Image may differ from product. See technical specification for details.

LVD

Wire Race Bearings LVD-Series are pre-assembled units with steel housing rings, external gears, and integrated 4-point bearing elements. Designed for medium speeds and accuracies, they handle high multi-directional loads while resisting shocks/vibrations. Thy are sealed on both sides.

Search for the bearing model you need

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh

Inner diameter (di)

50 mm-1670 mm

Outer diameter (Da)

150 mm-1930 mm

Weight

3.4 kg-484.2 kg

Brand

QIBR/OEM/Neutral

Package

QIBR/Standard Industrial Package/OEM

Applications

Industrial automation, grinding machines, MRI/CT scanner, material handling systems, packaging machinery, etc

QIBR Model Selection

Filters

Height inner ring (H2)

Height outer ring (H1)

Outer diameter (Da)

Overall height (H)

Weight

Inner diameter (di)

Rolling element center diameter (T)

NO.	Product Number	Height inner ring (H2)	Height outer ring (H1)	Outer diameter (Da)	Overall height (H)	Weight	Inner diameter (di)	Rolling element center diameter (T)
1	LVD-0100	27 mm	27 mm	150 mm	34+/-0.4 mm	3.4 kg	50 mm	100 mm
2	LVD-0150	27 mm	27 mm	200 mm	34+/-0.4 mm	5 kg	100 mm	150 mm
3	LVD-0200	27 mm	27 mm	250 mm	34+/-0.4 mm	6.7 kg	150 mm	200 mm
4	LVD-0250	27 mm	27 mm	300 mm	34+/-0.4 mm	8.4 kg	200 mm	250 mm
5	LVD-0300	31 mm	31 mm	360 mm	38+/-0.4 mm	14.1 kg	240 mm	300 mm
6	LVD-0350	31 mm	31 mm	410 mm	38+/-0.4 mm	16.5 kg	290 mm	350 mm
7	LVD-0400	37 mm	37 mm	470 mm	44+/-0.5 mm	26 kg	330 mm	400 mm
8	LVD-0450	37 mm	37 mm	520 mm	44+/-0.5 mm	29.2 kg	380 mm	450 mm
9	LVD-0500	42 mm	42 mm	580 mm	49+/-0.5 mm	42.4 kg	420 mm	500 mm
10	LVD-0600	42 mm	42 mm	680 mm	49+/-0.5 mm	50.8 kg	520 mm	600 mm
11	LVD-0700	45 mm	45 mm	790 mm	53+/-0.5 mm	73 kg	610 mm	700 mm
12	LVD-0800	45 mm	45 mm	890 mm	53+/-0.5 mm	83.2 kg	710 mm	800 mm
13	LVD-0900	45 mm	45 mm	990 mm	53+/-0.5 mm	93.6 kg	810 mm	900 mm
14	LVD-1000	45 mm	45 mm	1090 mm	53+/-0.5 mm	104 kg	910 mm	1000 mm
15	LVD-1200	52 mm	52 mm	1300 mm	60+/-0.5 mm	158.5 kg	1100 mm	1200 mm
16	LVD-1400	52 mm	52 mm	1500 mm	60+/-0.5 mm	184.9 kg	1300 mm	1400 mm
17	LVD-1600	82 mm	82 mm	1730 mm	90+/-0.5 mm	430.8 kg	1470 mm	1600 mm
18	LVD-1800	82 mm	82 mm	1930 mm	90+/-0.5 mm	484.2 kg	1670 mm	1800 mm
