3.333 inch | 4.60 lbs | 3.000 inch | 6 |
| 643 |
|
TS621 | 21 | 3.833 inch | 6.60 lbs | 3.500 inch | 6 |
| 644 |
|
TS624 | 24 | 4.333 inch | 8.10 lbs | 4.000 inch | 6 |
| 645 |
|
TS627 | 27 | 4.833 inch | 10.60 lbs | 4.500 inch | 6 |
| 646 |
|
TS630 | 30 | 5.333 inch | 13.40 lbs | 5.000 inch | 6 |
| 647 |
|
TS633 | 33 | 5.833 inch | 17.80 lbs | 5.500 inch | 6 |
| 648 |
|
TS636 | 36 | 6.333 inch | 20.40 lbs | 6.000 inch | 6 |
| 649 |
|
TS642 | 42 | 7.333 inch | 26.20 lbs | 7.000 inch | 6 |
| 650 |
|
TS648 | 48 | 8.333 inch | 32.80 lbs | 8.000 inch | 6 |
| 651 |
|
TS654 | 54 | 9.333 inch | 40.40 lbs | 9.000 inch | 6 |
| 652 |
|
TS660 | 60 | 10.333 inch | 50.00 lbs | 10.000 inch | 6 |
| 653 |
|
TS664 | 64 | 11.000 inch | 56.50 lbs | 10.666 inch | 6 |
| 654 |
|
TS666 | 66 | 11.333 inch | 59.80 lbs | 11.000 inch | 6 |
| 655 |
|
TS672 | 72 | 12.333 inch | 70.00 lbs | 12.000 inch | 6 |
| 656 |
|
TS684 | 84 | 14.333 inch | 42.80 lbs | 14.000 inch | 6 |
| 657 |
|
TS696 | 96 | 16.333 inch | 46.00 lbs | 16.000 inch | 6 |
| 658 |
|
TS6108 | 108 | 18.333 inch | 48.80 lbs | 18.000 inch | 6 |
| 659 |
|
TS6120 | 120 | 20.333 inch | 51.30 lbs | 20.000 inch | 6 |
| 660 |
|
TS612BS 1 | 12 | 2.333 inch | 1.60 lbs | 2.000 inch | 6 |
| 661 |
|
TS614BS 1 | 14 | 2.667 inch | 2.40 lbs | 2.333 inch | 6 |
| 662 |
|
TS614BS 1-1/8 | 14 | 2.667 inch | 2.40 lbs | 2.333 inch | 6 |
| 663 |
|
TS615BS 1 | 15 | 2.833 inch | 2.90 lbs | 2.500 inch | 6 |
| 664 |
|
TS615BS 1-1/8 | 15 | 2.833 inch | 2.90 lbs | 2.500 inch | 6 |
| 665 |
|
TS615BS 1-3/16 | 15 | 2.833 inch | 2.90 lbs | 2.500 inch | 6 |
| 666 |
|
TS615BS 1-1/4 | 15 | 2.833 inch | 2.90 lbs | 2.500 inch | 6 |
| 667 |
|
TS616BS 1 | 16 | 3.000 inch | 3.40 lbs | 2.667 inch | 6 |
| 668 |
|
TS616BS 1-1/8 | 16 | 3.000 inch | 3.40 lbs | 2.667 inch | 6 |
| 669 |
|
TS616BS 1-3/16 | 16 | 3.000 inch | 3.40 lbs | 2.667 inch | 6 |
| 670 |
|
TS616BS 1-1/4 | 16 | 3.000 inch | 3.40 lbs | 2.667 inch | 6 |
| 671 |
|
TS618BS 1 | 18 | 3.333 inch | 4.60 lbs | 3.000 inch | 6 |
| 672 |
|
TS618BS 1-1/8 | 18 | 3.333 inch | 4.60 lbs | 3.000 inch | 6 |
| 673 |
|
TS618BS 1-3/16 | 18 | 3.333 inch | 4.60 lbs | 3.000 inch | 6 |
| 674 |
|
TS618BS 1-1/4 | 18 | 3.333 inch | 4.60 lbs | 3.000 inch | 6 |
| 675 |
|
TS621BS 1 | 21 | 3.833 inch | 6.60 lbs | 3.500 inch | 6 |
| 676 |
|
TS621BS 1-1/8 | 21 | 3.833 inch | 6.60 lbs | 3.500 inch | 6 |
| 677 |
|
TS621BS 1-3/16 | 21 | 3.833 inch | 6.60 lbs | 3.500 inch | 6 |
| 678 |
|
TS621BS 1-1/4 | 21 | 3.833 inch | 6.60 lbs | 3.500 inch | 6 |
| 679 |
|
TS812 | 12 | 1.750 inch | 0.70 lbs | 1.500 inch | 8 |
| 680 |
|
TS814 | 14 | 2.000 inch | 1.00 lbs | 1.750 inch | 8 |
| 681 |
|
TS815 | 15 | 2.125 inch | 1.20 lbs | 1.875 inch | 8 |
| 682 |
|
TS816 | 16 | 2.250 inch | 1.40 lbs | 2.000 inch | 8 |
| 683 |
|
TS818 | 18 | 2.500 inch | 1.90 lbs | 2.250 inch | 8 |
| 684 |
|
TS819 | 19 | 2.625 inch | 2.30 lbs | 2.375 inch | 8 |
| 685 |
|
TS820 | 20 | 2.750 inch | 2.50 lbs | 2.500 inch | 8 |
| 686 |
|
TS822 | 22 | 3.000 inch | 3.20 lbs | 2.750 inch | 8 |
| 687 |
|
TS824 | 24 | 3.250 inch | 3.90 lbs | 3.000 inch | 8 |
| 688 |
|
TS826 | 26 | 3.500 inch | 4.60 lbs | 3.250 inch | 8 |
| 689 |
|
TS828 | 28 | 3.750 inch | 5.20 lbs | 3.500 inch | 8 |
| 690 |
|
TS830 | 30 | 4.000 inch | 5.60 lbs | 3.750 inch | 8 |
| 691 |
|
TS832 | 32 | 4.250 inch | 6.60 lbs | 4.000 inch | 8 |
| 692 |
|
TS836 | 36 | 4.750 inch | 8.60 lbs | 4.500 inch | 8 |
| 693 |
|
TS840 | 40 | 5.250 inch | 10.20 lbs | 5.000 inch | 8 |
| 694 |
|
TS842 | 42 | 5.500 inch | 11.40 lbs | 5.250 inch | 8 |
| 695 |
|
TS844 | 44 | 5.750 inch | 12.30 lbs | 5.500 inch | 8 |
| 696 |
|
TS848 | 48 | 6.250 inch | 14.20 lbs | 6.000 inch | 8 |
| 697 |
|
TC852 | 52 | 6.750 inch | 11.90 lbs | 6.500 inch | 8 |
| 698 |
|
TC856 | 56 | 7.250 inch | 13.00 lbs | 7.000 inch | 8 |
| 699 |
|
TC860 | 60 | 7.750 inch | 12.00 lbs | 7.500 inch | 8 |
| 700 |
|
TC864 | 64 | 8.250 inch | 12.10 lbs | 8.000 inch | 8 |
