Image may differ from product. See technical specification for details.

Wire Race Bearings

Application: Solar panels/Antennas/Robot joints/High-precision indexing tables/3D printer rotary platforms

Alternative Brands: Franke

Subseries:

LEL
LER
LEW
LSA
......

Specifications:

Weight: 0.01-484.2kg
Torque: 0.2-66200kNm
Structures: Outer Ring, Inner Ring, Spacer, Rolling element, Seal
Package: Standard Export Package

Wire Race Bearings

LEL

Wire Race Bearings LEL-Series are engineered to address extreme performance requirements in rotational smoothness and micron-level positioning accuracy. Their hardened, precision-machined ground raceways combined with optimized geometric congruence between ball curvature and raceway profile deliver enhanced load distribution, minimized stress concentrations and dynamic stability across variable speed/temperature conditions.

LEL

LEW

Wire Race Bearings LEW-Series provide robust performance for medium-speed precision applications, featuring cross-optimized roller arrangements that ensure smooth operation under combined tilt moments and omnidirectional loads. Their space-optimized footprint integrates high rigidity with shock/vibration resistance, while the orthogonal roller geometry enables exceptional multi-axis load capacity.

LEW

LSA

Wire Race Bearings LSA-Series offer smooth operation in ultra-thin profiles with tool-free installation, featuring split hardened raceways and a 4-point contact system. The polymer cage securely retains balls, dampens vibrations while maintaining cost efficiency. Ideal for space-sensitive environments requiring frequent maintenance, including food processing conveyors, miniature robotic joints, and light industrial automation systems.

LSA

LVA

Wire Race Bearings LVA-Series are pre-assembled units with steel housing rings and integrated 4-point contact bearings, designed for medium-speed applications requiring multidirectional load capacity. Their sealed construction with factory-adjusted preload ensures shock/vibration-resistant performance.

LVA

LVB

Wire Race Bearings LVB-Series are pre-assembled units with aluminum housing rings and integrated bearings, designed for medium-speed applications requiring balanced accuracy and lightweight performance. Featuring a 4-point load design, they handle equal high forces from all directions while resisting shocks and vibrations. Thy are sealed on both sides.

LVB

LVC

Wire Race Bearings LVC-Series are double-row angular contact ball bearings with integrated components, engineered for extreme rotational speeds. Their 4-point contact design and factory preload ensure high dynamic performance with minimal rotational resistance and low starting torque. The steel construction provides shock/vibration resistance while low friction coefficients enable near-maintenance operation and extended service life.

LVC

LVD

Wire Race Bearings LVD-Series are pre-assembled units with steel housing rings, external gears, and integrated 4-point bearing elements. Designed for medium speeds and accuracies, they handle high multi-directional loads while resisting shocks/vibrations. Thy are sealed on both sides.

LVD

LVE

Wire Race Bearings LVE-Series combine toothed belt gearing with aluminum housing rings and integrated bearing elements. Suitable for medium speeds and accuracies, these lightweight units are often available from stock. Designed as 4-point bearings, they handle equal loads from all directions while resisting shocks and vibrations. The assemblies feature double-sided seals and come preload-adjusted for immediate use.

LVE

LVG

Wire Race Bearings LVE-Series combine toothed belt gearing, aluminum housing rings, and integrated bearing elements for medium-speed applications. These 4-point contact bearings evenly handle multidirectional loads while resisting shocks/vibrations.

LVG
