Spur Gears

Image may differ from product. See technical specification for details.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Material

42CrMo, 50Mn

Pitch diameter

4-36 inch

Outer diameter (D)

4.666-36.5 inch

Weight

12-140 lbs

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

suitable for the transmission system of packaging machines, printing machines and medical equipment, etc. It is the most widely used in working conditions with high precision requirements.

Spur Gears

Filters

NO. Product Product Number Number of teeth (z) Outer diameter (D) Weight Pitch diameter Pitch (DP)
701 TC872/ TC872 72 9.250 inch 14.40 lbs 9.000 inch 8
702 TC880/ TC880 80 10.250 inch 17.00 lbs 10.000 inch 8
703 TC888/ TC888 88 11.250 inch 19.00 lbs 11.000 inch 8
704 TC896/ TC896 96 12.250 inch 23.70 lbs 12.000 inch 8
705 TC8112/ TC8112 112 14.250 inch 25.00 lbs 14.000 inch 8
706 TC8120/ TC8120 120 15.250 inch 25.80 lbs 15.000 inch 8
707 TC8128/ TC8128 128 16.250 inch 28.00 lbs 16.000 inch 8
708 TC8144/ TC8144 144 18.250 inch 32.00 lbs 18.000 inch 8
709 TC8160/ TC8160 160 20.250 inch 34.80 lbs 20.000 inch 8
710 TS812BS TS812BS 3/4 12 1.750 inch 0.70 lbs 1.500 inch 8
711 TS814BS TS814BS 3/4 14 2.000 inch 1.00 lbs 1.750 inch 8
712 TS815BS TS815BS 3/4 15 2.125 inch 1.20 lbs 1.875 inch 8
713 TS815BS TS815BS 7/8 15 2.125 inch 1.20 lbs 1.875 inch 8
714 TS816BS TS816BS 7/8 16 2.250 inch 1.40 lbs 2.000 inch 8
715 TS816BS TS816BS 1 16 2.250 inch 1.40 lbs 2.000 inch 8
716 TS818BS TS818BS 7/8 18 2.500 inch 1.90 lbs 2.250 inch 8
717 TS818BS TS818BS 1 18 2.500 inch 1.90 lbs 2.250 inch 8
718 TS818BS TS818BS 1-1/8 18 2.500 inch 1.90 lbs 2.250 inch 8
719 TS820BS TS820BS 7/8 20 2.750 inch 2.50 lbs 2.500 inch 8
720 TS820BS TS820BS 1 20 2.750 inch 2.50 lbs 2.500 inch 8
721 TS820BS TS820BS 1-1/8 20 2.750 inch 2.50 lbs 2.500 inch 8
722 TS822BS TS822BS 7/8 22 3.000 inch 3.20 lbs 2.750 inch 8
723 TS822BS TS822BS 1 22 3.000 inch 3.20 lbs 2.750 inch 8
724 TS822BS TS822BS 1-1/8 22 3.000 inch 3.20 lbs 2.750 inch 8
725 TS824BS TS824BS 7/8 24 3.250 inch 3.90 lbs 3.000 inch 8
726 TS824BS TS824BS 1 24 3.250 inch 3.90 lbs 3.000 inch 8
727 TS824BS TS824BS 1-1/8 24 3.250 inch 3.90 lbs 3.000 inch 8
728 TS1012/ TS1012 12 1.400 inch 0.40 lbs 1.200 inch 10
729 TS1014/ TS1014 14 1.600 inch 0.60 lbs 1.400 inch 10
730 TS1015/ TS1015 15 1.700 inch 0.60 lbs 1.500 inch 10
731 TS1016/ TS1016 16 1.800 inch 0.70 lbs 1.600 inch 10
732 TS1018/ TS1018 18 2.000 inch 0.90 lbs 1.800 inch 10
733 TS1020/ TS1020 20 2.200 inch 1.20 lbs 2.000 inch 10
734 TS1022/ TS1022 22 2.400 inch 1.50 lbs 2.200 inch 10
735 TS1024/ TS1024 24 2.600 inch 1.80 lbs 2.400 inch 10
736 TS1025/ TS1025 25 2.700 inch 2.00 lbs 2.500 inch 10
737 TS1026/ TS1026 26 2.800 inch 2.20 lbs 2.600 inch 10
738 TS1028/ TS1028 28 3.000 inch 2.70 lbs 2.800 inch 10
739 TS1030/ TS1030 30 3.200 inch 3.40 lbs 3.000 inch 10
740 TS1032/ TS1032 32 3.400 inch 3.70 lbs 3.200 inch 10
741 TS1035/ TS1035 35 3.700 inch 4.20 lbs 3.500 inch 10
742 TS1036/ TS1036 36 3.800 inch 4.30 lbs 3.600 inch 10
743 TS1040/ TS1040 40 4.200 inch 6.40 lbs 4.000 inch 10
744 TS1045/ TS1045 45 4.700 inch 7.50 lbs 4.500 inch 10
745 TS1048/ TS1048 48 5.000 inch 8.70 lbs 4.800 inch 10
746 TS1050/ TS1050 50 5.200 inch 9.60 lbs 5.000 inch 10
747 TS1055/ TS1055 55 5.700 inch 11.50 lbs 5.500 inch 10
748 TS1060/ TS1060 60 6.200 inch 13.10 lbs 6.000 inch 10
749 TC1070/ TC1070 70 7.200 inch 8.20 lbs 7.000 inch 10
750 TC1080/ TC1080 80 8.200 inch 11.20 lbs 8.000 inch 10
751 TC1090/ TC1090 90 9.200 inch 11.70 lbs 9.000 inch 10
752 TC10100/ TC10100 100 10.200 inch 12.20 lbs 10.000 inch 10
753 TS1012BS TS1012BS 5/8 12 1.400 inch 0.40 lbs 1.200 inch 10
754 TS1014BS TS1014BS 5/8 14 1.600 inch 0.60 lbs 1.400 inch 10
755 TS1015BS TS1015BS 3/4 15 1.700 inch 0.60 lbs 1.500 inch 10
756 TS1016BS TS1016BS 3/4 16 1.800 inch 0.70 lbs 1.600 inch 10
757 TS1018BS TS1018BS 3/4 18 2.000 inch 0.88 lbs 1.800 inch 10
758 TS1018BS TS1018BS 7/8 18 2.000 inch 0.90 lbs 1.800 inch 10
759 TS1020BS TS1020BS 7/8 20 2.200 inch 1.20 lbs 2.000 inch 10
760 TS1020BS TS1020BS 1 20 2.200 inch 1.20 lbs 2.000 inch 10
761 TS1024BS TS1024BS 7/8 24 2.600 inch 1.50 lbs 2.400 inch 10
762 TS1024BS TS1024BS 1 24 2.600 inch 1.50 lbs 2.400 inch 10
763 TS1025BS TS1025BS 7/8 25 2.700 inch 2.00 lbs 2.500 inch 10
764 TS1025BS TS1025BS 1 25 2.700 inch 2.00 lbs 2.500 inch 10
765 TS1028BS TS1028BS 7/8 28 3.000 inch 2.70 lbs 2.800 inch 10
766 TS1028BS TS1028BS 1 28 3.000 inch 2.70 lbs 2.800 inch 10
767 TS1212/ TS1212 12 1.167 inch 0.21 lbs 1.000 inch 12
768 TS1213/ TS1213 13 1.250 inch 0.21 lbs 1.083 inch 12
769 TS1214/ TS1214 14 1.333 inch 0.28 lbs 1.167 inch 12
770 TS1215/ TS1215 15 1.417 inch 0.34 lbs 1.250 inch 12
771 TS1216/ TS1216 16 1.500 inch 0.41 lbs 1.333 inch 12
772 TS1218/ TS1218 18 1.667 inch 0.51 lbs 1.500 inch 12
773 TS1219/ TS1219 19 1.750 inch 0.59 lbs 1.583 inch 12
774 TS1220/ TS1220 20 1.833 inch 0.65 lbs 1.667 inch 12
775 TS1221/ TS1221 21 1.917 inch 0.75 lbs 1.750 inch 12
776 TS1222/ TS1222 22 2.000 inch 0.88 lbs 1.833 inch 12
777 TS1224/ TS1224 24 2.166 inch 1.06 lbs 2.000 inch 12
778 TS1225/ TS1225 25 2.250 inch 1.22 lbs 2.083 inch 12
779 TS1226/ TS1226 26 2.333 inch 1.33 lbs 2.167 inch 12
780 TS1228/ TS1228 28 2.500 inch 1.60 lbs 2.333 inch 12
781 TS1230/ TS1230 30 2.667 inch 1.83 lbs 2.500 inch 12
782 TS1232/ TS1232 32 2.833 inch 2.08 lbs 2.667 inch 12
783 TS1236/ TS1236 36 3.167 inch 2.98 lbs 3.000 inch 12
784 TS1242/ TS1242 42 3.666 inch 3.71 lbs 3.500 inch 12
785 TS1248/ TS1248 48 4.166 inch 4.99 lbs 4.000 inch 12
786 TS1254/ TS1254 54 4.666 inch 6.57 lbs 4.500 inch 12
787 TS1260/ TS1260 60 5.166 inch 7.63 lbs 5.000 inch 12
788 TS1266/ TS1266 66 5.666 inch 8.80 lbs 5.500 inch 12
789 TS1272/ TS1272 72 6.166 inch 10.08 lbs 6.000 inch 12
790 TC1284/ TC1284 84 7.166 inch 5.90 lbs 7.000 inch 12
791 TC1296/ TC1296 96 8.166 inch 7.00 lbs 8.000 inch 12
792 TC12108/ TC12108 108 9.166 inch 7.60 lbs 9.000 inch 12
793 TC12120/ TC12120 120 10.166 inch 10.30 lbs 10.000 inch 12
794 TC12144/ TC12144 144 12.166 inch 10.40 lbs 12.000 inch 12
795 TS1212BS TS1212BS 1/2 12 1.167 inch 0.21 lbs 1.000 inch 12
796 TS1213BS TS1213BS 5/8 13 1.250 inch 0.21 lbs 1.083 inch 12
797 TS1214BS TS1214BS 5/8 14 1.333 inch 0.28 lbs 1.167 inch 12
798 TS1215BS TS1215BS 5/8 15 1.417 inch 0.34 lbs 1.250 inch 12
799 TS1216BS TS1216BS 5/8 16 1.500 inch 0.41 lbs 1.333 inch 12
800 TS1218BS TS1218BS 3/4 18 1.667 inch 0.51 lbs 1.500 inch 12
